Dahua DHI-NVR5864-AI/ANZ 64CH 2U 4K & H.265 Wizsense Network Video Recorder NVR
SKU: DHI-NVR5864-AI/ANZ
Description
The Dahua DHI-NVR5864-AI/ANZ is a 64-channel 2U WizSense AI network video recorder for large commercial, industrial and public-safety sites. It has eight HDD bays with RAID 0/1/5/6/10, up to 384 Mbps of bandwidth, support for cameras up to 32MP, and on-board AI including face detection and recognition, perimeter protection and SMD Plus. Hard drives are supplied separately.
Key points
- 64 IP channels; 2U enterprise chassis
- 8 SATA HDD bays with RAID 0/1/5/6/10 redundancy
- 384 Mbps bandwidth (AI off) / 200 Mbps (AI on); cameras up to 32MP
- AI by recorder: face detection & recognition, perimeter protection, SMD Plus
- AcuPick / Quick Pick smart search with compatible WizSense cameras
- Dual HDMI + dual VGA, 4K display; no built-in PoE; HDD not included
Regular price
$1,368.00 AUD
Sale price
$1,368.00 AUD
Regular price
$1,469.45 AUD
Sale
6.9%
$101.45 AUD
(6.9%)
Member Price$1,326.96 AUD
Sign into save $41.04 AUD · Free to join
Business or bulk buyer? Apply for trade pricing →
inc GST + 3 Year Warranty & Support
Free shipping over AUD300
In stock
No reviews
Dahua DHI-NVR5864-AI/ANZ 64CH 2U 4K & H.265 Wizsense Network Video Recorder NVR
1
/
of
1
Build your setup Build a complete CCTV system Complete setup from $1,738.00
A camera needs an NVR, a hard drive, and cabling to work. Add everything below, or pick a ready-made kit.
3-Year Warranty
Warranty on all cameras
Free Shipping
On orders over $300
30-Day Returns
Easy returns for unopened items
Fast Delivery
5-10 Day Delivery Australia-wide
§ 01Overview
What the DHI-NVR5864-AI/ANZ is
The Dahua DHI-NVR5864-AI/ANZ is an enterprise-class 64-channel WizSense AI recorder in a 2U chassis, built for large Australian commercial, industrial and public-safety installations.
It accepts up to 64 IP cameras (over the network, not built-in PoE) at resolutions up to 32MP, with up to 384 Mbps of bandwidth when AI is off and 200 Mbps with AI features running.
Eight SATA HDD bays with RAID 0/1/5/6/10 give you both high capacity and the redundancy a critical site needs, so a single drive failure does not cost you footage.
The recorder runs Dahua's WizSense AI on board: face detection and recognition, perimeter protection (tripwire and intrusion) and SMD Plus to separate people and vehicles from irrelevant motion, plus AcuPick / Quick Pick smart search that lets an operator find a person or vehicle across recordings quickly when used with compatible WizSense cameras.
It carries ANZ firmware for local compliance, outputs to dual HDMI and dual VGA for a multi-screen control room, and supports third-party cameras over ONVIF.
Note that this is an enterprise recorder supplied without hard drives and without built-in PoE — cameras connect through your network switches, and you add surveillance drives to suit your retention and RAID plan.
It is genuine Australian Dahua stock with local warranty and support.
