Dahua DH-IPC-HDBW3867E-AS-IL-ANZ 8MP Smart Dual Light Fixed-Focal Dome WizSense Network Camera
Dahua DH-IPC-HDBW3867E-AS-IL-ANZ 8MP Smart Dual Light Dome WizSense Network Camera
1 1
Dahua

Dahua DH-IPC-HDBW3867E-AS-IL-ANZ 8MP Smart Dual Light Fixed-Focal Dome WizSense Network Camera

SKU: DH-IPC-HDBW3867E-AS-IL-ANZ
Description

The Dahua DH-IPC-HDBW3867E-AS-IL-ANZ is an 8MP (4K) WizSense fixed-focal dome with Smart Dual Light, built into a vandal-resistant IK10 metal housing for entries, ceilings and public-facing walls. It runs in efficient infrared at night and switches on a warm white light for full-colour footage the moment its AI detects a person or vehicle, while SMD 4.0 and AcuPick keep alerts and searches focused on real human and vehicle activity.

Key points
- 8MP 4K (3840 × 2160) 1/2.7" CMOS at up to 25/30 fps, 120 dB WDR
- Fixed 2.8 mm or 3.6 mm lens (choose before ordering)
- Smart Dual Light: IR and warm white, each up to 30 m; full colour on detection
- AcuPick and SMD 4.0 with human/vehicle classification; IVS tripwire/intrusion
- IP67 weatherproof and IK10 vandal-resistant metal dome; built-in mic
- microSD up to 512 GB; 12 VDC or PoE (802.3af) single-cable install
8MP Ultra HD 30m IR Night Vision Full Color Night Vision IP67 Weatherproof Human/Vehicle Detection False Alarm Reduction Built-in Microphone
$220.08 AUD $220.08 AUD $262.00 AUD
Sale 16.0% $41.92 AUD (16.0%)
Member Sign in to save $4.40 on this item — free to join.
Buying for business? Apply for trade pricing →
Building a kit or need installation? Email sales@smarket.com.au for a quote.

inc GST + 3 Year Warranty & Support
Free shipping over AUD300

In stock
Build your setup Build a complete CCTV system Complete setup from $719.53

A camera needs an NVR, a hard drive, and cabling to work. Add everything below, or pick a ready-made kit.

Select NVR (recorder) · channels ≥ your camera count
Select hard drive · 4TB ≈ 2-3 weeks for 4 cameras recording 24/7
Add accessories Optional. Junction box → hides & weatherproofs cable joins (best for outdoors). Brackets → only if mounting on a corner or under eaves. Cable → one per camera; skip if you already have your own.
1
1
1
1
1
1
1
Bundle total: $220.08
3-Year Warranty

3-Year Warranty

Warranty on all cameras

Free Shipping

Free Shipping

On orders over $300

30-Day Returns

30-Day Returns

Easy returns for unopened items

Fast Delivery

Fast Delivery

5-10 Day Delivery Australia-wide

§ 01Overview

What the DH-IPC-HDBW3867E-AS-IL-ANZ is

The Dahua DH-IPC-HDBW3867E-AS-IL-ANZ is an 8MP (4K) WizSense fixed-focal dome that pairs Smart Dual Light night vision with a tough IK10 vandal-resistant housing, made for entries, eaves, car parks, shopfronts and any public-facing spot where the camera itself needs protecting.

Its 1/2.7 inch CMOS sensor captures 3840 by 2160 detail at up to 25/30 fps, with 120 dB WDR to balance bright doorways against dark interiors.

Smart Dual Light is the headline feature.

At night the dome runs in efficient infrared, then the instant its AI detects a person or vehicle it switches on a warm white light to record full-colour footage, with both the IR and the warm light reaching up to 30 m.

Between events it drops back to IR, so you get colour evidence on people and cars without leaving a bright light burning all night.

You can also lock it to IR-only or warm-light-only if a site calls for it.

It ships with a fixed 2.8 mm or 3.6 mm lens, so choose the focal length before you order: the 2.8 mm gives a wider 110 degree entry or room view, the 3.6 mm narrows to about 86 degrees and reaches a little further down a corridor or driveway.

SMD 4.0 and IVS tripwire and intrusion analytics classify human and vehicle movement to cut false alarms, and AcuPick lets a compatible Dahua WizSense NVR find a particular person or vehicle in recordings in seconds.

A built-in microphone records audio, with audio and alarm in/out for integration.

The dome is built for Australian outdoors and abuse-prone spots: an IP67 seal against dust and rain plus an IK10 vandal-resistant metal housing.

Power is by PoE (802.3af) or 12 VDC over a single cable, drawing up to about 8.2 W on PoE, and footage records to a microSD card up to 512 GB or to a Dahua NVR.

