Hikvision DS-2CD2386G2 8MP Active Deter Camera

Name: Hikvision Acusense DS-2CD2386G2-ISU/SL IP Camera 8MP 4K With Sound & Strobe Turret Camera
Brand: Hikvision
Price: 281.3 AUD
Availability: InStock

Build your setup Build a complete CCTV system Complete setup from $1,325.45 or kits from $2,766.45

A camera needs an NVR, a hard drive, and cabling to work. Add everything below, or pick a ready-made kit.

Select NVR (recorder) · channels ≥ your camera count

None

Hikvision DS-7604NI-M1/4P 4ch M-Series PoE NVR, 40Mbps, H.265, 4 PnP Ports, 1 HDD Bay, 4TB ~~$748.00~~$674.15

Hikvision DS-7608NI-M2/8P 8ch M-Series PoE NVR, 128Mbps, 4K, 2 Bay, 1RU, 4TB ~~$1,055.00~~$966.10

Hikvision DS-7608NI-M2/8P 8ch M-Series PoE NVR, 128Mbps, 4K, 2 Bay, 1RU, 6TB $1,140.70

Hikvision DS-7616NI-M2/16P 16ch M-Series PoE NVR, 256Mbps, H.265, 16 PnP Ports, 2 HDD Bay, 4TB ~~$1,314.00~~$1,164.00

Select hard drive · 4TB ≈ 2-3 weeks for 4 cameras recording 24/7

None

4TB HDD – WD Purple / Seagate Surveillance HDD for DVRs & NVRs

4TB $370.00

6TB HDD – WD Purple / Seagate Surveillance HDD for DVRs & NVRs

6TB $550.00

8TB HDD – Purple / Skyhawk Surveillance Hard Drive for DVRs & NVR

8TB $780.00

10TB HDD – Purple Surveillance Hard Drive for DVRs & NVR

10TB $1,020.00

Add accessories Optional. Junction box → hides & weatherproofs cable joins (best for outdoors). Brackets → only if mounting on a corner or under eaves. Cable → one per camera; skip if you already have your own.

Hikvision DS-1280ZJ-DM21 Junction Box ~~$20.00~~$19.40

0

Hikvision DS-1273ZJ-140B Bracket to suit G Series Turret cameras $67.00

0

Cable · 10m $13.00

0

Cable · 20m $28.00

0

Cable · 30m $40.00

0

Cable · 50m $65.00

0

Or pick a ready-made kit

Pre-built kits

None

Hikvision 8MP 8CH CCTV Kit:6xAcusenseOutdoor Turret With Strobe & Siren + 8CH NVR/4TB ~~$3,506.00~~$2,766.45

Hikvision 8MP 16CH CCTV Kit: 8 x AcusenseOutdoor Turret With Strobe & Siren + 16CH NVR/4TB ~~$4,458.00~~$3,361.90

§ 01Overview

What the DS-2CD2386G2-ISU/SL is

Lens options: 2.8mm or 4mm focal length.
Color options: White or Black.
Note: Please indicate your choice in your order message.

The Hikvision HIK-2CD2386G2SL2 is an 8MP outdoor turret camera providing high-definition security surveillance for Australian properties.
Featuring advanced AcuSense with deep learning algorithms, this network camera effectively reduces false alarms through precise human and vehicle detection.

See it in action

What the DS-2CD2386G2-ISU/SL features actually look like

Representative illustrations of how each key feature performs in a real scene.

8MP Ultra HD — 8MP (4K) resolution captures four times the detail of 1080p. Even when a person or car is fa... (1/2) — 8MP Ultra HD
8MP (4K) resolution captures four times the detail of 1080p.
Even when a person or car is far down the driveway, you can zoom in and still recognise a face or read a number plate — detail that lower-resolution cameras lose.

8MP Ultra HD — 8MP (4K) resolution captures four times the detail of 1080p. Even when a person or car is fa... (2/2) — 8MP Ultra HD
8MP (4K) resolution captures four times the detail of 1080p.
Even when a person or car is far down the driveway, you can zoom in and still recognise a face or read a number plate — detail that lower-resolution cameras lose.