§ 02Engineering
DHI-NVR5864-AI/ANZ specifications
- 64-channel 2U WizSense AI NVR for large enterprise installations
- 8 SATA HDD bays with RAID 0/1/5/6/10 for capacity and redundancy
- Up to 384 Mbps bandwidth (200 Mbps with AI enabled); cameras up to 32MP
- AI by recorder: face detection and recognition, perimeter protection, SMD Plus
- AcuPick / Quick Pick smart search with compatible WizSense cameras
- Dual HDMI and dual VGA outputs with 4K display for control rooms
- ANZ firmware; third-party camera support over ONVIF
- No built-in PoE and no HDD included — add switches and drives to suit
- 8 SATA HDD bays with RAID 0/1/5/6/10 for capacity and redundancy
- Up to 384 Mbps bandwidth (200 Mbps with AI enabled); cameras up to 32MP
- AI by recorder: face detection and recognition, perimeter protection, SMD Plus
- AcuPick / Quick Pick smart search with compatible WizSense cameras
- Dual HDMI and dual VGA outputs with 4K display for control rooms
- ANZ firmware; third-party camera support over ONVIF
- No built-in PoE and no HDD included — add switches and drives to suit
§ 03Full datasheet
Detailed specifications
Video
| Feature | Detail |
|---|---|
| Access Channel | 64 |
| Network Bandwidth | AI disabled: 384 Mbps incoming, 384 Mbps recording and 384 Mbps outgoing | AI enabled: 200 Mbps incoming, 200 Mbps recording and 200 Mbps outgoing |
| Resolution | 32 MP; 24 MP; 16 MP; 12 MP; 8 MP; 5 MP; 4 MP; 1080p; 720p; D1; CIF; QCIF |
| Decoding Capability | AI disabled: 2-channel 32 MP@20 fps; 2-channel 24 MP@20 fps; 4-channel 16 MP@30 fps; 5-channel 12 MP@30 fps; 8-channel 8 MP@30 fps; 12-channel 5 MP@30 fps; 16-channel 4 MP@30 fps; 32-channel 1080p@30 fps | AI enabled: 1-channel 32 MP@20 fps; 1-channel 24 MP@20 fps; 2-channel 16 MP@30 fps; 4-channel 12 MP@30 fps; 4-channel 8 MP@30 fps; 8-channel 5 MP@30 fps; 12-channel 4 MP@30 fps; 24-channel 1080p@30 fps |
| Video Output | 2-channel VGA, 2-channel HDMI video output. | Heterogeneous video source output for HDMI1 and HDMI2 | Simultaneous video source output for VGA1 and HDMI1 | Simultaneous video source output for VGA2 and HDMI2 | Supports 4K display |
| Multi-screen Display | Main screen: 1/4/8/9/16/25/36/64 | Sub screen: 1/4/8/9/16 |
| Third-party Camera Access | ONVIF; Panasonic; Sony; Axis; Arecont; Pelco; Canon; Samsung |
| Video Compression | Smart H.265+; H.265; Smart H.264+; H.264; MJPEG |
| Multi-channel Playback | Up to 16 channels |
| Record Mode | General, motion detection; intelligent; alarm; POS |
| Backup Method | USB device and network |
| Playback Mode | Instant playback, general playback, event playback, tag playback, smart playback (face and motion detection) |
Audio
| Feature | Detail |
|---|---|
| Audio Compression | G.711a; G.711u; PCM; G726 |
AI & Deep Learning
| Feature | Detail |
|---|---|
| AI by Recorder | Face detection; face recognition; perimeter protection; SMD Plus |
| AI by Camera | Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); perimeter protection; SMD Plus; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; heat map |
| Perimeter Performance AI by Recorder (Number of Channels) | 4 channels, 10 IVS rules for each channel |
| Perimeter Performance of AI by Camera (Number of Channels) | 16 channels |
| Face Attributes | Gender; age group; glasses; expressions; face mask; beard |
| Face Detection Performance of AI by Recorder (Number of Channels) | 2 channels (up to 12 face images/s each channel) |
| Face Detection Performance of AI by Camera (Number of Channels) | 16 channels |
| Face Database Capacity | Up to 20 face databases with 20,000 images, with a total capacity of 2.5 G. Name, gender, birthday, address, credential type, credential No., countries & regions and state can be added to each face image. |
| Face Recognition Performance of AI by Recorder (Number of Channels) | 1. 16-channel FD (by camera) + FR (by recorder), image stream: 16 face images/s | 2. 2-channe FD (by recorder) + FR (by recorder), video stream: 12 face images/s |
