Hanwha QNV-C9011R 8MP AI IR Vandal Dome 3mm — Person/Vehicle Detect, 20m IR, IP67/IK10, Built-in Mic

SKU: QNV-C9011R
Description

- 8MP Identification-Grade Detail: 3840x2160 resolution captures face and license plate detail at close-to-mid range where 5MP loses definition — the difference between 'detect a shape' and 'identify the subject'.
- On-Device AI Classification: Person and vehicle separation reduces false alerts from wind, shadows, and animals on retail and perimeter deployments.
- Built-in Microphone: Synchronised audio capture alongside 8MP video — useful for retail dispute resolution and workplace incident review.
- IP67 + IK10 Combo: Deeper water ingress protection than the IP66 sibling — margin on low-set exterior mounts subject to occasional flooding.
$618.45 AUD $618.45 AUD $637.56 AUD
Sale 3.0% $19.11 AUD (3.0%)
Member Sign in to save $12.37 on this item — free to join.
Building a kit or need installation? Email sales@smarket.com.au for a quote.

inc GST + 3 Year Warranty & Support
Free shipping over AUD300

In stock
Build your setup Build a complete CCTV system Complete setup from $887.90

A camera needs an NVR, a hard drive, and cabling to work. Add everything below, or pick a ready-made kit.

Select hard drive · 4TB ≈ 2-3 weeks for 4 cameras recording 24/7
Add accessories Optional. Junction box → hides & weatherproofs cable joins (best for outdoors). Brackets → only if mounting on a corner or under eaves. Cable → one per camera; skip if you already have your own.
1
1
1
1
Bundle total: $618.45
3-Year Warranty

3-Year Warranty

Warranty on all cameras

Free Shipping

Free Shipping

On orders over $300

30-Day Returns

30-Day Returns

Easy returns for unopened items

Fast Delivery

Fast Delivery

5-10 Day Delivery Australia-wide

§ 01Overview

What the QNV-C9011R is

The Hanwha QNV-C9011R is an 8MP AI outdoor vandal dome camera built for commercial and institutional installations that need identification-grade image detail at close-to-mid range distances.

A 3mm fixed lens delivers wide coverage at 3840x2160 resolution — the step up from 5MP that separates 'detect a shape' from 'identify the subject' at typical retail counter, foyer, or corridor distances.

On-device AI classifies people and vehicles, generating targeted alerts rather than raw motion events.

H.265+ compression keeps storage and bandwidth manageable at 8MP resolution — a practical necessity when adding higher-resolution cameras to shared NVR storage.

Built-in microphone captures audio synchronised with video, useful for retail dispute resolution and workplace incident review.

Rated IP67 for outdoor exposure and IK10 for physical impact resistance, the camera suits demanding installation environments including retail ceilings, lobby entries, lift corridors, and public-facing concourses where both weather and tampering are genuine risks.

ONVIF integration supports connection to third-party NVRs and video management systems.

§ 02Engineering

QNV-C9011R specifications

- 8MP resolution (3840x2160)
- Fixed 3mm lens for wide continuous coverage
- On-device AI person and vehicle classification
- True WDR for high-contrast scenes
- 20m IR viewable length
- H.265+, H.265, H.264, MJPEG codecs
- Built-in microphone for synchronised audio capture
- ONVIF-compatible for third-party VMS/NVR integration
- Hanwha Q Series (AI)
- IP67 weatherproof / IK10 impact resistance
- PoE powered
- Outdoor vandal dome housing

§ 04Why choose this

Built for the way you actually use the QNV-C9011R

Identification vs Detection

8MP resolution captures face and license plate detail at typical retail counter, foyer, and corridor distances where 5MP loses definition. The difference between 'someone was there' and 'here's exactly who it was' when the footage matters for a dispute or investigation.

AI Filters What Actually Matters

On-device person/vehicle classification cuts alert noise from shadow flicker, HVAC-driven movement, and animal traffic — meaningful on always-monitored sites where standard motion detection generates too many events to review.

IP67 Beats IP66 on Low-Set Mounts

IP67 provides margin against occasional immersion (test: 1m water for 30 minutes) — practical for ground-level exterior mounts, low-set canopy fitouts, and installations subject to seasonal flooding. IP66 covers water jets but not immersion.