30m IR Night Vision — Built-in infrared lets the camera see in complete darkness up to around 30m — enough ... (1/2) — 30m IR Night Vision
Built-in infrared lets the camera see in complete darkness up to around 30m — enough for a typical driveway, front yard or entrance. People and vehicles stay clear in black-and-white, brighter the closer they are.

30m IR Night Vision — Built-in infrared lets the camera see in complete darkness up to around 30m — enough ... (2/2) — 30m IR Night Vision
Built-in infrared lets the camera see in complete darkness up to around 30m — enough for a typical driveway, front yard or entrance. People and vehicles stay clear in black-and-white, brighter the closer they are.

False Alarm Reduction — Filtering helps separate real activity from harmless movement like rain, leaves or ... — False Alarm Reduction
Filtering helps separate real activity from harmless movement like rain, leaves or pets, so you get fewer pointless notifications and the alerts that matter stand out.

Human/Vehicle Detection — Smart detection focuses on people and vehicles and can ignore things like swaying... — Human/Vehicle Detection
Smart detection focuses on people and vehicles and can ignore things like swaying branches, rain or small animals — helping cut down false alerts and making the right moments easier to find.

IP67 Weatherproof — Sealed against dust and water to IP67, built to keep working through rain, storms and h... — IP67 Weatherproof
Sealed against dust and water to IP67, built to keep working through rain, storms and harsh sun — suitable for fully outdoor mounting.

Two-Way Audio — Talk and listen in real time through the app — tell a courier where to leave a parcel, or s... — Two-Way Audio
Talk and listen in real time through the app — tell a courier where to leave a parcel, or speak to someone at the gate, whether you're home or away.

Strobe Light — On detecting activity, the camera can trigger a bright flashing strobe to make an intruder a... — Strobe Light
On detecting activity, the camera can trigger a bright flashing strobe to make an intruder aware they've been spotted — a visible warning rather than silent recording.

Illustrative — simulated for demonstration

§ 02Engineering

DS-2CD2386G2-ISU/SL specifications

- 4K resolution for high-quality CCTV camera imaging
- 2.8mm lens providing wide coverage angles
- DarkFighter technology enabling excellent night vision in low light
- 120dB true WDR for clear security camera footage against backlight
- H.265+ compression technology reducing bandwidth and storage needs
- Deep learning-based classification reduces false alarms for human and vehicle targets
- Active strobe light and audio alarm deter intruders for perimeter protection
- Built-in two-way audio enabling real-time communication on surveillance systems
- IP67 weatherproof rating ensuring reliable outdoor performance in Australia

§ 03Full datasheet

Detailed specifications

Camera & Image

Camera & Image — Hikvision Acusense DS-2CD2386G2-ISU/SL IP Camera 8MP 4K With Sound & Strobe Turret Camera
Feature	Detail
Image Sensor	1/1.8" Progressive Scan CMOS
Min. Illumination	Color: 0.003 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
Shutter Speed	1/3 s to 1/100,000 s
Slow Shutter	Yes
P/N	P/N
Wide Dynamic Range	120 dB
Day & Night	IR cut filter
SNR	≥ 52 dB
Target Cropping	Yes
Image Enhancement	BLC, HLC, 3D DNR
Image Parameters Switch	Yes
Image Settings	Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
Day/Night Switch	Day, Night, Auto, Schedule

Lens & Distance

Lens & Distance — Hikvision Acusense DS-2CD2386G2-ISU/SL IP Camera 8MP 4K With Sound & Strobe Turret Camera
Feature	Detail
Lens Type	Fixed focal lens, 2.8, 4, and 6 mm optional
Iris Type	Fixed
Focal Length & FOV	2.8 mm, horizontal FOV 111°, vertical FOV 59°, diagonal FOV 131° \| 4 mm, horizontal FOV 87°, vertical FOV 47°, diagonal FOV 102° \| 6 mm, horizontal FOV 51°, vertical FOV 28°, diagonal FOV 60°
Aperture	F1.6
Lens Mount	M12
DORI	2.8 mm: D: 89.2 m, O: 35.4 m, R: 17.8 m, I: 8.9 m \| 4 mm: D: 99.4 m, O: 39.4 m, R: 19.9 m, I: 9.9 m \| 6 mm: D: 140.0 m, O: 55.6 m, R: 28.0 m, I: 14.0 m
Pan Range	0° to 360°
Tilt Range	0° to 75°
Rotation Range	0° to 360°

