Bosch CP155B External Keypad Combo Reader for Bosch 6000
1 1
Bosch

Bosch CP155B External Keypad Combo Reader for Bosch 6000

SKU: CP155B
Description

The Bosch CP155B is an external keypad with a built-in smart-prox reader for the Bosch Solution 6000 alarm panel. Rated IP65 and built from UV-resistant plastic, it suits an entry door, gate or carport where you need to arm, disarm and control access from outside.

Key points
- External, IP65 weather-rated, UV-resistant housing
- Built-in smart-prox reader (PR301, PR350, PR365, PR370 cards/tokens)
- Backlit numeric keypad with red, green and blue status LEDs
- For Bosch Solution 6000 / 144 (alarm and access control)
- Encrypted RS485 LAN with front and rear tamper
- 10VDC, 100mA max; occupies one keypad position
$406.90 AUD $406.90 AUD $411.00 AUD
Sale 1.0% $4.10 AUD (1.0%)
Business or bulk buyer? Apply for trade pricing →
Found a lower price? We’ll match it →

inc GST + 3 Year Warranty & Support
Free shipping over AUD300

In stock
3-Year WarrantyOn all cameras
Free ShippingOn orders over $300
30-Day ReturnsUnopened items
Fast Delivery1–5 days Australia-wide
Build your setup Build a complete CCTV system

A camera needs an NVR, a hard drive, and cabling to work. Add everything below, or pick a ready-made kit.

Add accessories Optional. Junction box → hides & weatherproofs cable joins (best for outdoors). Brackets → only if mounting on a corner or under eaves. Cable → one per camera; skip if you already have your own.
0
0
0
0
0
0
Bundle total: $406.90

§ 01Overview

What the CP155B is

The Bosch CP155B is the external smart-prox keypad for the Bosch Solution 6000. It brings alarm control and door access outside the building, so you can arm and disarm at the front door or gate and present a card to enter, with a housing built to handle the weather.

It is rated IP65 and made from high-strength, UV-resistant plastic for external installation, and it has both front and rear tamper protection. The built-in smart-prox reader works with Bosch PR301, PR350, PR365 and PR370 cards and tokens, the numeric keys are backlit for night use, and red, green and blue indicators show area and door-lock status.

The CP155B connects to the panel over an encrypted RS485 LAN, with anti-replay and anti-substitution protection, and occupies one standard keypad position. It runs on 10VDC at 100mA max, provides both alarm and access-control functions on the Solution 6000, and is fitted by a licensed installer.

§ 02Engineering

CP155B specifications

- External keypad rated IP65 and built from UV-resistant plastic, suited to entry doors, gates and carports.

- Built-in smart-prox reader compatible with Bosch PR301, PR350, PR365 and PR370 cards and tokens for card-based arming and access.

- Backlit numeric keypad with red, green and blue indicators showing area and door-lock status.

- For the Bosch Solution 6000 / 144, providing both alarm control and access-control functions.

- Connects on an encrypted RS485 LAN with anti-replay and anti-substitution protection; front and rear tamper.

- 10VDC at 100mA max; occupies one standard keypad position in the panel configuration.

§ 04Why choose this

Built for the way you actually use the CP155B

Built for outside

An IP65 weather rating and UV-resistant housing let you put a keypad at the front door, gate or carport.

Card or PIN

The built-in smart-prox reader works with Bosch PR-series cards and tokens, so people can tap to disarm or enter rather than key a PIN.

Alarm and access in one

It arms and disarms the Solution 6000 and can control a door, useful for shared entries and small sites.

Secure and tamper-protected

Encrypted RS485 with anti-replay protection plus front and rear tamper guards against interference.

§ 05Where it fits

Right at home in these scenarios

Front-door or gate control

Arm, disarm and enter from outside, with a housing rated for sun and rain.

Card-based entry

Staff or family tap a PR-series card or token to disarm and unlock instead of sharing a PIN.

Carports and side gates

A weather-rated keypad suits exposed entries where an indoor keypad would not survive.

Small business access

Combine alarm control with a single access-controlled door at the entrance.

§ 06Setup

Installation & setup

01

What it is

An external keypad with a smart-prox reader for the Bosch Solution 6000. It occupies one keypad position and provides alarm and access functions.

02

Wiring

Connect over the panel's encrypted RS485 LAN. Power is 10VDC at 100mA max. Use the front and rear tamper as part of the install.

03

Cards

Issue Bosch PR301, PR350, PR365 or PR370 cards or tokens for users; the installer enrols them to the panel.

04

Professional install

In Australia a Bosch alarm should be installed by a licensed security installer, who wires the device to the panel on the RS485 LAN or wireless receiver, programs it and tests the system. Mount it at a sheltered point where practical even though it is IP65 rated.

§ 07Questions

Frequently asked about the CP155B

Q.01

Can the CP155B be used outdoors?
Yes. It is rated IP65 and made from UV-resistant plastic, so it suits an entry door, gate or carport, ideally in a sheltered spot.
Q.02

Which panel does it work with?
The Bosch Solution 6000 / 144, providing both alarm control and access-control functions.
Q.03

What cards does the reader use?
The built-in smart-prox reader works with Bosch PR301, PR350, PR365 and PR370 cards and tokens.
Q.04

Can people enter with a card instead of a code?
Yes. Users can present a PR-series card or token to disarm and enter, or key a PIN on the backlit keypad.
Q.05

How does it connect to the panel?
Over an encrypted RS485 LAN with anti-replay and anti-substitution protection; it occupies one keypad position.
Q.06

Is it tamper protected?
Yes. It has front and rear tamper protection.
Q.07

How is it powered?
10VDC at 100mA max from the panel.
Q.08

Who installs it?
A licensed installer wires it to the LAN, mounts it and enrols the access cards.

§ 09Bundles

Recommended packages

01

Indoor keypads too

Pair an external CP155B with an indoor CP737B WiFi keypad or CP736B graphic keypad on the same Solution 6000.

02

Add a reader

For a reader-only point, see the PR115B slim smartcard reader or the PR116B mullion prox reader.
