Hikvision Acusense DS-2CD2366G2-ISU/SL IP Camera 6MP With Warning & Strobe Turret Network Camera
Skip to product information
1
/
of
1
Vendor:
Hikvision
Hikvision Acusense DS-2CD2366G2-ISU/SL IP Camera 6MP With Warning & Strobe Turret Network Camera
SKU: DS-2CD2366G2-ISU/SL
Description
- 6MP resolution: delivers high-resolution imaging capability.
- Active deterrence: features audio alarm and strobe light to warn intruders.
- Built-in mic: enables clear audio capture and real-time two-way talk communication.
- IP67 rated: ensures reliable waterproof performance for outdoor operation.
Regular price
$266.45 AUD
Sale price
$266.45 AUD
Regular price
$335.00 AUD
Sale
20.46%
$68.55 AUD
(20.46%)
inc GST + 3 Year Warranty & Support
Free shipping over AUD300
In stock
Hikvision Acusense DS-2CD2366G2-ISU/SL IP Camera 6MP With Warning & Strobe Turret Network Camera
1
/
of
1
Build your setup Configure your bundle Bundle this camera with NVR, hard drive & accessories Complete setup from $1,210.05 or kits from $2,206.75
Or pick a ready-made kit
3-Year Warranty
Warranty on all cameras
Free Shipping
On orders over $300
30-Day Returns
Easy returns for unopened items
Fast Delivery
5-10 Day Delivery Australia-wide
§ 01Overview
What this product is
Lens options: 2.8mm or 4mm focal length.
Color options: White or Black.
Note: Please indicate your choice in your order message.
Hikvision HIK-2CD23662USL2 6MP outdoor security camera delivers high resolution surveillance for Australian properties
Its advanced AcuSense gen 2 technology drastically reduces false alarms triggered by animals or falling leaves
§ 02Engineering
Technical specifications
- 6MP resolution security cameras, for clear identification at distance
- Excellent low-light night vision powered by DarkFighter technology
- 120dB true WDR technology, handles challenging lighting conditions
- AI classification for human and vehicle detection, reducing false alarms
- Active deterrent with strobe light and audio alarm for intruders
- Real-time security via built-in two-way audio communication
- IP67 weatherproof rating for reliable outdoor surveillance cameras
- Excellent low-light night vision powered by DarkFighter technology
- 120dB true WDR technology, handles challenging lighting conditions
- AI classification for human and vehicle detection, reducing false alarms
- Active deterrent with strobe light and audio alarm for intruders
- Real-time security via built-in two-way audio communication
- IP67 weatherproof rating for reliable outdoor surveillance cameras
§ 03Full datasheet
Detailed specifications
Camera & Image
| Feature | Detail |
|---|---|
| Image Sensor | 1/2.4" Progressive Scan CMOS |
| Max. Resolution | 3200 × 1800 |
| Min. Illumination | Color: 0.003 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
| Shutter Speed | 1/3 s to 1/100,000 s |
| Slow Shutter | Yes |
| Wide Dynamic Range | 120 dB |
| Day & Night | IR cut filter |
| SNR | ≥ 52 dB |
| Target Cropping | Yes |
| Day/Night Switch | Day, Night, Auto, Schedule |
| Image Enhancement | BLC, HLC, 3D DNR |
| Image Parameters Switch | Yes |
| Image Settings | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser |
Lens & Distance
| Feature | Detail |
|---|---|
| Lens Type | Fixed focal lens, 2.8, 4, and 6 mm optional |
| Iris Type | Fixed |
| Focal Length & FOV | 2.8 mm, horizontal FOV 105.1°, vertical FOV 53.4°, diagonal FOV 128.6° | 4 mm, horizontal FOV 83.9°, vertical FOV 44.5°, diagonal FOV 100.8° | 6 mm, horizontal FOV 47.5°, vertical FOV 26°, diagonal FOV 54.5° |
| Aperture | F1.6 |
| Lens Mount | M12 |
| DORI | 2.8 mm: D: 78.6 m, O: 31.2 m, R: 15.7 m, I: 7.9 m | 4 mm: D: 95.6 m, O: 37.9 m, R: 19.1 m, I: 9.6 m | 6 mm: D: 160.0 m, O: 63.5 m, R: 32.0 m, I: 16.0 m |
| Pan Range | 0° to 360° |
| Tilt Range | 0° to 75° |
| Rotate Range | 0° to 360° |
Night Vision
| Feature | Detail |
|---|---|
| Supplement Light Type | IR |
| IR Range | Up to 30 m |
| IR Wavelength | 850 nm |
| Smart Supplement Light | Yes |
| Visual Alarm | Yes |
Video
| Feature | Detail |
|---|---|
| Main Stream | 50 Hz: 25 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) | 60 Hz: 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) |
| Sub-Stream | 50 Hz: 25 fps (640 × 480, 640 × 360) | 60 Hz: 30 fps (640 × 480, 640 × 360) |
| Third Stream | 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) | 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360); Third stream is supported under certain settings. |
| Video Compression | Main stream: H.265/H.264/H.265+/H.264+; Sub-stream: H.265/H.264/MJPEG; Third stream: H.265/H.264; Third stream is supported under certain settings. |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| H.264 Type | Baseline Profile/Main Profile/High Profile |
| H.265 Type | Main Profile |
| H.264+ | Main stream supports |
| H.265+ | Main stream supports |
| Bit Rate Control | CBR/VBR |
| Scalable Video Coding (SVC) | H.264 and H.265 encoding |
| Region of Interest (ROI) | 1 fixed region for main stream and sub-stream |
Audio
| Feature | Detail |
|---|---|
| Audio Type | Mono sound |
| Environment Noise Filtering | Yes |
| Audio Sampling Rate | 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Audio Compression | G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC |
| Audio Bit Rate | 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC) |
| Built-in Microphone | Yes |
| Built-in Speaker | Power: 1.2 W. Max. sound pressure level: 10 cm: 95 dB. |
AI & Deep Learning
| Feature | Detail |
|---|---|
| Face Capture | Yes |
| Perimeter Protection | Line crossing detection, intrusion detection, region entrance detection, region exiting detection; Supports human and vehicle targets classification |
Network & Storage
