Hikvision 6 Cameras & 8 Channel CCTV Kit: 2 x 8MP ColorVu & 4 x 6MP AcuSense Turret Cameras + 8CH 8K NVR Bundle
Skip to product information
1
/
of
1
Vendor:
Hikvision
Hikvision 6 Cameras & 8 Channel CCTV Kit: 2 x 8MP ColorVu & 4 x 6MP AcuSense Turret Cameras + 8CH 8K NVR Bundle
SKU: DS-2CD2387G3-LIS2UY/SL
Description
This Hikvision 6-camera, 8-channel CCTV kit mixes two 8MP ColorVu turrets for full-colour night vision at the most important angles with four 6MP AcuSense turrets for sharp, AI-filtered coverage everywhere else, all recording to a DS-7608NI-M2/8P 8-channel PoE NVR with a 4TB hard drive already fitted. It is a complete, ready-to-install system for a typical home or small business.
Key points
- 2 × 8MP ColorVu turrets: 24/7 full-colour night vision, two-way audio, strobe deterrence
- 4 × 6MP AcuSense turrets: human/vehicle AI, 30 m IR, built-in mic
- DS-7608NI-M2/8P 8-channel 4K NVR with 8 built-in PoE ports
- 4TB surveillance hard drive included and fitted
- All cameras IP67 weatherproof; single-cable PoE per camera
- Two spare channels to expand later
Regular price
$2,373.65 AUD
Sale price
$2,373.65 AUD
Regular price
$3,178.00 AUD
Sale
25.31%
$804.35 AUD
(25.31%)
EOFY sale: extra 5% off orders over $800
Applied automatically in cart — ends 30 June.
Building a kit or need installation? Email sales@smarket.com.au for a quote.
inc GST + 3 Year Warranty & Support
Free shipping over AUD300
In stock
Hikvision 6 Cameras & 8 Channel CCTV Kit: 2 x 8MP ColorVu & 4 x 6MP AcuSense Turret Cameras + 8CH 8K NVR Bundle
1
/
of
1
Customize this kit Kit price $2,373.65
This kit includes:
- 6 × Hikvision DS-2CD2366G2-IU 6MP AcuSense Turret Camera 2.8mm, Built-in Mic, 30m IR
- 1 × Hikvision DS-7608NI-M2/8P 8ch M-Series PoE NVR, 128Mbps, 4K, 2 Bay, 1RU, 4TB (8ch)
- 1 × 4TB HDD – WD Purple / Seagate Surveillance HDD for DVRs & NVRs (4TB)
3-Year Warranty
Warranty on all cameras
Free Shipping
On orders over $300
30-Day Returns
Easy returns for unopened items
Fast Delivery
5-10 Day Delivery Australia-wide
§ 01Overview
What the DS-2CD2387G3-LIS2UY/SL is
This Hikvision mixed CCTV kit is built around a simple idea: put full-colour ColorVu cameras where colour matters most and cost-effective AcuSense cameras everywhere else.
You get two 8MP ColorVu turrets and four 6MP AcuSense turrets recording to an 8-channel Hikvision PoE NVR with a 4TB hard drive already installed, so the system arrives ready to mount and run.
The two 8MP ColorVu cameras use a large sensor and an F1.0 lens with Smart Hybrid Light to deliver vivid full-colour footage at night, and they add two-way audio and an active strobe-and-audio deterrent, so they are ideal at the front door, driveway or any angle where you want to see colour detail and warn intruders off.
The four 6MP AcuSense turrets cover the rest of the property with deep-learning human and vehicle detection, a built-in microphone and 30 m infrared night vision, keeping alerts focused on real activity rather than pets or weather.
The DS-7608NI-M2/8P NVR has eight built-in PoE ports, so each camera connects with a single network cable that carries both power and data, and it records up to 4K.
AcuSense runs end to end, so you can search recordings by people or vehicles to find an event quickly.
The kit uses six of the eight channels, leaving two spare to add cameras later.
Note that the ColorVu cameras give full colour at night via their warm white light, while the AcuSense turrets use infrared and so record in black and white after dark.
