Hanwha PNV-A6081R-E2T 2MP SolidEDGE Dome with 2TB SSD, 40m IR
1 4
Hanwha

Hanwha PNV-A6081R-E2T 2MP SolidEDGE Dome with 2TB SSD, 40m IR

SKU: PNV-A6081R-E2T
Description

- SolidEDGE Server-Less Architecture: 2TB built-in SSD plus pre-loaded Wisenet WAVE VMS — complete camera + recording system in one housing, no external NVR needed.
- Extend to 6 Cameras From One Unit: connects up to 5 additional Hanwha cameras that record to the same 2TB SSD — turn one SolidEDGE camera into a 6-channel micro-NVR.
- Built-In Cybersecurity: TPM 2.0 hardware chip + FIPS 140-2 Level 2 certification for local data encryption — mandatory for sites where the recording resides in-camera.
- IP66/IP67 + IK10 + IP6K9K: fully sealed for high-pressure wash-down environments — food processing, chemical wash-down, industrial cleaning zones.
$3,886.40 AUD $3,886.40 AUD
Bulk Price$3,653.22 AUD
Save $233.18 AUD — 6% off orders over $1,500, applied automatically at checkout.
Business or bulk buyer? Apply for trade pricing →
Found a lower price? We’ll match it →
Delivery, warranty & returns · ships same day before 2pm
  • Same-day dispatch on in-stock orders placed before 2pm, Sydney time.
  • 1–4 business days Australia-wide. Free standard shipping over $300, flat $25 under.
  • 3-year warranty on cameras and recorders, back-to-base, plus your Australian Consumer Law rights.
  • 30-day returns on unopened items. Faulty on arrival? We cover return shipping.
  • Genuine Australian stock. Never grey imports. Prices include GST.
  • American Express
  • Apple Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Union Pay
  • Visa

See all FAQs →

In stock
Build your setup Build a complete CCTV system Complete setup from $4,256.40

A camera needs an NVR, a hard drive, and cabling to work. Add everything below, or pick a ready-made kit.

Select hard drive · 4TB ≈ 2-3 weeks for 4 cameras recording 24/7
Add accessories Optional. Junction box → hides & weatherproofs cable joins (best for outdoors). Brackets → only if mounting on a corner or under eaves. Cable → one per camera; skip if you already have your own.
0
0
0
0
Bundle total: $3,886.40
Bulk Price$3,653.22 6% off orders over $1,500 — applied automatically at checkout.

§ 01Overview

What the PNV-A6081R-E2T is

The Hanwha PNV-A6081R-E2T is a SolidEDGE camera — a 2MP outdoor vandal dome with a built-in 2TB SSD and Wisenet WAVE VMS pre-installed, delivering a complete server-less recording system in a single camera housing.

Beyond just self-recording, the SolidEDGE architecture allows the camera to act as a micro-NVR: up to five additional Hanwha cameras can be connected and record to the same 2TB SSD, letting one PNV-A6081R-E2T serve as the recording hub for a 6-channel small-site deployment.

The 4.38mm to 9.33mm motorized varifocal lens covers 103.1° wide to 44.5° tight; WiseIR reaches 40m for full-dark identification.

TPM 2.0 hardware root of trust plus FIPS 140-2 Level 2 certification protect the on-device recording data — critical when the storage resides in-camera.

IP66, IP67, IK10, NEMA 4X plus ISO 20653 IP6K9K high-pressure water-jet rating; the fully-sealed housing suits food processing, industrial wash-down, and chemically-hostile deployment environments.

PoE+ (802.3at Class 4) or 12VDC power.

Ideal for small businesses that need a complete surveillance system without a separate NVR appliance.

§ 02Engineering

PNV-A6081R-E2T specifications

- 2MP (1920x1080) resolution at up to 120fps in H.265/H.264, MJPEG codec supported
- 4.38mm to 9.33mm motorized varifocal lens, 103.1° to 44.5° horizontal field of view
- 2TB built-in SSD plus pre-loaded Wisenet WAVE VMS — no external NVR required
- Connects up to 5 additional Hanwha cameras recording to the same SSD (6 total channels)
- IR viewable length up to 40m for full-dark identification
- extremeWDR (120dB), WiseNR II AI-driven noise reduction, WiseStream
- AI Object Classification: Person, Face, Vehicle, License plate
- TPM 2.0 hardware root of trust + FIPS 140-2 Level 2 encryption certification
- IP66, IP67, IP6K9K high-pressure water-jet, IK10, NEMA 4X — food-industry-grade sealing
- ONVIF Profile S/G/T, SUNAPI (HTTP API)
- PoE+ (IEEE 802.3at, Class 4), 12VDC input
- Outdoor vandal dome housing suited to industrial wash-down environments

§ 04Why choose this

Built for the way you actually use the PNV-A6081R-E2T

Complete Surveillance System In One Camera

Server-less architecture removes the NVR appliance, its rack space, its cabling, its power supply, its support contract, and its failure surface. One SolidEDGE camera plus a mounting bracket is the complete system for a small commercial or industrial site.

