The Hikvision DS-PS1-E-WB is a wireless outdoor sounder for AX PRO alarm systems. Mounted high on an external wall, its 110dB siren and blue strobe make an alarm loud and visible from outside the property - a strong deterrent and a clear call for attention - all without running siren cable back to the hub.

At a glance
- 110dB external sounder with a blue strobe for outdoor deterrence
- IP65 weatherproof housing, -20 to 60 degrees C
- 433MHz two-way wireless with AES-128, up to 900m open-air
- 4 x CR123A batteries, up to 3 years, or 12 VDC
- Front and rear tamper protection for the AX PRO platform

The Hikvision DS-PM1-O1L-WB is a wireless relay output module for Hikvision AX PRO alarm systems. It lets the alarm switch a low-voltage circuit - by an alarm event, a schedule, a fault, or manually from the Hik-Connect app - so you can automate devices such as a gate, a light or an indicator without running a wired output back to the hub.

Key points
- One NO/NC relay output, 0-36 VDC, up to 5 A
- Triggered by alarm, manual app control, schedule or fault
- 433 MHz two-way wireless with AES-128 encryption, up to 800 m
- Flexible DC 7-24 V power input
- Three status LEDs for register/signal, power and relay state
- Compact wall-mount module, 38 x 25 x 18 mm

The Hikvision DS-PKF1-WB is a compact wireless keyfob for Hikvision AX PRO alarm systems. It lets you arm in away or stay mode, disarm, and trigger a panic alarm with a press of a button, so you can control your security on the way in and out without reaching for a keypad or your phone. It pairs with the AX PRO hub over 433 MHz and comes in white or black.

Key points
- One-touch stay/away arming, disarming and panic alarm
- 433 MHz 2GFSK wireless to the AX PRO hub
- Range up to 500 m in open space
- Up to 3 years' standby battery life
- Lightweight 16 g body for a keyring or pocket
- Available in white or black

The Hikvision DS-PK1-E-WB is a wireless keypad for Hikvision AX PRO alarm systems. It gives you a wall-mounted point to arm in stay or away mode, disarm and clear alarms with a PIN code on its backlit touch keys, plus one-push emergency keys. It links to the AX PRO hub over encrypted 433 MHz wireless and runs on AA batteries, so there is no cabling to run.

Key points
- Full touch keypad with LED backlight for PIN arm/disarm
- Stay and away arming, disarming and alarm clearing
- One-push fire, panic and medical emergency keys
- 433 MHz 2GFSK wireless with AES-128 encryption and frequency hopping
- Battery powered (4 x AA included), up to 2 years' life
- Wireless install with no cabling; configure remotely via app
- Note: PIN keypad only - no built-in tag reader or LCD

The Hikvision DS-PDWL-E-WB is a wireless water-leak detector for AX PRO alarm systems. Placed on the floor near a likely leak, it raises an early warning the moment water bridges its probe, so a slow leak under a sink or behind a washing machine can be caught before it causes costly damage.

At a glance
- Detects water through an included external probe and internal sensing
- IP66-rated body for damp locations near appliances and pipes
- Tri-X two-way wireless on 433MHz, AES-128 with frequency hopping
- One CR2450 battery, up to 3 years; front and rear tamper
- App alerts through Hik-Connect; wall or surface placement, indoor

The Hikvision DS-PDPG12P-EG2-WB is a wireless dual-function detector for the AX PRO system, combining a 12-metre PIR with an 8-metre acoustic glass-break sensor in one unit. It offers up to 30kg pet immunity, runs on Tri-X two-way wireless, lasts up to four years on its batteries, and is for indoor wall mounting.

At a glance
- Dual function: 12m / 85.9-degree PIR plus 8m acoustic glass-break detection
- Up to 30kg pet immunity (Auto / High / Pet sensitivity)
- Tri-X two-way wireless (433MHz, AES-128), up to 1km open-air
- Battery powered (2 x CR123A), up to 4 years standby
- Indoor wall mount 1.8m to 2.4m; optional wall/ceiling bracket; front and rear tamper

Detect movement and receive instant image verification to confirm whether an alarm is a real threat or a false alert.

The Hikvision DS-PDPC12P-EG2-WB is a wireless PIRCAM detector for AX PRO alarm systems. It combines a passive infrared motion sensor with a built-in camera that captures JPEG snapshots when the alarm triggers, so you or a monitoring centre can see what set it off - turning a bare motion alert into a verified event over a fully wireless link.

At a glance
- PIR motion + built-in camera for image verification (JPEG snapshots on alarm)
- 12m range / 85.9 degree / 52 detection zones; up to 30kg pet immunity
- Polarising IR lens with 12m infrared fill for clearer low-light snapshots
- CAM-X two-way wireless on 433MHz, up to 800m open-air, AES-128
- Three CR123A batteries, up to 6 years; front and rear tamper; indoor wall mount
