Dahua KIT-DH-LR1002-1ET/LR1002-1EC EoC Pair
1 1
Dahua

Dahua KIT-DH-LR1002-1ET/LR1002-1EC EoC Pair

SKU: KIT-DH-LR1002-1ET/LR1002-1EC
Description

The Dahua LR1002-1ET / LR1002-1EC pair carries Ethernet and power over an existing coaxial cable. Dahua specifies 100 Mbps up to 400 m or 10 Mbps up to 1,000 m using RG59 under its stated cable conditions.
$85.00 AUD $85.00 AUD
Business or bulk buyer? Apply for trade pricing →
Found a lower price? We’ll match it →
Delivery, warranty & returns · ships same day before 2pm
  • Same-day dispatch on in-stock orders placed before 2pm, Sydney time.
  • Metro delivery: 2–4 business days. Regional areas may take longer. Free standard shipping over $300, flat $25 under.
  • 3-year warranty on cameras and recorders, back-to-base, plus your Australian Consumer Law rights.
  • 30-day returns on unopened items. Faulty on arrival? We cover return shipping.
  • Genuine Australian stock. Never grey imports. Prices include GST.
  • American Express
  • Apple Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Union Pay
  • Visa

See all FAQs →

In stock

§ 01Overview

What the KIT-DH-LR1002-1ET/LR1002-1EC is

The Dahua KIT-DH-LR1002-1ET/LR1002-1EC pairs the LR1002-1ET and LR1002-1EC Ethernet over coax units. Each has an Ethernet connection and a BNC connector.

Dahua specifies 100 Mbps up to 400 m or 10 Mbps up to 1,000 m over RG59 when its cable resistance conditions are met.

The system supports long-range power transmission over coax. Check the power budget and 48 V passive PoE compatibility before installation.

§ 02Engineering

KIT-DH-LR1002-1ET/LR1002-1EC specifications

Product pair: LR1002-1ET and LR1002-1EC Ethernet over coax extenders
Ports: One 10/100 Mbps Ethernet port and one BNC port on each unit
Bandwidth over RG59: 100 Mbps to 400 m; 10 Mbps to 1,000 m
Power over coax: Supports long-range power transmission over coaxial cable
PoE protocol: 48 V passive PoE; confirm connected equipment compatibility
Operating temperature: -30 to 65 °C

§ 03Full datasheet

Detailed specifications

Specification

Specification — Dahua KIT-DH-LR1002-1ET/LR1002-1EC EoC Pair
FeatureDetail
Product pair LR1002-1ET and LR1002-1EC Ethernet over coax extenders
Ports One 10/100 Mbps Ethernet port and one BNC port on each unit
Bandwidth over RG59 100 Mbps to 400 m; 10 Mbps to 1,000 m
Power over coax Supports long-range power transmission over coaxial cable
PoE protocol 48 V passive PoE; confirm connected equipment compatibility
Operating temperature -30 to 65 °C

§ 08Questions

Frequently asked about the KIT-DH-LR1002-1ET/LR1002-1EC

Q.01

Can the LR1002 pair reuse RG59 coaxial cable?
Yes. Dahua lists 100 Mbps to 400 m and 10 Mbps to 1,000 m over RG59 under its specified cable conditions. Check cable resistance and the power budget for the installation.