Night Vision

Night Vision — Hikvision Acusense DS-2CD2386G2-ISU/SL IP Camera 8MP 4K With Sound & Strobe Turret Camera
Feature	Detail
Supplement Light Type	IR
IR Range	Up to 30 m
IR Wavelength	850 nm
Smart Supplement Light	Yes
Visual Alarm	Yes

Video

Video — Hikvision Acusense DS-2CD2386G2-ISU/SL IP Camera 8MP 4K With Sound & Strobe Turret Camera
Feature	Detail
Max. Resolution	3840 × 2160
Main Stream	50 Hz: 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) \| 60 Hz: 24 fps (3840 × 2160); 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream	50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) \| 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
Third Stream	50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) \| 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) *Third stream is supported under certain settings.
Video Compression	Main stream: H.265/H.264/H.264+/H.265+; Sub-stream: H.265/H.264/MJPEG; Third stream: H.265/H.264 *Third stream is supported under certain settings.
Video Bit Rate	32 Kbps to 16 Mbps
H.264 Type	Baseline Profile/Main Profile/High Profile
H.265 Type	Main Profile
H.264+	Main stream supports
H.265+	Main stream supports
Bit Rate Control	CBR/VBR
Scalable Video Coding (SVC)	H.264 and H.265 encoding
Region of Interest (ROI)	1 fixed region for main stream and sub-stream

Audio

Audio — Hikvision Acusense DS-2CD2386G2-ISU/SL IP Camera 8MP 4K With Sound & Strobe Turret Camera
Feature	Detail
Audio Type	Mono sound
Environment Noise Filtering	Yes
Audio Sampling Rate	8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Audio Compression	G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio Bit Rate	64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)

AI & Deep Learning

AI & Deep Learning — Hikvision Acusense DS-2CD2386G2-ISU/SL IP Camera 8MP 4K With Sound & Strobe Turret Camera
Feature	Detail
Face Capture	Yes
Perimeter Protection	Line crossing detection, intrusion detection, region entrance detection, region exiting detection; Supports human and vehicle targets classification

Network & Storage

Network & Storage — Hikvision Acusense DS-2CD2386G2-ISU/SL IP Camera 8MP 4K With Sound & Strobe Turret Camera
Feature	Detail
Simultaneous Live View	Up to 6 channels
API	Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK
Protocols	TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket, WebSockets
User/Host	Up to 32 users. 3 user levels: administrator, operator and user
Security	Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
Network Storage	NAS (NFS, SMB/CIFS), auto network replenishment (ANR); Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Client	iVMS-4200, Hik-Connect, Hik-Central
Web Browser	Plug-in required live view: IE 10, IE 11; Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+; Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+

Event & Alarm

Event & Alarm — Hikvision Acusense DS-2CD2386G2-ISU/SL IP Camera 8MP 4K With Sound & Strobe Turret Camera
Feature	Detail
Basic Event	Motion detection (human and vehicle targets classification), video tampering alarm, exception
Smart Event	Scene change detection
Linkage Method	Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture, trigger alarm output, audible warning, strobe light

Interface

Interface — Hikvision Acusense DS-2CD2386G2-ISU/SL IP Camera 8MP 4K With Sound & Strobe Turret Camera
Feature	Detail
Alarm	1 input, 1 output (max. 24 VDC/24 VAC, 500 mA)
Audio	1 input (line in), terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium; 1 output (line out), terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium; 1 built-in speaker, 1 built-in microphone
Built-in Microphone	Yes
Built-in Speaker	Power: 1.2 W. Max. sound pressure level: 10 cm: 95 dB.
On-Board Storage	Built-in micro SD/SDHC/SDXC slot, up to 512 GB
Hardware Reset	Yes
Ethernet Interface	1 RJ45 10 M/100 M self-adaptive Ethernet port