| Face Recognition Performance of AI by Camera (Number of Channels) | 16 channels |
| SMD Plus by Recorder | 8 channels: Secondary filtering for human and motor vehicle , reducing false alarms caused by leaves, rain and lighting condition change |
| SMD Plus by Camera | 16 channels |
| Metadata Performance of AI by Camera (Number of Channels) | 8 channels |
| Human Attributes | Top color, top type, bottom color, bottom type, hat, bag, age, gender and umbrella |
| Motor Vehicle Attributes | License plate, plate color, vehicle body, vehicle model, vehicle logo, calling, seatbelt, vehicle interior, vehicle registration location. |
| Non-motor Vehicle Attributes | Vehicle model, vehicle color, number of persons, helmet. |
| ANPR by Camera (Number of Channels) | 8 channels |
| License Plate Database Capacity | 1. Create up to 20,000 plate numbers. | 2. Blocklist and allowlist |
Network & Storage
| Feature | Detail |
|---|---|
| Main Processor | Industrial-grade processor |
| Operating System | Embedded Linux |
| Operating Interface | Web, Local GUI |
| Network Protocol | HTTP; HTTPS; TCP/IP; IPv4/IPv6; RTSP; UDP; SNMP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; PPPoE; FTP; DDNS; Alarm Server; IP Search (Supports Dahua IP camera, DVR, NVS, etc.); Multicast; P2P; Auto Registration |
| Mobile Phone Access | iOS; Android |
| Interoperability | ONVIF 21.12(Profile T; Profile S; Profile G); CGI; SDK |
| Browser | Chrome | IE 9 or later | Firefox |
| Network Mode | Multi-address mode, load balance, fault tolerance and other network port binding modes |
| HDD Interface | 8 SATA ports, up to 16 TB.The maximum HDD capacity varies with environment temperature. |
| Disk Group | Yes |
| RAID | RAID 0/1/5/6/10 |
Event & Alarm
| Feature | Detail |
|---|---|
| General Alarm | Motion detection; privacy masking; local alarm |
| Anomaly Alarm | Camera offline; storage error; disk full; IP conflict; MAC conflict; login lock; abnormal behavior of fan; cybersecurity exception |
| Intelligent Alarm | Face detection; perimeter protection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); SMD Plus; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; heat map |
| Alarm Linkage | Record; snapshot (panoramic); local alarm output; IPC external alarm output; access controller; audio; buzzer; log, preset; email |
Interface
| Feature | Detail |
|---|---|
| Audio Input | 1-channel RCA |
| Audio Output | 2-channel RCA |
| Alarm Input | 16 channels |
| Alarm Output | 8 channels (1-channel 12 V 1 A output) |
| eSATA | 1 |
| RS-232 | 1 |
| RS-485 | 2 (1 port for half-duplex serial communication, 1 port for full-duplex serial communication) |
| USB | 4 (2 front USB 2.0 ports, 2 rear USB 3.0 ports) |
| HDMI | 2 |
| VGA | 2 |
| Network Port | 2(10/100/1000 Mbps Ethernet port, RJ-45) |
General & Environment
| Feature | Detail |
|---|---|
| Power Supply | 100–240 VAC, 50-60 Hz |
| Power Consumption | Total output of NVR is ≤ 13 W (without HDD) |
| Net Weight | 6.4 kg (14.11 lb) |
| Gross Weight | 9.01 kg (19.86 lb) |
| Product Dimensions | 439.9 mm × 457.9 mm x 89.0 mm (17.32" × 18.03" × 3.50") (W ×D × H) |
| Packaging Dimensions | 570.0 mm × 570.0 mm x 226.0 mm (22.44" × 22.44" × 8.90") (W ×D × H) |
| Operating Temperature | –10 °C to +55 °C (14 °F to +131 °F) |
| Storage Temperature | –20 °C to +60 °C (–4 °F to +140 °F) |
| Operating Humidity | 10%–93% (RH) |
| Installation | Rack or desktop |
| Certifications | FCC: 47 CFR FCC Part15, SubpartB, Class A | CE-EMC: EN 55032: 2015+A1: 2020; EN IEC 61000-3-2: 2019+A1: 2021; EN 61000-3-3: 2013+A1: 2019+A2: 2021; EN 55035: 2017+A11: 2020; EN 50130-4: 2011+A1: 2014 | CE-LVD: EN 62368-1: 2014 |
§ 04Why choose this
Built for the way you actually use the DHI-NVR5864-AI/ANZ
Serious channel count and bandwidth
64 channels and up to 384 Mbps handle a large camera estate, with support for high-resolution cameras up to 32MP.