| Feature | Detail |
|---|---|
| Simultaneous Live View | Up to 6 channels |
| API | Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP |
| User/Host | Up to 32 users. 3 user levels: administrator, operator and user |
| Security | Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface |
| Network Storage | NAS (NFS, SMB/CIFS), auto network replenishment (ANR); Together with high-end Hikvision memory card, memory card encryption and health detection are supported. |
| Client | iVMS-4200, Hik-Connect, Hik-Central |
| Web Browser | Plug-in required live view: IE 10+; Plug-in free live view: Chrome 57.0+, Firefox 52.0+; Local service: Chrome 57.0+, Firefox 52.0+ |
Event & Alarm
| Feature | Detail |
|---|---|
| Basic Event | Motion detection (human and vehicle targets classification), video tampering alarm, exception |
| Smart Event | Scene change detection |
| Linkage Method | Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture, trigger alarm output, audible warning, strobe light |
Interface
| Feature | Detail |
|---|---|
| Alarm | 1 input, 1 output (max. 24 VDC/24 VAC, 500 mA) |
| Audio Input | 1 input (line in), terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium |
| Audio Output | 1 output (line out), terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium |
| On-Board Storage | Built-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB |
| Reset Key | Yes |
| Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
General & Environment
| Feature | Detail |
|---|---|
| Language | 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| General Function | Anti-flicker, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter |
| Software Reset | Yes |
| Firmware Version | V5.5.113 |
| Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Startup and Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Power Supply | 12 VDC ± 25%, reverse polarity protection; PoE: 802.3af, Class 3 |
| Power Consumption and Current | 12 VDC, 0.70 A, max. 8.4 W; PoE (802.3af, 36 V to 57 V), 0.27 A to 0.16 A, max. 9.7 W |
| Power Interface | Ø5.5 mm coaxial power plug |
| Material | Metal except for trim ring |
| Dimension | Ø138.3 mm× 112.1 mm (Ø5.4" × 4.4") |
| Package Dimension | 170 mm × 170 mm × 150 mm (6.7" × 6.7" × 5.9") |
| Weight | Approx. 820 g (1.8 lb.) |
| With Package Weight | Approx. 1150 g (2.5 lb.) |
| EMC | FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) |
| Safety | UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014) |
| Environment | CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
| Protection | IP67 (IEC 60529-2013) |
§ 07Questions
Frequently asked
Q.01
Does the strobe light and alarm activate automatically, or does it need to be manually triggered?
It activates automatically when the camera detects a human or vehicle target using AcuSense AI. You can configure the linkage settings via the web interface or iVMS-4200 to trigger the strobe and audible warning only for specific smart events like intrusion detection or line crossing.
Q.02
Will the strobe light and alarm disturb my neighbours?
It's possible if the camera faces toward neighbouring properties. The strobe and siren are designed for targeted deterrence, so careful placement and using privacy masks to limit detection zones to your own property is strongly recommended. In Australia, persistent light or noise nuisance from security devices can be subject to local council complaints under environmental protection laws.
Q.03
Does this camera work with my existing Hikvision NVR?
Yes, it works plug-and-play with Hikvision AcuSense-compatible NVRs (such as the NXI series). For full smart features including human/vehicle classification and strobe linkage to trigger correctly, ensure both the camera and NVR firmware are up to date — mismatched firmware is the most common cause of AcuSense features not functioning as expected.
Q.04
Can I use this camera as a standalone unit without an NVR?
Yes. Insert a microSD card (up to 512 GB) and the camera can record locally and be managed via the Hik-Connect app for live view, playback, and alerts — no NVR required. For continuous 24/7 recording rather than event-based recording, an NVR or NAS is recommended.
Q.05
Does it record in colour at night, or only black and white?
At night it switches to black and white IR mode by default, delivering up to 30 m of IR night vision. It does not have a built-in white light for full-colour night recording — if full-colour night footage is a priority, consider Hikvision's ColorVu range instead.
Q.06
Which lens size should I choose — 2.8 mm, 4 mm, or 6 mm?
For most Australian residential driveways, entry points, and backyards, the 2.8 mm lens (105° horizontal FOV) is the most popular choice as it covers wide areas at close range. The 4 mm is a good all-rounder for medium distances, while 6 mm suits narrower, longer corridors or laneways where detail at greater distance is needed.
Q.07
Can I receive push notifications to my phone when it detects a person?
Yes. Link the camera to the free Hik-Connect app and enable smart event notifications. Because AcuSense filters out non-human/vehicle movement like animals and wind-blown foliage, push alerts are far more reliable and less prone to false alarms than standard motion detection cameras.
Q.08
Is this camera suitable for outdoor use in Australia's harsh climate?
Yes, it carries an IP67 rating, meaning it is fully protected against dust and water immersion, making it suitable for Australian outdoor conditions including rain and dust. However, Hikvision notes this model has no specific anti-corrosion protection, so it is not recommended for coastal or high-salt-air environments without additional protection.
