Hikvision AE-VC222T-ITS Vehicle-Mounted 1080P Analog IR Camera — Shock-Proof and HD Coaxial Output
Skip to product information
1
/
of
1
Vendor:
Hikvision
Hikvision AE-VC222T-ITS Vehicle-Mounted 1080P Analog IR Camera — Shock-Proof and HD Coaxial Output
SKU: AE-VC122T-ITS
Description
The Hikvision AE-VC122T-ITS is a rugged 720P mobile camera built for vehicles. With a shock-proof conch housing, built-in infrared and a microphone, and an aviation-plug connector, it captures clear HD-TVI video and audio inside or around buses, trucks, vans and work machinery - even under vibration, heat and cold.
At a glance
- 720P HD-TVI mobile camera with a 1/2.9" progressive-scan CMOS sensor
- Shock-proof conch design with an aviation-plug connector for mobile use
- Built-in infrared and a built-in microphone for low-light vision and audio
- Lens options of 2.1mm (117 degrees), 2.8mm (96 degrees) or 3.6mm (75 degrees)
- 9-16VDC supply, low 2.2W draw, wide -40 to 75 degree operation; HD coaxial output
Regular price
$162.00 AUD
Sale price
$162.00 AUD
Regular price
$167.00 AUD
Sale
2.99%
$5.00 AUD
(2.99%)
Business or bulk buyer? Apply for trade pricing →
Found a lower price? We’ll match it →
Delivery, warranty & returns · ships same day before 2pm
- Same-day dispatch on in-stock orders placed before 2pm, Sydney time.
- 1–4 business days Australia-wide. Free standard shipping over $300, flat $25 under.
- 3-year warranty on cameras and recorders, back-to-base, plus your Australian Consumer Law rights.
- 30-day returns on unopened items. Faulty on arrival? We cover return shipping.
- Genuine Australian stock. Never grey imports. Prices include GST.
In stock
No reviews
Hikvision AE-VC222T-ITS Vehicle-Mounted 1080P Analog IR Camera — Shock-Proof and HD Coaxial Output
1
/
of
1
All cameras, NVRs and DVRs come with a 3-year back-to-base manufacturer warranty covering defects in materials and workmanship, in addition to your rights under Australian Consumer Law. Hard drives and accessories are covered as set out in our Warranty Policy.
Standard shipping is free on all orders over $300 AUD, Australia-wide. Orders under $300 ship at a flat rate of $25, calculated at checkout. Tracking is included on every order.
You have 30 days from the day you receive your order to request a change-of-mind return. Items must be unopened, factory-sealed and in resalable condition. A 15% restocking fee applies and return postage is at your cost. Faulty or incorrectly supplied items are different: we cover the return shipping and refund or replace at no charge. Read the full Return & Refund Policy.
Order before 2pm (Sydney time) on a business day and in-stock items are dispatched the same day. Most orders arrive within 1–4 business days Australia-wide; remote and regional areas can take a little longer. You'll receive a tracking number by email as soon as your order leaves the warehouse.
Build your setup
Build a complete CCTV system
—
Complete setup from
$1,206.15
A camera needs an NVR, a hard drive, and cabling to work. Add everything below, or pick a ready-made kit.
§ 01Overview
What the AE-VC122T-ITS is
The Hikvision AE-VC122T-ITS is a 720P mobile vehicle camera engineered for the knocks of life on the road. Its compact, shock-proof conch housing and aviation-plug connector are made for buses, trucks, vans, forklifts and emergency or work vehicles, where vibration, dust and big temperature swings would defeat an ordinary camera.
It uses a 1/2.9-inch progressive-scan CMOS sensor for smooth 720P HD-TVI video with reduced motion blur, and is available with 2.1mm, 2.8mm or 3.6mm fixed lenses giving a field of view from a wide 117 degrees down to a more focused 75 degrees - so you can fit it to a cabin, a doorway, a blind spot or a load area. A built-in infrared light supports low-light and night capture, and a built-in microphone adds audio context to recordings (note it is a microphone only, so it does not provide talk-back).
Power is a simple 9-16VDC at up to 2.2W, and it operates from -40 to 75 degrees in up to 90% humidity. The camera outputs HD-TVI video over coax via an aviation plug, so it is designed to connect to a mobile DVR (MDVR) rather than a network NVR, and it does not use PoE. A patented universal adjustment mechanism makes aiming quick during installation. Please note the product title lists it as a 1080P AE-VC222T-ITS; per Hikvision, this SKU (AE-VC122T-ITS) is a 720P mobile camera.
§ 02Engineering
AE-VC122T-ITS specifications
- 720P HD-TVI video on a 1/2.9" progressive-scan CMOS sensor for smooth, low-blur capture in moving vehicles.
- Shock-proof conch housing with an aviation-plug connector, rated -40 to 75 degrees, for demanding mobile environments.
- Built-in infrared light for clear black-and-white images in dark cabins and low-light conditions.