AI that speeds investigations
Face recognition, perimeter protection, SMD Plus and AcuPick smart search help operators find events and targets fast instead of scrubbing hours of video.
Built for control rooms
Dual HDMI and dual VGA with 4K display and ANZ firmware suit a manned monitoring position on a commercial or public-safety site.
§ 05Where it fits
Right at home in these scenarios
Large commercial and industrial sites
Centralise dozens of cameras across a factory, warehouse or campus on one redundant recorder.
Public safety and government
Run face and perimeter analytics with RAID-protected storage for sites that need reliable retention and fast search.
Multi-building campuses
Aggregate cameras from many switches and buildings into a single 64-channel control-room recorder.
High-retention installations
Fill eight bays with high-capacity drives for long retention under a RAID 5 or 6 plan.
§ 06Setup
Installation & setup
What's in the box
One DHI-NVR5864-AI/ANZ 2U recorder, power lead and mouse. Hard drives, network switches, cameras and monitors are not included.
Installation requirements
Rack the 2U chassis, fit surveillance-grade SATA drives and configure your RAID level, then connect cameras through managed PoE switches on the network (the recorder has no built-in PoE). Connect monitors over HDMI/VGA and the network for remote access, and plan camera bitrates against the AI-on bandwidth limit. A UPS is strongly recommended on an enterprise recorder. Professional installation and commissioning are recommended.
§ 07Questions
Frequently asked about the DHI-NVR5864-AI/ANZ
Q.01
Does this NVR come with hard drives?
No. It is an enterprise recorder supplied without drives so you can plan capacity and RAID to suit the site. It has eight SATA bays, each taking a high-capacity surveillance drive, for very large total storage.
Q.02
Does it have built-in PoE ports?
No. Unlike smaller all-in-one NVRs, the NVR5864 has no built-in PoE. Cameras connect through your own network switches, which is normal for a 64-channel enterprise system where cameras are spread across a managed network.
Q.03
What RAID levels does it support?
It supports RAID 0, 1, 5, 6 and 10 across its eight bays, so you can balance capacity, performance and redundancy. RAID 5 or 6 is common on critical sites so that footage survives a drive failure.
Q.04
How many cameras and what resolution can it handle?
It records up to 64 IP channels at resolutions up to 32MP, with up to 384 Mbps of bandwidth when AI is off. Enabling AI features reduces usable bandwidth to around 200 Mbps, so plan camera count and bitrates against the mode you will run.
Q.05
What AI features does the recorder provide?
On board it offers face detection and recognition, perimeter protection (tripwire and intrusion) and SMD Plus to filter people and vehicles from other motion. With compatible WizSense cameras it adds AcuPick / Quick Pick smart search, plus camera-side analytics such as ANPR, people counting and metadata.
Q.06
What is AcuPick and do I need special cameras?
AcuPick (and the related Quick Pick) is a fast smart-search tool that lets an operator pick a target and find matching people or vehicles across recorded footage in seconds. It works with compatible Dahua WizSense cameras, so check your cameras support it to use that feature.
Q.07
How many monitors can it drive?
It has dual HDMI and dual VGA outputs with 4K display support, so you can run a multi-screen layout in a control room rather than a single monitor.
Q.08
Is this the Australian model?
Yes. The /ANZ suffix indicates Australia/New Zealand firmware, and it is supplied as genuine Australian Dahua stock with local warranty and support.
