Hanwha XNV-C7083R X-Core 4MP AI IR Vandal Dome 2.8-10mm — 40m WiseIR, extremeWDR 120-150dB, IP66/IP67/IK10/NEMA4X
1 5
Hanwha

Hanwha XNV-C7083R X-Core 4MP AI IR Vandal Dome 2.8-10mm — 40m WiseIR, extremeWDR 120-150dB, IP66/IP67/IK10/NEMA4X

SKU: XNV-C7083R
Description

- 4MP Sweet Spot on Vandal Dome: More identification detail than 2MP without 6MP/4K storage cost — practical for post-event zoom on building entry and corridor coverage.
- Full X-Core AI Suite: Person/vehicle/face/plate classification with intrusion, loitering, line crossing analytics.
- Configurable 120-150dB extremeWDR: Standard 120dB for typical interiors or up to 150dB for extreme mixed-light scenes like fully glazed lobbies.
- Indoor + Outdoor Rated: IP66/IP67/IK10/NEMA4X — same camera works in exposed exterior positions or protected indoor ceilings.
$1,333.95 AUD $1,333.95 AUD $1,375.22 AUD
Sale 3.0% $41.27 AUD (3.0%)
Business or bulk buyer? Apply for trade pricing →
Found a lower price? We’ll match it →
Delivery, warranty & returns · ships same day before 2pm
  • Same-day dispatch on in-stock orders placed before 2pm, Sydney time.
  • 1–4 business days Australia-wide. Free standard shipping over $300, flat $25 under.
  • 3-year warranty on cameras and recorders, back-to-base, plus your Australian Consumer Law rights.
  • 30-day returns on unopened items. Faulty on arrival? We cover return shipping.
  • Genuine Australian stock. Never grey imports. Prices include GST.
  • American Express
  • Apple Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Union Pay
  • Visa

See all FAQs →

In stock
Build your setup Build a complete CCTV system Complete setup from $1,703.95

A camera needs an NVR, a hard drive, and cabling to work. Add everything below, or pick a ready-made kit.

Select hard drive · 4TB ≈ 2-3 weeks for 4 cameras recording 24/7
Add accessories Optional. Junction box → hides & weatherproofs cable joins (best for outdoors). Brackets → only if mounting on a corner or under eaves. Cable → one per camera; skip if you already have your own.
0
0
0
0
Bundle total: $1,333.95

§ 01Overview

What the XNV-C7083R is

The Hanwha XNV-C7083R is the 4MP tier of the X-Core AI vandal dome family — same face + plate + person + vehicle classification and intrusion/loitering/line-crossing analytics as the 2MP sibling, but stepped up to 4MP detail.

A 2.8-10mm motorised varifocal lens with 3.6x zoom lets framing be tuned from web viewer without opening the housing — particularly useful in finished ceilings or hard-to-access soffit mounts.

WiseIR reaches 40m for after-hours coverage, and extremeWDR is configurable across 120-150dB so scene setup can be tuned to the site: 150dB for extreme backlit glazing, 120dB for standard building interiors with lower processing overhead.

WiseNR II keeps IR-lit low-light footage clean without inflating bitrate.

Housing carries the full IP66/IP67/IK10/NEMA4X environmental spec — same SKU works on covered outdoor entries or protected indoor ceilings, meaningful for retail complexes, hospitality venues, and multi-tenant office fitouts where consistent camera choice across mixed-environment mounts simplifies procurement and NVR setup.

4MP is the practical sweet spot: enough detail for post-event identification zoom without inflating storage the way 6MP or 4K streams do on multi-camera deployments.

§ 02Engineering

XNV-C7083R specifications

- 4MP resolution (2592x1520) at up to 60fps H.265/H.264
- 1/2" CMOS sensor
- 2.8-10mm motorised varifocal lens, 3.6x optical zoom
- On-device AI person, vehicle, face, licence plate classification
- Intrusion, loitering, line crossing analytics
- extremeWDR configurable 120-150dB
- WiseNR II AI-based noise reduction
- WiseIR IR illumination up to 40m
- H.265, H.264, MJPEG codecs
- Wisenet X-Core platform
- IP66 + IP67 + IK10 + NEMA4X — indoor + outdoor rated
- microSD edge storage
- PoE powered

§ 04Why choose this

Built for the way you actually use the XNV-C7083R

4MP Resolution Sweet Spot

More detail than 2MP for post-event zoom to identify subjects at building entry and corridor distances, without inflating storage the way 6MP or 4K streams do across multi-camera deployments.