Expandable to a 6-Camera System

Unlike other 'edge NVR' concepts that record only the built-in camera, SolidEDGE lets you add up to 5 more Hanwha cameras writing to the same 2TB SSD. That's a micro-NVR replacement for typical small-business six-camera deployments.

Hardware-Level Data Protection

When the recording lives inside the camera housing, data security matters more than usual. TPM 2.0 hardware chip and FIPS 140-2 Level 2 certification give hardware-level encryption that a software-only approach cannot match — meaningful in regulated sites.

Rated for the Environments Where Other Cameras Fail

The IP6K9K rating adds high-pressure water-jet resistance to the standard IP66/IP67 stack — suitable for food processing, meatworks, dairy, breweries, and chemical wash-down zones where standard outdoor cameras leak within a year.

§ 05Where it fits

Right at home in these scenarios

Food Processing & Meatworks

Daily high-pressure wash-down destroys standard outdoor cameras within a year; IP6K9K sealing plus server-less recording makes SolidEDGE the practical choice for these environments.

Small Retail & Hospitality Sites

Six-camera deployments (front, back, tills, storage, kerb, back-door) fit within the SolidEDGE 6-channel envelope — one camera plus five satellites replaces a whole NVR-plus-camera stack.

Remote Sites Without Rack Space

Off-grid or minimalist sites (kiosks, cabins, unattended plant rooms) where a physical NVR appliance and its cabling aren't practical.

Chemical Process & Waste Water

Chemical wash-down, corrosive atmospheres, and constant humidity destroy standard bullet housings; IP6K9K + FIPS-protected local storage covers both physical and data protection needs.

Compliance-Sensitive Small Sites

Where data must not leave a specific site (some healthcare, legal, and government tenant configurations), edge-only recording in a FIPS 140-2-certified store removes the network exposure that centralised NVRs introduce.

§ 06Setup

Installation & setup

01

What's in the Box

1. Hanwha PNV-A6081R-E2T Camera (with 2TB SSD pre-installed) x 1 2. Mounting Template & Fixings x 1 set 3. Quick Start Guide x 1

02

Installation Requirements

1. Power: PoE+ (IEEE 802.3at, Class 4) or 12VDC — 2TB SSD + 40m IR draw exceeds 802.3af budget. 2. Mounting: outdoor vandal dome housing rated IP66/IP67/IP6K9K/IK10/NEMA 4X. 3. Storage: 2TB SSD pre-installed; no external NVR needed. 4. Network: RJ-45 with weather-sealed connector for outdoor positions; ONVIF Profile S/G/T for third-party VMS or the pre-installed Wisenet WAVE.

03

App & Setup

1. Power on the camera; Wisenet WAVE VMS auto-initialises on first boot. 2. Set admin password on first login (brute-force prevention enforced). 3. Configure recording schedules and event rules in WAVE. 4. To add additional cameras: connect up to 5 additional Hanwha cameras to the same network; register them in WAVE for recording to the SolidEDGE SSD.

§ 08Questions

Frequently asked about the PNV-A6081R-E2T

Q.01

What does SolidEDGE actually mean?
SolidEDGE is Hanwha's server-less recording architecture: a camera with a built-in 2TB SSD and pre-installed Wisenet WAVE VMS, functioning as its own recording system with no external NVR appliance. It also acts as a mini-NVR — up to 5 more cameras can be connected and record to the same SSD.
Q.02

How many cameras total does the system support?
Six channels: the built-in PNV-A6081R-E2T plus up to 5 additional Hanwha cameras registered to the same WAVE VMS instance, all recording to the shared 2TB SSD.
Q.03

Why 2MP instead of a higher resolution?
SolidEDGE prioritises long recording retention over maximum pixel density. 2MP 1080p recording at up to 120fps across 6 channels comfortably fits the 2TB SSD for continuous multi-week retention — higher-resolution capture would fill the same storage much faster.
Q.04

What's the practical difference between IP67 and IP6K9K?
IP67 covers temporary immersion in water at atmospheric pressure. IP6K9K specifically certifies high-pressure water-jet resistance (up to 100 bar) — the difference between 'survives being rained on' and 'survives industrial wash-down cleaning cycles'.
Q.05

What cybersecurity does the SolidEDGE storage have?
TPM 2.0 hardware root of trust plus FIPS 140-2 Level 2 certification for cryptographic operations. Recording data on the SSD is encrypted at rest with hardware-level key protection — meaningful when the storage is physically accessible in-camera.
Q.06

Do I need Wisenet WAVE separately?
No. WAVE VMS is pre-installed on the SolidEDGE unit as part of the shipped product. Configuration happens via the WAVE web interface after first boot; no separate VMS licence purchase is required for the SolidEDGE-embedded WAVE instance.
Q.07

Can I remove the built-in SSD and replace it?
The 2TB SSD is factory-installed. Contact your Hanwha reseller for any hardware modification or capacity expansion needs — this is a purpose-designed integrated camera+recorder, not a generic camera with a swappable drive.