There is a built-in microphone but no built-in speaker, so the camera records audio rather than offering built-in two-way talk.

See it in action

What the DH-IPC-HDBW3867E-AS-IL-ANZ features actually look like

Representative illustrations of how each key feature performs in a real scene.

8MP Ultra HD — 8MP (4K) resolution captures four times the detail of 1080p. Even when a person or car is fa... (1/2)
8MP Ultra HD — 8MP (4K) resolution captures four times the detail of 1080p. Even when a person or car is fa... (2/2)

8MP Ultra HD

8MP (4K) resolution captures four times the detail of 1080p.
Even when a person or car is far down the driveway, you can zoom in and still recognise a face or read a number plate — detail that lower-resolution cameras lose.
30m IR Night Vision — Built-in infrared lets the camera see in complete darkness up to around 30m — enough ... (1/2)
30m IR Night Vision — Built-in infrared lets the camera see in complete darkness up to around 30m — enough ... (2/2)

30m IR Night Vision

Built-in infrared lets the camera see in complete darkness up to around 30m — enough for a typical driveway, front yard or entrance. People and vehicles stay clear in black-and-white, brighter the closer they are.
Full Color Night Vision — Unlike plain black-and-white night vision, this camera can capture colour after d...

Full Color Night Vision

Unlike plain black-and-white night vision, this camera can capture colour after dark — so you can pick out the actual colour of a car, a jacket or a bag, detail that grey infrared footage loses.
Human/Vehicle Detection — Smart detection focuses on people and vehicles and can ignore things like swaying...

Human/Vehicle Detection

Smart detection focuses on people and vehicles and can ignore things like swaying branches, rain or small animals — helping cut down false alerts and making the right moments easier to find.
False Alarm Reduction — Filtering helps separate real activity from harmless movement like rain, leaves or ...

False Alarm Reduction

Filtering helps separate real activity from harmless movement like rain, leaves or pets, so you get fewer pointless notifications and the alerts that matter stand out.
IP67 Weatherproof — Sealed against dust and water to IP67, built to keep working through rain, storms and h...

IP67 Weatherproof

Sealed against dust and water to IP67, built to keep working through rain, storms and harsh sun — suitable for fully outdoor mounting.

Illustrative — simulated for demonstration

§ 02Engineering

DH-IPC-HDBW3867E-AS-IL-ANZ specifications

- 8MP 4K (3840 x 2160) 1/2.7" CMOS at up to 25/30 fps with 120 dB true WDR
- Fixed-focal 2.8 mm or 3.6 mm lens (F1.4, M12 mount) selected to suit the scene
- Smart Dual Light: IR and warm white each up to 30 m; warm light triggered by human or vehicle detection for full colour
- AcuPick fast smart search with a compatible Dahua WizSense NVR; SMD 4.0 and IVS tripwire/intrusion with human and vehicle classification
- IP67 weatherproof and IK10 vandal-resistant metal dome housing
- Built-in microphone with audio and alarm in/out; H.265 with microSD up to 512 GB and ONVIF
- 12 VDC or PoE (802.3af), up to ~8.2 W single-cable power and data

§ 03Full datasheet

Detailed specifications

Camera & Image

Camera & Image — Dahua DH-IPC-HDBW3867E-AS-IL-ANZ 8MP Smart Dual Light Fixed-Focal Dome WizSense Network Camera
FeatureDetail
Image Sensor 1/2.7" CMOS
Max. Resolution 3840 (H) × 2160 (V)
ROM 256 MB
RAM 1 GB
Scanning System Progressive
Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s
Min. Illumination 0.007 lux@F1.4 (Color, 30 IRE); 0.0007 lux@F1.4 (B/W, 30 IRE); 0 lux (Illuminator on)
S/N Ratio >56 dB
Day/Night Auto(ICR)/Color/B/W
BLC Yes
HLC Yes
WDR 120 dB
Scene Self-adaptation (SSA) Yes
White Balance Auto; natural; street lamp; outdoor; manual; regional custom
Gain Control Auto/Manual
Noise Reduction 3D NR
Motion Detection OFF/ON (4 areas, rectangular)
Region of Interest (RoI) Yes (4 areas)
Defog Yes
Image Rotation 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower)
Mirror Yes
Privacy Masking 8 areas
LDC Yes

§ 04Why choose this

Built for the way you actually use the DH-IPC-HDBW3867E-AS-IL-ANZ

Colour evidence, not a spotlight all night

Smart Dual Light keeps the dome in efficient IR until its AI sees a person or vehicle, then lights up in warm white for full-colour footage up to 30 m, so you capture colour detail on intruders without running a bright light all night or annoying the neighbours.