The 4TB hard drive is included with this kit; in everyday use it stores roughly a week or more of continuous footage from six cameras, depending on resolution, frame rate and activity.
§ 02Engineering
DS-2CD2387G3-LIS2UY/SL specifications
- 2 x 8MP ColorVu turrets (DS-2CD2387G3 type): 24/7 full-colour night vision, two-way audio, strobe and audio deterrence
- 4 x 6MP AcuSense turrets (DS-2CD2366G2-IU): human/vehicle classification, 30 m IR (black and white at night), built-in mic
- DS-7608NI-M2/8P 8-channel 4K NVR with 8 built-in PoE ports for single-cable camera connection
- 4TB surveillance-grade hard drive included and fitted
- AcuSense end to end for people and vehicle search across recordings
- All cameras IP67 weatherproof for Australian outdoor conditions
- Two spare NVR channels to expand the system later
- 4 x 6MP AcuSense turrets (DS-2CD2366G2-IU): human/vehicle classification, 30 m IR (black and white at night), built-in mic
- DS-7608NI-M2/8P 8-channel 4K NVR with 8 built-in PoE ports for single-cable camera connection
- 4TB surveillance-grade hard drive included and fitted
- AcuSense end to end for people and vehicle search across recordings
- All cameras IP67 weatherproof for Australian outdoor conditions
- Two spare NVR channels to expand the system later
§ 03Full datasheet
Detailed specifications
Camera & Image
| Feature | Detail |
|---|---|
| Image Sensor | 1/1.8" Progressive Scan CMOS |
| Max. Resolution | 3840 × 2160 |
| Min. Illumination | Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light |
| Shutter Time | 1 s to 1/100,000 s |
| Day & Night | IR cut filter |
| Day/Night Switch | Day, Night, Auto, Schedule |
| Image Enhancement | BLC, HLC, 3D DNR, Distortion Correction, Defog |
| SNR | ≥ 52 dB |
| Wide Dynamic Range (WDR) | 130 dB |
| Image Stabilization | EIS |
| Privacy Mask | 4 programmable polygon privacy masks |
| Image Parameters Switch | Yes |
| Image Settings | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser |
Lens & Distance
| Feature | Detail |
|---|---|
| Lens Type | Fixed focal lens, 2.8 and 4 mm optional |
| Focal Length & FOV | 2.8 mm, horizontal FOV 108.8°, vertical FOV 56.4°, diagonal FOV 134.3° | 4 mm, horizontal FOV 93.3°, vertical FOV 47.2°, diagonal FOV 114.2° |
| Lens Mount | M16 |
| Iris Type | Fixed |
| Aperture | F1.0 |
| Depth of Field | 2.8 mm: 3.3 m to ∞ | 4 mm: 3.8 m to ∞ |
| DORI | 2.8 mm: D: 89 m, O: 35 m, R: 17 m, I: 8 m | 4 mm: D: 109 m, O: 43 m, R: 21 m, I: 10 m |
| Pan Range | 0° to 360° |
| Tilt Range | 0° to 75° |
| Rotation Range | 0° to 360° |
Night Vision
| Feature | Detail |
|---|---|
| Supplement Light Type | White Light, IR |
| Supplement Light Range | Up to 30 m |
| Smart Supplement Light | Yes |
| IR Wavelength | 850 nm |
Video
| Feature | Detail |
|---|---|
| Main Stream | 50 Hz: 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) | 60 Hz: 30 fps (3840 × 2160，3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) |
| Sub-Stream | 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) | 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) |
| Third Stream | 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) | 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360); *Third stream is supported under certain settings. |
| Video Compression | Main stream: H.265/H.264/H.264+/H.265+, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264, *Third stream is supported under certain settings. |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| H.264 Type | Baseline Profile, Main Profile, High Profile |
| H.265 Type | Main Profile |
| Bit Rate Control | CBR, VBR |
| Scalable Video Coding (SVC) | H.264 and H.265 encoding |
| Region of Interest (ROI) | 1 fixed region for main stream |
Audio
| Feature | Detail |
|---|---|
| Audio Type | Mono sound |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
| Audio Bit Rate | 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) |
| Audio Sampling Rate | 8 kHz/16 kHz/32 kHz/48 kHz |
| Environment Noise Filtering | Yes |
| Built-in Microphone | -2U: Arrayed dual-microphone |
| Built-in Speaker | Max. power consumption: 2 W, max. sound pressure level: 10 cm: 110 dB. |
AI & Deep Learning
| Feature | Detail |