General & Environment

General & Environment — Hikvision Acusense DS-2CD2386G2-ISU/SL IP Camera 8MP 4K With Sound & Strobe Turret Camera
Feature	Detail
Web Client Language	33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
General Function	Anti-flicker, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter
Software Reset	Yes
Firmware Version	V5.5.112
Storage Conditions	-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup and Operating Conditions	-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Power Supply	12 VDC ± 25%, reverse polarity protection; PoE: 802.3af, Class 3
Power Consumption and Current	12 VDC, 0.75 A, max. 9 W; PoE (802.3af, 36 V to 57 V), 0.28 A to 0.17 A, max. 10 W
Power Interface	Ø 5.5 mm coaxial power plug
Camera Material	Metal except for trim ring
Camera Dimension	Ø138.3 mm× 124.5 mm (Ø5.4" × 4.9")
Package Dimension	170 mm × 170 mm × 150 mm (6.9" × 6.9" × 5.9")
Camera Weight	Approx. 840 g (1.9 lb.)
With Package Weight	Approx. 1160 g (2.6 lb.)
EMC	FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
Safety	UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014 ); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014 )
Environment	CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Protection	IP67 (IEC 60529-2013)

Hikvision Acusense DS-2CD2386G2-ISU/SL IP Camera 8MP 4K With Sound & Strobe Turret Camera — full specifications
Camera & Image — Image Sensor	1/1.8" Progressive Scan CMOS
Camera & Image — Min. Illumination	Color: 0.003 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
Camera & Image — Shutter Speed	1/3 s to 1/100,000 s
Camera & Image — Slow Shutter	Yes
Camera & Image — P/N	P/N
Camera & Image — Wide Dynamic Range	120 dB
Camera & Image — Day & Night	IR cut filter
Camera & Image — SNR	≥ 52 dB
Camera & Image — Target Cropping	Yes
Camera & Image — Image Enhancement	BLC, HLC, 3D DNR
Camera & Image — Image Parameters Switch	Yes
Camera & Image — Image Settings	Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
Camera & Image — Day/Night Switch	Day, Night, Auto, Schedule
Lens & Distance — Lens Type	Fixed focal lens, 2.8, 4, and 6 mm optional
Lens & Distance — Iris Type	Fixed
Lens & Distance — Focal Length & FOV	2.8 mm, horizontal FOV 111°, vertical FOV 59°, diagonal FOV 131° \| 4 mm, horizontal FOV 87°, vertical FOV 47°, diagonal FOV 102° \| 6 mm, horizontal FOV 51°, vertical FOV 28°, diagonal FOV 60°
Lens & Distance — Aperture	F1.6
Lens & Distance — Lens Mount	M12
Lens & Distance — DORI	2.8 mm: D: 89.2 m, O: 35.4 m, R: 17.8 m, I: 8.9 m \| 4 mm: D: 99.4 m, O: 39.4 m, R: 19.9 m, I: 9.9 m \| 6 mm: D: 140.0 m, O: 55.6 m, R: 28.0 m, I: 14.0 m
Lens & Distance — Pan Range	0° to 360°
Lens & Distance — Tilt Range	0° to 75°
Lens & Distance — Rotation Range	0° to 360°
Night Vision — Supplement Light Type	IR
Night Vision — IR Range	Up to 30 m
Night Vision — IR Wavelength	850 nm
Night Vision — Smart Supplement Light	Yes
Night Vision — Visual Alarm	Yes
Video — Max. Resolution	3840 × 2160
Video — Main Stream	50 Hz: 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) \| 60 Hz: 24 fps (3840 × 2160); 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
Video — Sub-Stream	50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) \| 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
Video — Third Stream	50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) \| 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) *Third stream is supported under certain settings.
Video — Video Compression	Main stream: H.265/H.264/H.264+/H.265+; Sub-stream: H.265/H.264/MJPEG; Third stream: H.265/H.264 *Third stream is supported under certain settings.
Video — Video Bit Rate	32 Kbps to 16 Mbps
Video — H.264 Type	Baseline Profile/Main Profile/High Profile
Video — H.265 Type	Main Profile
Video — H.264+	Main stream supports
Video — H.265+	Main stream supports
Video — Bit Rate Control	CBR/VBR
Video — Scalable Video Coding (SVC)	H.264 and H.265 encoding
Video — Region of Interest (ROI)	1 fixed region for main stream and sub-stream