Built to be tampered with

An IK10 vandal-resistant metal dome plus IP67 sealing means the camera survives knocks, weather and deliberate attacks, which is exactly what entryways, car parks and public areas demand.

Find footage fast

AcuPick on a Dahua WizSense NVR locates a specific person or vehicle in recordings in seconds, and SMD 4.0 keeps the alerts that get there worth checking.

Flagship 8MP detail

An 8MP 4K sensor with 120 dB WDR captures faces and number plates with room to digitally zoom in on review, well beyond a 2MP or 4MP dome.

§ 05Where it fits

Right at home in these scenarios

Entrances and reception areas

A low-profile dome on a ceiling or eave watches a doorway or foyer in 4K, switching to full colour the moment someone is detected.

Car parks and shopfronts

IK10 toughness handles public areas where cameras are within reach, while dual-light colour helps capture vehicle colours and clothing at night.

Schools and stairwells

Vandal resistance suits corridors, stairwells and grounds where tampering is a real concern.

AI NVR systems

Add it to a Dahua WizSense NVR for continuous recording and AcuPick fast search across all your cameras.

§ 06Setup

Installation & setup

01

What's in the box

The IPC-HDBW3867E-AS-IL-ANZ dome camera with its mounting base, screw pack and a waterproofing gland for the network connector. A PoE switch or injector, network cable, microSD card and any junction box or bracket are not included.

02

Installation requirements

Mount the dome to a ceiling, eave or wall that can carry it, and run Cat5e/Cat6 back to a PoE switch or Dahua NVR. Seal the connector with the supplied gland for outdoor use. Where the camera needs a junction box for the cable join or a bracket to angle off a flat wall, add a compatible Dahua part and confirm it under the camera's Accessory Selection. Insert a microSD card or set the camera to record to your NVR, then choose the Smart Dual Light mode that suits the site.

§ 07Questions

Frequently asked about the DH-IPC-HDBW3867E-AS-IL-ANZ

Q.01

Does the HDBW3867E record in full colour at night?
It records full colour at night whenever the warm white light is active. By default the dome runs in infrared, and the moment its AI detects a person or vehicle it switches on the warm light to capture full-colour footage up to 30 m, then reverts to IR once the subject leaves. You can also set it to IR-only for a discreet, dark install, or warm-light-only if you want colour all the time.
Q.02

Does it come with a 2.8 mm or 3.6 mm lens?
It is a fixed-focal camera offered with either a 2.8 mm or a 3.6 mm lens, so you choose the focal length before ordering. The 2.8 mm gives a wider 110 degree view for a room, entry or carport, while the 3.6 mm narrows to about 86 degrees and reaches a little further down a corridor or driveway. There is no motorised zoom on this model.
Q.03

What does the IK10 rating mean for me?
IK10 is the highest standard impact rating, so the metal dome is built to shrug off heavy knocks and deliberate tampering. Combined with the IP67 weather seal it makes this camera a strong choice for car parks, shopfronts, schools, stairwells and any spot within reach where a camera could be hit or attacked.
Q.04

What is AcuPick and do I need a special NVR for it?
AcuPick is Dahua's fast smart-search feature. It lets you search live and recorded video to quickly locate a particular person or vehicle instead of scrubbing through hours of footage. To use AcuPick you pair the camera with a compatible Dahua WizSense AI NVR; the camera's own SMD 4.0, IVS and recording all work regardless of the recorder.
Q.05

Will it cut false alarms from pets, trees and shadows?
Largely, yes. SMD 4.0 and WizSense analytics classify human and vehicle movement, so alerts and recording are driven by people and cars rather than by animals, blowing foliage or lighting changes. You can also draw tripwire and intrusion zones so only the areas you care about trigger events.
Q.06

Does it have two-way audio?
It has a built-in microphone that records audio with the video, plus audio input and output ports, but no built-in speaker, so it does not offer built-in two-way talk. An external active speaker can be wired to the audio output if you need to play audio.
Q.07

How is it powered and do I need an NVR?
It runs on PoE using the 802.3af standard, drawing up to about 8.2 W with the warm light and analytics active, or on a 12 VDC supply, so one network cable carries power and data. It records to a microSD card up to 512 GB for a single camera, or connect it to a Dahua WizSense PoE NVR for continuous recording and AcuPick fast search.
Q.08

Can I mount it on a wall as well as a ceiling?
Yes. The dome mounts on a ceiling, eave or wall. For a wall position angled out over an area, or where the camera needs a tidy cable join, add a Dahua junction box or wall mount; check the Accessory Selection line on the camera datasheet for the matching part.