- Built-in microphone adds audio context to recordings (microphone only - no talk-back speaker).
- Lens options of 2.1mm (117 degrees), 2.8mm (96 degrees) or 3.6mm (75 degrees) to suit cabins, doorways and blind spots.
- Simple 9-16VDC power at up to 2.2W with HD coaxial output via aviation plug; connects to a mobile DVR, not a network NVR.
- Shock-proof conch housing with an aviation-plug connector, rated -40 to 75 degrees, for demanding mobile environments.
- Built-in infrared light for clear black-and-white images in dark cabins and low-light conditions.
- Built-in microphone adds audio context to recordings (microphone only - no talk-back speaker).
- Lens options of 2.1mm (117 degrees), 2.8mm (96 degrees) or 3.6mm (75 degrees) to suit cabins, doorways and blind spots.
- Simple 9-16VDC power at up to 2.2W with HD coaxial output via aviation plug; connects to a mobile DVR, not a network NVR.
§ 03Full datasheet
Detailed specifications
Camera & Image
| Feature | Detail |
|---|---|
| Image Sensor | Progressive Scan CMOS |
| Min. Illumination | 0.1 Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Shutter Time | 1/25 s to 1/50,000 s |
| Angle | Horizontal: 0 to 60°, vertical: 0 to 50°, rotate: 0 to 360° |
| Day & Night | Electronic |
| Frame Rate | 1080P @25fps |
| Synchronization | Internal |
| S/N Ratio | 42 dB |
Lens & Distance
| Feature | Detail |
|---|---|
| FOV | 2.1 mm, horizontal FOV 117°, vertical FOV 66°, diagonal FOV 143° | 2.8 mm, horizontal FOV 96°, vertical FOV 51°, diagonal FOV 115° | 3.6 mm, horizontal FOV 75°, vertical FOV 44°, diagonal FOV 90° |
| Lens Mount | M12 |
Night Vision
| Feature | Detail |
|---|---|
| IR Distance | 10 m |
Interface
| Feature | Detail |
|---|---|
| Video Output | 1, Vp-p Composite Output (aviation plug) |
| Audio Input | Build-in MIC |
| Audio Output | 1, aviation plug (linear resistance: 1 kΩ) |
| Aviation Pin Order | 1: Video, 2: Audio, 3: Power, 4: Ground |
General & Environment
| Feature | Detail |
|---|---|
| Working Temperature | -40 °C to 75 °C (-40 °F to 167 °F) |
| Working Humidity | ≤ 90% |
| Power Supply | 9 to 16 V DC |
| Power Consumption | Max. 2.2 W |
| Dimension | 74 mm × 64.5 mm × 71.1 mm (2.9" × 2.5" × 2.8") |
| Weight | 200 g (0.44 lb.) |
| Camera & Image — Image Sensor | Progressive Scan CMOS |
|---|---|
| Camera & Image — Min. Illumination | 0.1 Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Camera & Image — Shutter Time | 1/25 s to 1/50,000 s |
| Camera & Image — Angle | Horizontal: 0 to 60°, vertical: 0 to 50°, rotate: 0 to 360° |
| Camera & Image — Day & Night | Electronic |
| Camera & Image — Frame Rate | 1080P @25fps |
| Camera & Image — Synchronization | Internal |
| Camera & Image — S/N Ratio | 42 dB |
| Lens & Distance — FOV | 2.1 mm, horizontal FOV 117°, vertical FOV 66°, diagonal FOV 143° | 2.8 mm, horizontal FOV 96°, vertical FOV 51°, diagonal FOV 115° | 3.6 mm, horizontal FOV 75°, vertical FOV 44°, diagonal FOV 90° |
| Lens & Distance — Lens Mount | M12 |
| Night Vision — IR Distance | 10 m |
| Interface — Video Output | 1, Vp-p Composite Output (aviation plug) |
| Interface — Audio Input | Build-in MIC |
| Interface — Audio Output | 1, aviation plug (linear resistance: 1 kΩ) |
| Interface — Aviation Pin Order | 1: Video, 2: Audio, 3: Power, 4: Ground |
| General & Environment — Working Temperature | -40 °C to 75 °C (-40 °F to 167 °F) |
| General & Environment — Working Humidity | ≤ 90% |
| General & Environment — Power Supply | 9 to 16 V DC |
| General & Environment — Power Consumption | Max. 2.2 W |
| General & Environment — Dimension | 74 mm × 64.5 mm × 71.1 mm (2.9" × 2.5" × 2.8") |
| General & Environment — Weight | 200 g (0.44 lb.) |
§ 04Why choose this
Built for the way you actually use the AE-VC122T-ITS
Audio and night vision
A built-in microphone and infrared light add context and low-light capture for incident review.
Flexible field of view
Three lens options from 117 down to 75 degrees fit cabins, doorways, blind spots and load areas.
Simple to power
A 9-16VDC supply at just 2.2W wires straight into the vehicle's electrical system.