Audio — Audio Type	Mono sound
Audio — Environment Noise Filtering	Yes
Audio — Audio Sampling Rate	8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Audio — Audio Compression	G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio — Audio Bit Rate	64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
AI & Deep Learning — Face Capture	Yes
AI & Deep Learning — Perimeter Protection	Line crossing detection, intrusion detection, region entrance detection, region exiting detection; Supports human and vehicle targets classification
Network & Storage — Simultaneous Live View	Up to 6 channels
Network & Storage — API	Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK
Network & Storage — Protocols	TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket, WebSockets
Network & Storage — User/Host	Up to 32 users. 3 user levels: administrator, operator and user
Network & Storage — Security	Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
Network & Storage — Network Storage	NAS (NFS, SMB/CIFS), auto network replenishment (ANR); Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Network & Storage — Client	iVMS-4200, Hik-Connect, Hik-Central
Network & Storage — Web Browser	Plug-in required live view: IE 10, IE 11; Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+; Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Event & Alarm — Basic Event	Motion detection (human and vehicle targets classification), video tampering alarm, exception
Event & Alarm — Smart Event	Scene change detection
Event & Alarm — Linkage Method	Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture, trigger alarm output, audible warning, strobe light
Interface — Alarm	1 input, 1 output (max. 24 VDC/24 VAC, 500 mA)
Interface — Audio	1 input (line in), terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium; 1 output (line out), terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium; 1 built-in speaker, 1 built-in microphone
Interface — Built-in Microphone	Yes
Interface — Built-in Speaker	Power: 1.2 W. Max. sound pressure level: 10 cm: 95 dB.
Interface — On-Board Storage	Built-in micro SD/SDHC/SDXC slot, up to 512 GB
Interface — Hardware Reset	Yes
Interface — Ethernet Interface	1 RJ45 10 M/100 M self-adaptive Ethernet port
General & Environment — Web Client Language	33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
General & Environment — General Function	Anti-flicker, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter
General & Environment — Software Reset	Yes
General & Environment — Firmware Version	V5.5.112
General & Environment — Storage Conditions	-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
General & Environment — Startup and Operating Conditions	-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
General & Environment — Power Supply	12 VDC ± 25%, reverse polarity protection; PoE: 802.3af, Class 3
General & Environment — Power Consumption and Current	12 VDC, 0.75 A, max. 9 W; PoE (802.3af, 36 V to 57 V), 0.28 A to 0.17 A, max. 10 W
General & Environment — Power Interface	Ø 5.5 mm coaxial power plug
General & Environment — Camera Material	Metal except for trim ring
General & Environment — Camera Dimension	Ø138.3 mm× 124.5 mm (Ø5.4" × 4.9")
General & Environment — Package Dimension	170 mm × 170 mm × 150 mm (6.9" × 6.9" × 5.9")
General & Environment — Camera Weight	Approx. 840 g (1.9 lb.)
General & Environment — With Package Weight	Approx. 1160 g (2.6 lb.)
General & Environment — EMC	FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
General & Environment — Safety	UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014 ); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014 )
General & Environment — Environment	CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
General & Environment — Protection	IP67 (IEC 60529-2013)

§ 04Why choose this

Built for the way you actually use the DS-2CD2386G2-ISU/SL

8MP 4K with AcuSense

3840 × 2160 resolution. Deep learning classifies people and vehicles, cutting false alarms from animals and moving objects.

