6MP Hikvision Colorvu 3.0 HYBRID CCTV Kit: 4 x Liveguard Cameras + 4CH M Series NVR / 4TB
Skip to product information
1
/
of
1
Vendor:
Hikvision
6MP Hikvision Colorvu 3.0 HYBRID CCTV Kit: 4 x Liveguard Cameras + 4CH M Series NVR / 4TB
SKU: DS-2CD2367G3-LIS2UY/SL
Description
4 x 6MP Hikvision Smart Hybrid Light ColorVu Turret Cameras
Model: DS-2CD2367G3-LIS2UY/SL
Specs: 6MP ColorVu 3.0 Smart Hybrid Light Strobe Speaker 2-Way Audio 2.8mm or 4mm Fixed Lens
1 x 4CH PoE NVR (4TB HDD)
Model: DS-7604NI-M1-4P
Specs: 4 PoE Ports GUI 4.0 Up to 128Mbps Bandwidth HDMI/VGA Output
Regular price
$1,776.85 AUD
Sale price
$1,776.85 AUD
Regular price
$2,554.00 AUD
Sale
30.43%
$777.15 AUD
(30.43%)
inc GST + 3 Year Warranty & Support
Free shipping over AUD300
In stock
6MP Hikvision Colorvu 3.0 HYBRID CCTV Kit: 4 x Liveguard Cameras + 4CH M Series NVR / 4TB
1
/
of
1
Customize this kit Kit price $1,776.85
This kit includes:
- 4 × Hikvision DS-2CD2367G3-LIS2UY/SL 6MP Smart Hybrid Light ColorVu 3.0 Gen 3 Turret Camera With Strobe / Speaker
- 1 × Hikvision DS-7604NI-M1/4P 4ch M-Series PoE NVR, 40Mbps, H.265, 4 PnP Ports, 1 HDD Bay, 4TB (4ch)
- 1 × 4TB HDD – WD Purple / Seagate Surveillance HDD for DVRs & NVRs (4TB)
3-Year Warranty
Warranty on all cameras
Free Shipping
On orders over $300
30-Day Returns
Easy returns for unopened items
Fast Delivery
5-10 Day Delivery Australia-wide
§ 01Overview
What this product is
This Hikvision 4-camera Smart Hybrid Light kit features the DS-2CD2367G3-LIS2UY/SL cameras with 6MP resolution ColorVu 3.0 technology for vivid full-color imaging in ultra-low light conditions and Smart Hybrid Light optimization
It integrates active deterrence with built-in strobe and speaker alerts AcuSense 3.0 intelligence for human and vehicle classification and plug-and-play setup
§ 02Engineering
Technical specifications
- 6MP Resolution: Features 3072x2048 resolution for excellent image clarity and low-light performance
- ColorVu 3.0 Imaging: Utilizes F1.0 lens and Super Confocal sensor to capture vivid full-color detail in ultra-low light conditions
- Smart Hybrid Light: Automatically toggles between IR and white light based on scene activity for optimal visibility only when needed
- Active Deterrence: Built-in strobe and speaker warn intruders proactively with real-time alerts
- ColorVu 3.0 Imaging: Utilizes F1.0 lens and Super Confocal sensor to capture vivid full-color detail in ultra-low light conditions
- Smart Hybrid Light: Automatically toggles between IR and white light based on scene activity for optimal visibility only when needed
- Active Deterrence: Built-in strobe and speaker warn intruders proactively with real-time alerts
§ 03Full datasheet
Detailed specifications
Camera & Image
| Feature | Detail |
|---|---|
| Image Sensor | 1/1.8" Progressive Scan CMOS |
| Max. Resolution | 3200 × 1800 |
| Min. Illumination | Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light |
| Shutter Time | 1 s to 1/100,000 s |
| Day & Night | IR cut filter |
| Image Enhancement | BLC, HLC, 3D DNR, Distortion Correction, Defog |
| SNR | ≥ 52 dB |
| Wide Dynamic Range (WDR) | 130 dB |
| Image Stabilization | EIS |
| Image Parameters Switch | Yes |
| Image Settings | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser |
| Day/Night Switch | Day, Night, Auto, Schedule |
| Privacy Mask | 4 programmable polygon privacy masks |
Lens & Distance
| Feature | Detail |
|---|---|
| Lens Type | Fixed focal lens, 2.8 and 4 mm optional |
| Focal Length & FOV | 2.8 mm, horizontal FOV 108.8°, vertical FOV 56.4°, diagonal FOV 134.3° | 4 mm, horizontal FOV 93.3°, vertical FOV 47.2°, diagonal FOV 114.2° |
| Lens Mount | M16 |
| Iris Type | Fixed |