|---|---|
| Face Capture | Yes |
| Perimeter Protection | Line crossing, intrusion, region entrance, region exiting. Support alarm triggering by specified target types (human and vehicle) |
Network & Storage
| Feature | Detail |
|---|---|
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP |
| Simultaneous Live View | Up to 6 channels |
| API | ONVIF (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP |
| User/Host | Up to 32 users. 3 user levels: administrator, operator, and user |
| Security | Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address) |
| Network Storage | NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR) |
| Client | iVMS-4200, Hik-Connect, Hik-Central |
| Web Browser | Plug-in free live view: Chrome 80+, Firefox 80+, Edge 89+, Local service: Chrome 80+, Firefox 80+, Edge 89+ |
Event & Alarm
| Feature | Detail |
|---|---|
| Basic Event | Motion detection (support alarm triggering by specified target types (human and vehicle)), video tampering alarm, exception |
| Smart Event | Scene change detection |
| Linkage | Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture, audible warning, strobe light flashing |
Interface
| Feature | Detail |
|---|---|
| Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
| On-Board Storage | Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB |
| Audio Input | 1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium |
| Audio Output | 1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium |
| Alarm Input | 1 input |
| Alarm Output | 1 output (max. 24 VDC/24 VAC, 1 A) |
| Reset Key | Yes |
General & Environment
| Feature | Detail |
|---|---|
| Power | 12 VDC ± 25%, 1.29 A, max. 15.5 W, Ø 5.5 mm coaxial power plug, reverse polarity protection, PoE: IEEE 802.3at, Class 4, max. 17 W |
| Material | Cover: metal, main body: metal |
| Dimension | Ø 138.3 mm × 115.4 mm (Ø 5.4" × 4.5") |
| Package Dimension | 170 mm × 170 mm × 160 mm (6.7" × 6.7" × 6.3") |
| Weight | Approx. 820 g (1.8 lb.) |
| With Package Weight | Approx. 1200 g (2.6 lb.) |
| Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Startup and Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| General Function | Heartbeat, mirror, flash log, password reset via email, pixel counter, anti-banding |
| Language | 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| EMC | CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7, KC: KN32: 2015, KN35: 2015 |
| Safety | UL: UL 62368-1, CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017 |
| Environment | CE-RoHS: 2011/65/EU |
| Protection | IP67: IEC 60529-2013 |
| Anti-Corrosion Protection | NEMA 4X (NEMA 250-2018) |
§ 04Why choose this
Built for the way you actually use the DS-2CD2387G3-LIS2UY/SL
Ready to record out of the box
A 4TB hard drive is included and fitted in the 8-channel PoE NVR, so the kit arrives complete; just mount the cameras, run the cables and power up.
AI that cuts false alarms
AcuSense runs end to end, classifying people and vehicles so alerts and recordings follow real activity, and letting you search footage by target to find events fast.
Simple PoE install with room to grow
Each camera runs on a single network cable from the NVR's built-in PoE ports, and two spare channels let you add cameras later.
§ 05Where it fits
Right at home in these scenarios
Front door and entryway
Place an 8MP ColorVu camera here to greet visitors with two-way audio, deter intruders with strobe and sound, and keep colour footage at night.
Driveway and garage forecourt
Use the high-resolution ColorVu cameras to capture vehicle detail and number plates in colour around the clock.
Sides, rear and yard
Cover the rest of the property with the four 6MP AcuSense turrets, using human and vehicle detection to keep alerts meaningful.
Home or small business
Six cameras and an 8-channel NVR suit a typical house, shop or office, with two spare channels to expand as needed.
§ 06Setup
Installation & setup
What's in the box
Two 8MP ColorVu turret cameras, four 6MP AcuSense turret cameras, a DS-7608NI-M2/8P 8-channel PoE NVR with a 4TB hard drive fitted, camera mounting hardware and quick start guides. Network cable is run to suit your site and is not pre-cut to length.