§ 05Where it fits
Right at home in these scenarios
Buses and coaches
Monitor drivers, passengers and doorways for safety and incident recording with audio.
Trucks and vans
Cover cabins, load areas and blind spots on delivery and service fleets.
Forklifts and machinery
Add wide-angle visibility in warehouses, loading docks and tight industrial spaces.
Emergency and work vehicles
Capture interior or exterior activity in patrol, service and utility vehicles, including at night.
§ 06Setup
Installation & setup
Choose the lens and spot
Pick the lens for the coverage you need and a mounting point that sees the cabin, doorway or blind spot clearly.
Mount and aim
Fix it with the universal adjustment mechanism and aim it, allowing for the vehicle's movement and vibration.
Wire to the MDVR
Run the aviation-plug lead to the mobile DVR, carrying video, audio, power and ground, and supply 9-16VDC.
Check and test
Confirm the framing and audio on the MDVR, then road-test to make sure the image stays steady under vibration.
§ 08Questions
Frequently asked about the AE-VC122T-ITS
Q.01
What resolution is the AE-VC122T-ITS?
It is a 720P HD-TVI mobile camera. Note the store title lists it as a 1080P AE-VC222T-ITS, but per Hikvision this SKU, AE-VC122T-ITS, is a 720P model - the specifications here follow the correct 720P camera.
Q.02
What recorder does it connect to?
It outputs HD-TVI video over coax through an aviation plug, so it is designed to connect to a mobile DVR (MDVR) in the vehicle. It does not use PoE and is not intended for a network NVR.
Q.03
Does it work in the dark?
Yes. It has a built-in infrared light for capturing black-and-white images in dark cabins and low-light conditions, suited to overnight fleet and cabin monitoring.
Q.04
Which lens option should I choose?
Choose 2.1mm for a very wide 117-degree view, 2.8mm for balanced coverage, or 3.6mm for a narrower, more detailed 75-degree view, depending on the space you are covering.
Q.05
Can it capture audio?
Yes. It has a built-in microphone that adds audio to recordings. It is a microphone only, so it does not provide two-way talk-back through a speaker.
Q.06
Is it built for vehicles with vibration?
Yes. It has a shock-proof conch design and an aviation-plug connector, and operates from -40 to 75 degrees, so it is made for buses, trucks, forklifts and other work vehicles.
Q.07
What power does it need?
A simple 9-16VDC supply at up to about 2.2W, taken from the vehicle's electrical system through the aviation connector.
Q.08
Where is it typically used?
Inside buses, trucks and vans to watch drivers, passengers and blind spots, and in forklifts, mining and agricultural machinery where a rugged, wide-angle camera is needed.
Buying from Smarket
Is your Hikvision, Dahua, HiLook and TP-Link VIGI stock genuine Australian stock?
Yes, 100%. Every Hikvision, Dahua, HiLook and TP-Link VIGI product we sell is a genuine Australian-market model sourced through Australian supply chains — never grey imports. That means factory-sealed units, Australian-region firmware that works with the official apps out of the box, and a full 3-year local warranty.
How long does delivery take?
Order before 2pm (Sydney time) on a business day and in-stock items are dispatched the same day. Most orders arrive within 1–4 business days Australia-wide; remote and regional areas can take a little longer. You'll receive a tracking number by email as soon as your order leaves the warehouse.
How much is shipping?
Standard shipping is free on all orders over $300 AUD, Australia-wide. Orders under $300 ship at a flat rate of $25, calculated at checkout. Tracking is included on every order.
What warranty do you offer?
All cameras, NVRs and DVRs come with a 3-year back-to-base manufacturer warranty covering defects in materials and workmanship, in addition to your rights under Australian Consumer Law. Hard drives and accessories are covered as set out in our Warranty Policy.
What is your return policy?
You have 30 days from the day you receive your order to request a change-of-mind return. Items must be unopened, factory-sealed and in resalable condition. A 15% restocking fee applies and return postage is at your cost. Faulty or incorrectly supplied items are different: we cover the return shipping and refund or replace at no charge. Read the full Return & Refund Policy.
Do you offer installation?
We can connect you with licensed installers in Sydney and Melbourne. Installation typically starts from around $200 per camera depending on cable runs and site conditions. Email sales@smarket.com.au with your address and camera count for a quote.
§ 10Bundles
Recommended packages
Needs a mobile DVR (MDVR)
This camera outputs HD-TVI over coax via an aviation plug, so it connects to a vehicle MDVR - choose an MDVR with matching HD-TVI inputs and aviation connectors for your fleet.
Add more vehicle cameras
Build out the vehicle with cameras such as the AE-VC224T-IT conch camera or AE-VC211T-IRS mobile camera for other angles.
Cover a wider cabin
The DS-2XM6726G1-ID mobile dome suits larger cabins and interiors.
Plan the wiring
Run the aviation lead to the MDVR for video, audio and power, and supply the camera with 9-16VDC.