| Aperture | F1.0 |
| Depth of Field | 2.8 mm: 3.3 m to ∞ | 4 mm: 3.8 m to ∞ |
| DORI | 2.8 mm: D: 89 m, O: 35 m, R: 17 m, I: 8 m | 4 mm: D: 109 m, O: 43 m, R: 21 m, I: 10 m |
| Pan Range | 0° to 360° |
| Tilt Range | 0° to 75° |
| Rotation Range | 0° to 360° |
Night Vision
| Feature | Detail |
|---|---|
| Supplement Light Type | White Light, IR |
| Supplement Light Range | Up to 30 m |
| Smart Supplement Light | Yes |
| IR Wavelength | 850 nm |
Video
| Feature | Detail |
|---|---|
| Main Stream | 50 Hz: 25 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) | 60 Hz: 30 fps (3200 × 1800，2688 × 1520, 1920 × 1080, 1280 × 720) |
| Sub-Stream | 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) | 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) |
| Third Stream | 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) | 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) *Third stream is supported under certain settings. |
| Video Compression | Main stream: H.265/H.264/H.264+/H.265+, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264, *Third stream is supported under certain settings. |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| H.264 Type | Baseline Profile, Main Profile, High Profile |
| H.265 Type | Main Profile |
| Bit Rate Control | CBR, VBR |
| Scalable Video Coding (SVC) | H.264 and H.265 encoding |
| Region of Interest (ROI) | 1 fixed region for main stream |
Audio
| Feature | Detail |
|---|---|
| Audio Type | Mono sound |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
| Audio Bit Rate | 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) |
| Audio Sampling Rate | 8 kHz/16 kHz/32 kHz/48 kHz |
| Environment Noise Filtering | Yes |
AI & Deep Learning
| Feature | Detail |
|---|---|
| Face Capture | Yes |
| Perimeter Protection | Line crossing, intrusion, region entrance, region exiting; Support alarm triggering by specified target types (human and vehicle) |
Network & Storage
| Feature | Detail |
|---|---|
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP |
| Simultaneous Live View | Up to 6 channels |
| API | ONVIF (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP |
| User/Host | Up to 32 users; 3 user levels: administrator, operator, and user |
| Security | Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address) |
| Network Storage | NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR) |
| Client | iVMS-4200, Hik-Connect, Hik-Central |
| Web Browser | Plug-in free live view: Chrome 80+, Firefox 80+, Edge 89+, Local service: Chrome 80+, Firefox 80+, Edge 89+ |
Event & Alarm
| Feature | Detail |
|---|---|
| Basic Event | Motion detection (support alarm triggering by specified target types (human and vehicle)), video tampering alarm, exception |
| Smart Event | Scene change detection |
| Linkage | Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture, audible warning, strobe light flashing |
Interface
| Feature | Detail |
|---|---|
| Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
| On-Board Storage | Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB |
| Built-in Speaker | Max. power consumption: 2 W, max. sound pressure level: 10 cm: 110 dB. |
| Built-in Microphone | Arrayed dual-microphone |
| Audio | 1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium | 1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium |
| Alarm | 1 input, 1 output (max. 24 VDC/24 VAC, 1 A) |
| Reset Key | Yes |
General & Environment
| Feature | Detail |
|---|---|
| Power | 12 VDC ± 25%, 1.29 A, max. 15.5 W, Ø 5.5 mm coaxial power plug, reverse polarity protection, PoE: IEEE 802.3at, Class 4, max. 17 W |
| Material | Cover: metal, main body: metal |
