The Hikvision DS-PK1-LT-WB is a wireless LCD keypad for the AX PRO alarm system, with a backlit LCD screen, full-touch keys and a built-in Mifare tag reader. It arms and disarms by PIN or tag, has one-touch fire, panic and medical keys, and communicates over Tri-X two-way wireless. Available in black or white.

At a glance
- Backlit LCD screen with full-touch keys for clear status and menus
- Built-in Mifare tag reader for tap-to-arm without a PIN
- One-touch fire, panic and medical emergency keys
- Tri-X two-way wireless (433MHz, 2GFSK), up to 800m open-air
- Battery powered (4 x CR123), up to 2 years standby; front and rear tamper

The Hikvision DS-PHA64-LP/NP is an AX Hybrid Pro hardwired alarm control panel - the brain of a professional intrusion system. Built around wired reliability but able to add wireless detectors and peripherals, it scales from a small home to a large commercial site with up to 64 zones, 8 areas and 4-channel video verification.

At a glance
- 8 on-board zones, expandable to 64 wired and wireless zones
- 45 users, 8 areas/partitions, 4 on-board outputs expandable to 64
- LAN, Wi-Fi and PSTN reporting, with optional 3G/4G cellular module
- 4-channel on-board IP camera video verification (7-second clips)
- Hik-Connect app control with free self-monitoring, 12-15 VDC, backup battery ready

The Hikvision DS-PDTT15AM-LM-WB is a wireless outdoor Tri-Tech detector for AX PRO alarm systems. By requiring two PIR sensors and a 24GHz microwave sensor to agree before it raises an alarm, it delivers dependable perimeter detection outdoors while shrugging off the weather, wildlife and moving foliage that defeat ordinary sensors.

At a glance
- Tri-Tech detection: dual PIR plus 24GHz microwave with triple-signal logic
- 15m range, 90-degree angle adjustable up to 180 degrees, 92 zones
- Pet immunity up to 40kg and active IR anti-masking
- IP65 weatherproof, -25 to 60 degrees C, anti-sway analytics
- Tri-X two-way 433MHz to 1km, CR123A x5 up to 5 years

The Hikvision DS-PDTPH-E-WB is a wireless temperature and humidity sensor for AX PRO alarm systems. It keeps watch on indoor conditions and sends an alert through Hik-Connect when temperature or humidity drifts outside the range you set, so problems in a server room, cellar, cool room or store room are caught early.

At a glance
- Wireless temperature and humidity monitoring with threshold alerts via Hik-Connect
- 2.7-inch on-screen display shows live readings
- -10 to 55°C standalone, or -35 to 99°C with the included external probe
- Tri-X two-way wireless, up to 800m open-air, 433MHz, AES-128 with frequency hopping
- Two AAA batteries, up to 2 years; front and rear tamper; indoor wall mount

The Hikvision DS-PDSMK-S-WB is a wireless photoelectric smoke detector for Hikvision AX PRO alarm systems. It gives early warning of a fire with a photoelectric sensing chamber and a built-in 85 dB sounder, while also alerting your AX PRO system and your phone so you are warned whether you are home or away. A sealed 10-year battery means a decade of protection with no recharging.

Key points
- Photoelectric smoke sensing for early fire warning
- Built-in sounder, 85 dB or more at 3 m
- Two-way 433 MHz wireless with AES-128 encryption
- Range up to 800 m in free space
- Sealed 10-year battery (non-replaceable CR17450)
- Ceiling mount; indoor use; red alarm LED

The Hikvision DS-PDSMK-4BAR is a wired 4-wire photoelectric smoke detector that adds early fire warning to a 12 VDC intrusion or fire alarm system. When smoke enters its sensing chamber, it raises a built-in sounder and signals the connected alarm panel, so an emerging fire is flagged locally and remotely.

At a glance
- Photoelectric smoke sensing for early, low-nuisance fire detection
- 4-wire conventional connection to 12 VDC alarm panels
- Built-in high-output sounder, approximately 85dB at 3m
- Normally Open (NO) or Normally Closed (NC) relay output
- Dual red LEDs with 360-degree visibility, low-profile ceiling mount

The Hikvision DS-PDSK-P is a wired shock detector for AX Hybrid Pro alarm systems. Fitted directly to a door, window, wall or safe, it senses the vibration of drilling, levering or hammering and raises the alarm during a forced-entry attempt - before an intruder actually gets inside.

At a glance
- Shock sensor detects forced-entry vibration on the protected surface
- Adjustable sensitivity via potentiometer, with gross-attack override
- Advanced digital background-noise filter to reduce false alarms
- Wired NC alarm output, front tamper, blue LED indicator
- 9-16 VDC (typically 12 VDC), 30mA, indoor use

The Hikvision DS-PDP18-EG2 is a wired indoor PIR motion detector from the AX Hybrid range, giving 18 metres of volumetric coverage from a slim, unobtrusive housing. It uses a dual-element infrared sensor and a 3D Fresnel lens to detect a moving intruder accurately while ignoring everyday nuisances, and its selectable end-of-line resistors let it wire into almost any hardwired or hybrid alarm panel.

Key points
- 18 m volumetric coverage at an 85.9° detection angle
- Dual-element PIR sensor with 3D Fresnel lens optics
- Creep-zone protection covers the blind spot directly below the unit
- Sealed optical chamber resists insects and false triggers
- Selectable EOL resistors (1K/2K2/4K7/5K6/8K2) suit most panels
- 9-16 VDC wired power with reverse-polarity protection
- Optional pet mask for immunity up to 10 kg