Audio Evidence Alongside 8MP Video

Built-in microphone captures synchronised audio — useful for retail dispute resolution and workplace incident review. Note Australian privacy law consent requirements when deploying audio recording.

§ 05Where it fits

Right at home in these scenarios

Retail Ceilings and Counter Areas

8MP + AI person classification generates high-detail identification-grade footage of counter interactions, cutting false alerts from POS shadow flicker. Synchronised audio adds evidence value on dispute resolution.

Lobby Entries and Lift Corridors

3mm wide framing covers full lobby or lift lobby area from one mount; IK10 impact rating suits publicly accessible ceilings where tampering is a considered risk.

Public-Facing Concourses and Shopping Centre Corridors

AI classification separates real subjects from environmental noise on high-traffic public areas; the 8MP resolution supports post-event zooming to identify individuals from wide-frame footage.

Low-Set Exterior Building Entries

IP67 provides margin over IP66 for ground-level building entries and canopy-adjacent mounts where seasonal water accumulation is possible.

§ 06Setup

Installation & setup

01

What is in the Box

1. Hanwha QNV-C9011R Camera x 1 2. Mounting Screws & Anchors x 1 set 3. Quick Start Guide x 1

02

Installation Requirements

1. Power: PoE — verify switch/injector budget when adding 8MP AI cameras. 2. Mounting: ceiling, soffit, or wall — outdoor vandal dome housing. 3. Sealing: preserve the IP67 rating by sealing all conduit and cable entries. 4. Audio: signage disclosure if enabling audio recording on public-facing installations (Australian privacy law).

03

App/Software Setup

1. Access via web viewer, or add to Hanwha Wisenet WAVE or SSM software. 2. Configure AI analytics: person/vehicle classification thresholds and event forwarding. 3. Enable H.265+ compression from the outset to keep 8MP streams NVR-friendly. 4. Configure audio capture and confirm it's disabled where not legally allowed or consented.

§ 07Questions

Frequently asked about the QNV-C9011R

Q.01

Q: How does 8MP compare to 5MP for real-world use?
A: At typical retail counter, foyer, or corridor distances, 8MP (3840x2160) captures face and license plate detail where 5MP starts losing definition. The practical difference is between 'someone was present' (5MP) and 'here's exactly who it was' (8MP) when the footage matters for a dispute or investigation.
Q.02

Q: What AI events can this detect?
A: Person and vehicle classification separately from general motion — generating alerts on real subjects rather than shadow flicker, HVAC curtains, or animal traffic. Configure through the web viewer or Wisenet WAVE.
Q.03

Q: What's the practical difference between IP67 and IP66?
A: IP67 is rated for temporary immersion in 1m water for 30 minutes; IP66 covers water jets from any direction but not immersion. Practical impact: IP67 gives margin on low-set exterior mounts subject to occasional flooding or ground-level water accumulation, not day-to-day water spray.
Q.04

Q: How does H.265+ help at 8MP resolution?
A: 8MP raw streams generate substantially more data than 5MP. H.265+ adds further compression optimisation on top of standard H.265, keeping shared NVR storage sane when adding higher-resolution cameras to an existing setup. Practical: enable H.265+ from the outset unless a specific VMS requires standard H.265.
Q.05

Q: Can I use the built-in microphone?
A: Yes, but check consent requirements first. Australian privacy law varies by state — VIC, WA, and ACT require both-party consent for recording private conversations. Common practical mitigation is signage disclosure that audio is being recorded on the premises.
Q.06

Q: How far does the IR reach?
A: 20m — appropriate for indoor ceilings, apartment common areas, lobby entries, and short-to-mid exterior perimeters. Not designed for extended perimeter runs.
Q.07

Q: Can this integrate with a third-party NVR or VMS?
A: Yes — the QNV-C9011R supports ONVIF for standard third-party integration with major VMS platforms and generic NVRs. For AI-specific event forwarding into third-party VMS alarm workflows, test event delivery to your recorder before large rollouts.
Q.08

Q: Why pick this over the QNV-C8011R sibling?
A: For 8MP identification-grade resolution and IP67 sealing. The C8011R is 5MP with IP66. If face/plate identification detail matters, or the mount location has occasional water accumulation, the C9011R is the better fit; if 5MP suffices and standard IP66 covers the environment, the C8011R is a lower-cost choice.
