Hikvision DS-K2702WX-E1 Two-Door Access Controller
Hikvision DS-K2702WX-E1 is an Ultra Series two-door access controller that can grow to 126 doors by adding up to 62 DS-K2M002X access modules. It connects over gigabit Ethernet or 2.4 GHz Wi-Fi, accepts standard PoE or 100 to 240 VAC input, and provides RS-485 ports for readers and modules plus four Wiegand 26/34 reader inputs.
Delivery, warranty & returns · ships same day before 2pm
- Same-day dispatch on in-stock orders placed before 2pm, Sydney time.
- Metro delivery: 2–4 business days. Regional areas may take longer. Free standard shipping over $300, flat $25 under.
- 3-year warranty on cameras and recorders, back-to-base, plus your Australian Consumer Law rights.
- 30-day returns on unopened items. Faulty on arrival? We cover return shipping.
- Genuine Australian stock. Never grey imports. Prices include GST.
All cameras, NVRs and DVRs come with a 3-year back-to-base manufacturer warranty covering defects in materials and workmanship, in addition to your rights under Australian Consumer Law. Hard drives and accessories are covered as set out in our Warranty Policy.
Standard shipping is free on all orders over $300 AUD, Australia-wide. Orders under $300 ship at a flat rate of $25, calculated at checkout. Tracking is included on every order.
You have 30 days from the day you receive your order to request a change-of-mind return. Items must be unopened, factory-sealed and in resalable condition. A 15% restocking fee applies and return postage is at your cost. Faulty or incorrectly supplied items are different: we cover the return shipping and refund or replace at no charge. Read the full Return & Refund Policy.
Order before 2pm (Sydney time) on a business day and in-stock items are dispatched the same day. Metro delivery usually takes 2–4 business days. Regional areas may take longer. You'll receive a tracking number by email as soon as your order leaves the warehouse.
§ 01Overview
What the DS-K2702WX-E1 is
Hikvision DS-K2702WX-E1 is an Ultra Series two-door access controller that can grow to 126 doors by adding up to 62 DS-K2M002X access modules. It connects over gigabit Ethernet or 2.4 GHz Wi-Fi, accepts standard PoE or 100 to 240 VAC input, and provides RS-485 ports for readers and modules plus four Wiegand 26/34 reader inputs.
On-board I/O covers two lock outputs, two door contact inputs, two exit-button inputs, four alarm inputs and four alarm outputs. Seven RS-485 ports are split as two for card readers and five for access modules. Capacity is 100,000 users, 200,000 cards, 10,000 fingerprints and 600,000 events.
Power consumption is up to 72 W. The unit is wall-mounted and rated -10 °C to 55 °C at 0 to 90 % humidity.
§ 02Engineering
DS-K2702WX-E1 specifications
Gigabit Ethernet plus 2.4 GHz Wi-Fi 802.11b/g/n
Powered by standard PoE or 100 to 240 VAC
Seven RS-485 ports (two for readers, five for modules) and four Wiegand 26/34 inputs
Two lock outputs, two door contacts, two exit buttons, four alarm inputs and four alarm outputs
100,000 users, 200,000 cards and 600,000 events
§ 03Full datasheet
Detailed specifications
Specification
| Feature | Detail |
|---|---|
| Model | DS-K2702WX-E1 |
| Doors | 2 on the controller; up to 126 doors with up to 62 DS-K2M002X access modules |
| Wired network | 1 × 10/100/1000 Mbps self-adaptive |
| Wi-Fi | Supported, 2.4 GHz, 802.11b/g/n |
| PoE | 1 port; standard PoE |
| Power supply | 100 VAC to 240 VAC, or standard PoE |
| Power consumption | ≤ 72 W |
| RS-485 | 7 (2 for card readers, 5 for access modules) |
| Wiegand | 4, standard 26/34 input |
| Lock control | 2 |
| Door contact input | 2 |
| Exit button input | 2 |
| Alarm inputs | 4 |
| Alarm outputs | 4 |
| User capacity | 100,000 |
| Card capacity | 200,000 |
| Fingerprint capacity | 10,000 |
| Event capacity | 600,000 |
| Operating temperature | -10 °C to 55 °C |
| Humidity | 0 % to 90 % non-condensing |
| Installation | Wall mounting |
| Linked reader capacity | 4 RS-485 card readers (OSDP) and 4 Wiegand card readers |
| Specification — Model | DS-K2702WX-E1 |
|---|---|
| Specification — Doors | 2 on the controller; up to 126 doors with up to 62 DS-K2M002X access modules |
| Specification — Wired network | 1 × 10/100/1000 Mbps self-adaptive |
| Specification — Wi-Fi | Supported, 2.4 GHz, 802.11b/g/n |
| Specification — PoE | 1 port; standard PoE |
| Specification — Power supply | 100 VAC to 240 VAC, or standard PoE |
| Specification — Power consumption | ≤ 72 W |
| Specification — RS-485 | 7 (2 for card readers, 5 for access modules) |
| Specification — Wiegand | 4, standard 26/34 input |
| Specification — Lock control | 2 |
| Specification — Door contact input | 2 |
| Specification — Exit button input | 2 |
| Specification — Alarm inputs | 4 |
| Specification — Alarm outputs | 4 |
| Specification — User capacity | 100,000 |
| Specification — Card capacity | 200,000 |
| Specification — Fingerprint capacity | 10,000 |
| Specification — Event capacity | 600,000 |
| Specification — Operating temperature | -10 °C to 55 °C |
| Specification — Humidity | 0 % to 90 % non-condensing |
| Specification — Installation | Wall mounting |
| Specification — Linked reader capacity | 4 RS-485 card readers (OSDP) and 4 Wiegand card readers |
§ 08Questions
Frequently asked about the DS-K2702WX-E1
Q.01
How many readers can I connect?
Q.02
Can it grow beyond two doors later?
