Dahua TiOC Cameras

5MP TiOC active-deterrence dome with smart dual illumination, two-way audio and red-blue strobe, combining full-colour night vision with a built-in siren to warn off intruders.

• 5MP 1/2.7" CMOS, 2960 x 1668, 120dB WDR
• Smart dual light: IR to 50m and warm light to 40m
• Full-colour night vision when a target is detected
• Active deterrence: red-blue strobe and built-in siren with voice messages
• Built-in dual microphone and speaker for two-way talk
• SMD 4.0 and perimeter protection with human and vehicle detection
• Motorised 2.7-13.5mm lens; IP67 and IK10; 12V DC or PoE

5MP TiOC active-deterrence full-colour eyeball that combines 24/7 colour imaging, AI human and vehicle detection and a built-in light and siren deterrent.

• 1/2.7" 5MP CMOS, fixed 2.8mm lens, F1.0
• Smart Dual Illumination: IR up to 30m and warm light up to 30m
• Full-colour night imaging with warm light
• Active deterrence: red and blue strobe plus 110dB speaker
• Two-way audio with built-in microphone and speaker
• AI perimeter protection with human and vehicle classification
• IP67 weatherproof housing
• PoE or 12V DC; microSD up to 256GB

5MP TiOC 2.0 fixed full-colour bullet with active deterrence, two-way audio and AI human and vehicle detection for proactive outdoor protection.

• 1/2.7" 5MP CMOS, 2592 x 1944
• Fixed 2.8mm lens, F1.0
• Warm-light full-colour night vision up to 40m
• Active deterrence: red and blue strobe plus speaker with siren and voice alerts
• Two-way audio with built-in dual microphone array and speaker
• SMD 3.0 and perimeter protection with human and vehicle classification
• IP67 metal housing; PoE or 12V DC; microSD up to 256GB

- Previous-generation 8MP TiOC turret in a black housing — red and blue lights plus siren and voice warnings.
- 8MP F1.0 sensor, colour rated to 0.004 lux, with 30m IR and 30m warm light.
- SMD 3.0 human/vehicle filtering and one-tap disarming via the DMSS app.
- PoE powered (802.3af) — works with any current Dahua PoE NVR.

5MP TiOC 2.0 motorised bullet that combines full-colour night vision, AI human and vehicle detection and an active light-and-sound deterrent.

• 1/2.7" 5MP CMOS, up to 2960 x 1668
• Motorised 2.7-13.5mm varifocal lens, F1.0
• Smart Dual Illumination: IR up to 50m and warm light up to 40m
• Full-colour night imaging with warm light
• Active deterrence: red and blue strobe plus 110dB speaker
• Two-way audio with built-in dual microphone array and speaker
• SMD 3.0 and perimeter protection with human and vehicle classification
• IP67 metal and plastic housing; PoE or 12V DC; microSD up to 256GB

- Entry path into 8MP TiOC deterrence — red and blue lights plus siren and voice warnings.
- 8MP F1.0 sensor, colour rated to 0.004 lux, with 30m IR and 30m warm light.
- SMD 3.0 human/vehicle filtering and one-tap disarming via the DMSS app.
- PoE powered (802.3af) — works with any current Dahua PoE NVR.

- The HDW3849 S2 TiOC in a black housing — same 8MP F1.0 sensor, colour rated to 0.004 lux.
- Active deterrence: red and blue lights plus siren and voice warnings when a zone is crossed.
- Smart Dual Illuminators: 30m IR everyday, warm light full-colour event capture.
- AcuPick support, SMD 4.0, two-way talk and one-tap disarming in the DMSS app.
- PoE powered (802.3af) — drops straight into a 4, 8 or 16 channel Dahua NVR.

The Dahua DH-IPC-HFW3649T1-AS-PV-ANZ is a 6 MP TiOC 2.0 active-deterrence bullet camera that does more than record. When it detects a person or vehicle it answers back with red and blue flashing strobes and an audible siren, while dual illumination keeps the footage in full colour at night. It pairs SMD 4.0 human and vehicle classification with two-way audio and an IP67 housing for exposed outdoor positions.

Key points
- 6 MP (3200 x 1800) 1/2.7" CMOS, fixed 2.8 mm wide lens
- Active deterrence: red and blue strobe lights plus a built-in siren
- Full-colour night vision: 30 m warm light plus 30 m infrared
- Two-way audio: built-in microphone and speaker
- SMD 4.0 human and vehicle classification to cut false alarms
- 120 dB WDR; IP67 weatherproof; microSD up to 256 GB
- Powered by PoE (802.3af) or 12 VDC
