Hikvision AX PRO Series DS-PDC15-EG2-WB Wireless Curtain PIR Detector
1 1
Hikvision

Hikvision AX PRO Series DS-PDC15-EG2-WB Wireless Curtain PIR Detector

SKU: DS-PDC15-EG2-WB
Description

The Hikvision DS-PDC15-EG2-WB is a wireless curtain PIR detector for AX PRO alarm systems. Its narrow 6.3 degree beam forms a thin vertical curtain of detection reaching up to 15m, ideal for guarding a window line, a doorway or a hallway without covering the whole room - so you can arm the perimeter while people move freely behind it.

At a glance
- Curtain-style PIR, narrow 6.3 degree beam up to 15m, 18 detection zones
- Digital temperature compensation, white-light filter and creep-zone protection for stable detection
- Tri-X two-way wireless on 433MHz, up to 1.2km open-air, AES-128 with frequency hopping
- One CR123A battery, up to 5 years; front and rear tamper
- Indoor wall mount (height 2.4-3.6m); app set-up; no pet immunity on this model
$66.85 AUD $66.85 AUD $79.00 AUD
Sale 15.38% $12.15 AUD (15.38%)
Business or bulk buyer? Apply for trade pricing →
Found a lower price? We’ll match it →

inc GST + 3 Year Warranty & Support
Free shipping over AUD300

In stock
3-Year WarrantyOn all cameras
Free ShippingOn orders over $300
30-Day ReturnsUnopened items
Fast Delivery1–5 days Australia-wide
Build your setup Build a complete CCTV system

A camera needs an NVR, a hard drive, and cabling to work. Add everything below, or pick a ready-made kit.

Add accessories Optional. Junction box → hides & weatherproofs cable joins (best for outdoors). Brackets → only if mounting on a corner or under eaves. Cable → one per camera; skip if you already have your own.
0
0
0
0
0
Bundle total: $66.85

§ 01Overview

What the DS-PDC15-EG2-WB is

The Hikvision DS-PDC15-EG2-WB is a wireless curtain PIR detector for AX PRO alarm systems. Where a standard PIR floods a whole room, a curtain detector throws a thin, tall sheet of detection along a line - across a window, a glass door, a hallway or a set of curtains - so it catches movement at that line while leaving the rest of the space clear.

It reaches up to 15m over a narrow 6.3 degree angle across 18 detection zones, with a detectable speed of 0.3 to 2m/s. Digital signal processing, digital temperature compensation, a 6500lux white-light filter, sealed optics and creep-zone protection keep detection steady and reduce false alarms. Set-up and sensitivity are handled remotely in the Hik-Connect app, and the battery is easy to replace with PCB protection.

It links to the hub over Tri-X two-way wireless on 433MHz, rated up to 1.2km in open space, with AES-128 encryption and frequency hopping for a secure, jam-resistant connection. A single CR123A battery gives up to five years of life, and front and rear tamper switches report interference. It mounts indoors on a wall at 2.4 to 3.6m. Please note this curtain model has no pet immunity, so for rooms where pets roam freely choose a pet-tolerant PIR instead. It pairs with a Hikvision AX PRO wireless hub and is not compatible with the older Axiom system.

§ 02Engineering

DS-PDC15-EG2-WB specifications

- Narrow 6.3 degree curtain beam reaches up to 15m across 18 detection zones to guard a window line, doorway or hallway.

- Digital signal processing with temperature compensation, a 6500lux white-light filter and creep-zone protection for steady, low-false-alarm detection.

- Tri-X two-way wireless on 433MHz, rated up to 1.2km in open space, with AES-128 encryption and frequency hopping against jamming.

- Single CR123A battery gives up to five years of life, with an easy, PCB-protected battery replacement.

- Front and rear tamper protection report if the detector is opened or removed; signal-strength and temperature indicators aid set-up.

- Indoor wall mount at 2.4-3.6m with full remote configuration in the Hik-Connect app; note this model has no pet immunity.

§ 03Full datasheet

Detailed specifications

Network & Storage

Network & Storage — Hikvision AX PRO Series DS-PDC15-EG2-WB Wireless Curtain PIR Detector
FeatureDetail
Transmission Technology Tri-X Wireless
Transmission Method Two-Way RF Wireless
Transmission Frequency 433MHz
Transmission Security AES-128 Encryption
Transmission Range(Free Space) 1.2Km
Frequency Hopping Support
Enrolling Method Power up,Remote ID,QR Code

§ 04Why choose this

Built for the way you actually use the DS-PDC15-EG2-WB

Protect a line, not a room

A narrow 6.3 degree curtain guards a window, door or hallway while leaving the rest of the space clear for movement.

Steady, low false alarms

Digital processing, temperature compensation and a white-light filter keep detection reliable indoors.

Long, secure wireless reach

Tri-X two-way wireless to 1.2km with AES-128 and frequency hopping resists interference around larger homes and sites.

Five-year battery, easy swap

One CR123A lasts up to five years, with a PCB-protected, easy-to-replace battery.

§ 05Where it fits

Right at home in these scenarios

Windows and glass doors

Run a curtain across a window line or sliding door so a forced entry is caught at the glass.

Hallways and corridors

Cover a narrow passage where a wide PIR would over-trigger, catching anyone who walks through.

Display and showroom lines

Guard a run of windows or a display frontage without alarming on movement deeper inside.

Perimeter-first protection

Combine with room detectors so the alarm catches both the entry line and any movement that follows.

§ 06Setup

Installation & setup

01

Choose the line to protect

Pick the window, door or hallway to cover and plan the wall position so the narrow curtain runs along it.

02

Mount at the right height

Fix it to the wall at 2.4 to 3.6m, away from heaters, vents and direct sun that could skew detection.

03

Pair to the hub

Power it up and enrol it to the AX PRO hub by power-up, remote ID or QR code in the Hik-Connect app.

04

Set sensitivity and test

Adjust sensitivity in the app, then walk-test the curtain line and check signal strength before arming.

§ 07Questions

Frequently asked about the DS-PDC15-EG2-WB

Q.01

What is a curtain PIR detector for?
It creates a thin vertical curtain of detection along a line - such as a window, glass door or hallway - rather than covering a whole room, so it catches anyone crossing that line while people behind it can move freely.
Q.02

Does the DS-PDC15-EG2-WB have pet immunity?
No, this curtain model has no pet immunity. In rooms where pets roam, choose a pet-tolerant PIR such as a pet-friendly AX PRO detector instead, or aim the curtain where pets cannot cross it.
Q.03

How far does the curtain reach?
Up to 15m over a narrow 6.3-degree beam across 18 detection zones, which suits long windows, doorways and corridors.
Q.04

Which alarm system does it work with?
It is a wireless AX PRO device and pairs with a Hikvision AX PRO hub such as the DS-PWA96-M-WB. It is not compatible with the older Axiom system.
Q.05

Can it be used outdoors?
No, it is rated for indoor use only. For outdoor perimeters use a weatherproof AX PRO outdoor curtain detector instead.
Q.06

How far can it be from the hub?
Up to 1.2km in open space over Tri-X two-way wireless on 433MHz. Walls and obstructions reduce that, so check signal strength where it will be installed.
Q.07

What battery does it use and how long does it last?
A single CR123A lithium battery, giving up to five years of standby life, with a low-battery warning sent to the hub and easy PCB-protected replacement.
Q.08

Where should I mount it?
Indoors on a wall at a height of 2.4 to 3.6m, aimed so the narrow curtain runs along the window, door or hallway you want to protect.