Built-in Strobe and Speaker

Flashing strobe and audio alarm deter intruders. Supports custom voice messages through Hik-Connect.

Built-in Microphone

Records ambient audio alongside video. Adds context to footage — hear conversations, glass breaking, or car sounds.

120 dB WDR

Manages high-contrast scenes like glass doorways, sunlit lobbies, and partially shaded car parks.

IP67 Weatherproof

Fully sealed against dust and rain. Operates from -30°C to 60°C.

§ 05Where it fits

Right at home in these scenarios

Front Porch and Entrance

Mount under the eave. Wide 2.8 mm lens covers the full porch. Strobe and speaker warn off package thieves.

Side Gate or Passage

Turret shape fits neatly on a wall or soffit. AcuSense ignores cats and possums — only alerts on people and vehicles.

Small Retail Entry

Ceiling mount above the door. 4K resolution captures faces clearly. Two-way talk via external speaker possible.

Courtyard or Garden

IP67 handles sprinklers and rain. Strobe activates only when someone is detected.

§ 06Setup

Installation & setup

01

What's in the Box

1. Hikvision DS-2CD2386G2-ISU/SL Camera × 1 2. Mounting Screws & Anchors × 1 set 3. Quick Start Guide × 1

02

Installation Requirements

1. Power: PoE (IEEE 802.3af) or 12V DC. 2. Cable: Cat5e or Cat6, max 100 m. 3. Mounting: Wall or soffit. Camera weighs about 650 g. 4. Height: 2.5–3.5 m for best detection accuracy.

03

App Setup

1. Download Hik-Connect app (iOS or Android). Create an account. 2. Power the camera via PoE. Wait about 60 seconds. 3. Scan the QR code or add by serial number. 4. Configure strobe/speaker alarm rules, detection zones, and push notifications.

§ 07Questions

Frequently asked about the DS-2CD2386G2-ISU/SL

Q.01

How is this different from the DS-2CD2387G2H-LISU/SL?

The 2386G2 uses IR only (no warm light / no ColorVu). The 2387G2H has Smart Hybrid Light for colour night vision. The 2386G2 is more affordable if you do not need colour footage at night.

Q.02

Does the speaker play custom messages?

Yes. You can record and upload custom voice warnings through the Hik-Connect app or web interface.

Q.03

What IR range does it have?

Up to 30 m with Smart IR that adjusts intensity to avoid overexposure at close range.

Q.04

Does it have alarm I/O?

Yes. The ISU/SL model includes 1 alarm input, 1 alarm output, plus audio input and output.

Q.05

Can I use it without an NVR?

Yes. It supports microSD up to 256 GB for standalone recording. The Hik-Connect app gives you live view and playback.

Hikvision Acusense DS-2CD2386G2-ISU/SL IP Camera 8MP 4K With Sound & Strobe Turret Camera

3-Year Warranty

Free Shipping

30-Day Returns

Fast Delivery

What the DS-2CD2386G2-ISU/SL is

What the DS-2CD2386G2-ISU/SL features actually look like

8MP Ultra HD

30m IR Night Vision

False Alarm Reduction

Human/Vehicle Detection

IP67 Weatherproof

Two-Way Audio

Strobe Light

DS-2CD2386G2-ISU/SL specifications

Detailed specifications

Camera & Image

Lens & Distance

Night Vision

Video

Audio

AI & Deep Learning

Network & Storage

Event & Alarm

Interface

General & Environment

Built for the way you actually use the DS-2CD2386G2-ISU/SL

8MP 4K with AcuSense

Built-in Strobe and Speaker

Built-in Microphone

120 dB WDR

IP67 Weatherproof

Right at home in these scenarios

Front Porch and Entrance

Side Gate or Passage

Small Retail Entry

Courtyard or Garden

Installation & setup

What's in the Box

Installation Requirements

App Setup

Frequently asked about the DS-2CD2386G2-ISU/SL

How is this different from the DS-2CD2387G2H-LISU/SL?

Does the speaker play custom messages?

What IR range does it have?

Does it have alarm I/O?

Can I use it without an NVR?