| Dimension | Ø138.3 mm × 115.4 mm (Ø5.4" × 4.5") |
| Package Dimension | 170 mm × 170 mm × 160 mm (6.7" × 6.7" × 6.3") |
| Weight | Approx. 820 g (1.8 lb.) |
| With Package Weight | Approx. 1200 g (2.6 lb.) |
| Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Startup and Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| General Function | Heartbeat, mirror, flash log, password reset via email, pixel counter, anti-banding |
| Language | 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| EMC | CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7, KC: KN32: 2015, KN35: 2015 |
| Safety | UL: UL 62368-1, CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017 |
| Environment | CE-RoHS: 2011/65/EU |
| Protection | IP67: IEC 60529-2013 |
| Anti-Corrosion Protection | NEMA 4X (NEMA 250-2018) |
§ 04Why choose this
Built for the way you actually use it
130dB Wide Dynamic Range Excels in Harsh Light
Outperforms competitors with widest tonal range at this price point, capturing detail in both bright sunlight and dark shadows simultaneously across Australian properties.
NEMA 4X Anti-Corrosion for Coastal Australia
Specifically engineered for properties within 2 kilometres of coastlines with anti-corrosion coating, preventing failure in salt air and high-humidity tropical conditions.
AcuSense AI Distinguishes Humans from Vehicles
Reduces notification fatigue with 99% accuracy in optimal conditions, filtering out pets, foliage, and passing cars for meaningful alerts only.
§ 05Where it fits
Right at home in these scenarios
Front Verandah and Driveway Security
Monitor package deliveries and vehicle movements with colour night vision, capturing clothing colours and facial features for Australia Post theft prevention evidence.
Coastal Workshop and Tradies' Yards
Protect tool storage and equipment with 30-metre infrared range and NEMA 4X coating, eliminating need for always-on security lighting while maintaining licence plate visibility.
Small Retail and Café Monitoring
Cover front counter transactions, seating areas, and storage zones with 6-megapixel resolution, providing clear evidence for register discrepancies and customer safety incidents.
Quarter-Acre Suburban Perimeter Coverage
Four cameras effectively monitor typical Australian properties up to 800 square metres, covering side access points, backyard, and garage with 108.8-degree horizontal field of view.
§ 06Setup
Installation & setup
What's in the Box
1. Hikvision DS-2CD2367G3-LIS2UY/SL Camera × 4 2. Hikvision DS-7604NI-M1-4P 4CH PoE NVR (4TB HDD) × 1 3. Power Connector × 1 4. Quick Start Guide × 1
Installation Requirements
1. Power over Ethernet: Requires DS-7604NI-M1-4P NVR with built-in PoE ports, running both data and power through single Cat5e or Cat6 ethernet cable up to 90 metres. 2. Weatherproof Connections: Must use supplied cable gland with self-amalgamating tape and electrical tape on RJ45 connections to prevent water ingress and corrosion in Australian conditions. 3. Mounting Surface: Eave mounting at 2.5 to 3 metres height on brick veneer, weatherboard, or Colorbond using appropriate masonry anchors or tek screws with rubber sealing washers.
App Setup
1. Connect cameras to NVR's built-in PoE ports for automatic network detection and address assignment via DHCP server. 2. Download Hik-Connect app and enable UPnP on NBN router, then scan QR code for remote access after updating NVR firmware to latest version. 3. Configure motion detection zones and vehicle classification via web browser interface for most reliable playback, as mobile app playback functionality experiences frequent loading failures.
§ 08In motion
Meet the Hikvision's Smart Hybrid Light Camera with ColorVu