Installation requirements
Mount each camera to a wall or eave, ideally 2.5 to 3 m high, angled down over the area to watch, and run a single Cat5e or Cat6 cable from each camera back to a PoE port on the NVR. The NVR needs a mains power outlet and a connection to your router for remote viewing. Power up, add the cameras (they connect plug-and-play on the NVR's PoE ports), set detection zones and the ColorVu light and deterrence options, then set up the Hik-Connect app for phone access.
§ 07Questions
Frequently asked about the DS-2CD2387G3-LIS2UY/SL
Q.01
What is the difference between the ColorVu and AcuSense cameras in this kit?
The two 8MP ColorVu turrets keep the night image in full colour using a warm white light and a large F1.0 lens, and they add two-way audio and a strobe-and-audio deterrent, so they suit the front door and driveway where colour detail and deterrence matter. The four 6MP AcuSense turrets use infrared night vision, so they record in black and white after dark, and focus on deep-learning human and vehicle detection. Both types cut false alarms with AI; the ColorVu cameras simply add colour night vision, audio and active deterrence at the key angles.
Q.02
Is a hard drive included?
Yes. This kit ships with a 4TB surveillance-grade hard drive already fitted in the DS-7608NI-M2/8P NVR, so it is ready to record out of the box. In typical use 4TB stores roughly a week or more of continuous footage from all six cameras, depending on the resolution, frame rate and how busy the scenes are. You can fit a larger drive if you need longer retention.
Q.03
Do the cameras record in colour at night?
The two 8MP ColorVu cameras do; they use a warm white light to capture full-colour footage at night. The four 6MP AcuSense turrets use infrared, so their night image is black and white. A common setup is to place the ColorVu cameras at the front door and driveway for colour and deterrence, and use the AcuSense turrets for the sides, rear and yard.
Q.04
How are the cameras powered and wired?
Each camera connects to the NVR with a single Cat5e or Cat6 network cable that carries both power and data, using the NVR's eight built-in PoE ports. There is no separate power supply at each camera, which keeps the install tidy. You only need mains power at the NVR itself.
Q.05
Can I add more cameras later?
Yes. The kit uses six of the NVR's eight channels and PoE ports, so you can add up to two more Hikvision PoE cameras directly to the recorder later. If you outgrow eight channels, you would step up to a 16-channel NVR such as the DS-7616NI-M2/16P.
Q.06
Does it have two-way audio across all cameras?
Two-way audio is on the two 8MP ColorVu cameras, which have both a microphone and a speaker, so you can listen and talk back through those positions. The four 6MP AcuSense turrets have a built-in microphone that records audio but no speaker, so they capture sound without talk-back.
Q.07
Can I view it on my phone and is it AcuSense throughout?
Yes. The system connects to the Hik-Connect app for live view, playback and alerts on your phone or tablet. AcuSense runs across the cameras and the NVR, so you can filter recordings by people or vehicles to find an event quickly rather than scrubbing through every motion clip.
Q.08
Is it suitable for Australian outdoor conditions?
Yes. All six cameras carry an IP67 rating against dust and rain and are built for outdoor mounting. Positioning them under eaves where possible helps reduce direct sun and glare and keeps rain off the lenses for the clearest footage.
§ 08In motion
Hikvision AcuSense – Intelligent Footage Retrieval
Hikvision Explains - Acusense NVR & Normal camera combination
Hikvision AcuSense——Powerful False Alarm Reduction
§ 09Bundles
Recommended packages
Add mounting accessories
For tidy, sealed cable joins behind the turrets, add Hikvision junction boxes and brackets such as the DS-1273ZJ-140 G-series turret bracket; the kit already lists compatible accessories.
Expand beyond 8 channels
Outgrowing eight cameras? Step up the recorder to the DS-7616NI-M2/16P 16-channel NVR, or run the kit alongside a second system.
Compare standalone recorders
Prefer to build your own system? See Hikvision standalone NVRs such as the DS-7608NI-M2/8P and the DS-7608NI-I2/8P.