Face + Plate + Person + Vehicle AI

Full X-Core AI classification suite plus intrusion, loitering, and line crossing analytics — meaningful for identification workflows on building entries, corridors, and covered car park approaches.

One Camera Indoor + Outdoor

IP66/IP67/IK10/NEMA4X rating supports both exposed exterior installations and protected indoor ceilings — simplifies procurement and NVR configuration on mixed-environment sites (office lobby + adjacent covered walkway).

Configurable extremeWDR Range

120-150dB configurable — use 150dB mode for extreme mixed-light scenes (fully glazed lobbies at midday), or 120dB for typical building interiors with lower processing overhead.

§ 05Where it fits

Right at home in these scenarios

Covered Car Parks

120-150dB extremeWDR manages the high contrast at ramp entries; AI vehicle and plate classification support automatic vehicle logging and identification workflows.

Building Entrances and Retail Facades

4MP resolution supports post-event zoom to identify subjects at door distances; face classification generates alerts on real customers rather than shadow flicker from shopfront lighting.

Corporate Corridors and Reception

Vandal dome housing blends into finished ceilings; WiseIR reaches 40m for full corridor coverage after site lighting shuts down.

Mixed Indoor-Outdoor Commercial Sites

One SKU works across covered outdoor entries and adjacent interior ceilings — meaningful for retail complexes, hospitality venues, and multi-tenant offices where consistent camera choice matters.

§ 06Setup

Installation & setup

01

What is in the Box

1. Hanwha XNV-C7083R Camera x 1 2. Mounting Screws & Anchors x 1 set 3. Quick Start Guide x 1

02

Installation Requirements

1. Power: PoE. 2. Mounting: ceiling, soffit, or wall — vandal dome housing (indoor or outdoor). 3. Sealing: preserve IP66/IP67 rating by sealing all cable and conduit entries on outdoor installations.

03

App/Software Setup

1. Access via web viewer, or add to Hanwha Wisenet WAVE or SSM software. 2. Dial in zoom across the 2.8-10mm range remotely. 3. Configure AI analytics: face/plate/person/vehicle, intrusion, loitering, line crossing. 4. Configure extremeWDR level (120dB standard or 150dB for extreme mixed-light scenes).

§ 08Questions

Frequently asked about the XNV-C7083R

Q.01

Q: How is this different from the XNV-C6083R sibling?
A: The C7083R is 4MP; the C6083R is 2MP. Same X-Core AI feature set (face/plate/person/vehicle classification), same WiseIR 40m, same IP66/IP67/IK10/NEMA4X housing. Pick the C7083R when 4MP identification detail matters at your mount distance; pick the C6083R when 2MP suffices and budget matters.
Q.02

Q: Why 4MP instead of 2MP or 6MP?
A: 4MP is the sweet spot — more usable detail than Full HD (2MP) for identification and post-event zoom, without the storage cost of 6MP or 4K streams. Fits most vandal dome deployments where 2MP feels thin and 6MP+ is overkill for typical ceiling-to-floor distances.
Q.03

Q: Can this be mounted outdoors?
A: Yes — IP66/IP67/IK10/NEMA4X supports full exposed outdoor installation, unlike the XND-C7083RV indoor-only dome sibling (IP52). One consistent SKU across mixed-environment sites where indoor + outdoor coverage is required.
Q.04

Q: What AI events can this detect?
A: Person, vehicle, face, and licence plate classification, plus intrusion, loitering, and line crossing. Configure through web viewer or Wisenet WAVE.
Q.05

Q: What field of view can I dial in?
A: The 2.8-10mm motorised varifocal lens with 3.6x optical zoom lets you dial between wide corridor sweep at 2.8mm and focused counter or intersection shot at 10mm. Adjust remotely from web viewer.
Q.06

Q: What's 120-150dB extremeWDR mean in practice?
A: The WDR level is configurable — use 150dB for extreme mixed-light scenes (fully glazed lobbies at midday), or 120dB for typical building interiors where 120dB is enough and reduces processing overhead.
Q.07

Q: How far does WiseIR reach?
A: Approximately 40m — appropriate for building entries, corridor lengths, and covered car park coverage.
Q.08

Q: Can this integrate with third-party VMS?
A: Yes — supports ONVIF for standard third-party integration.
