The Dahua DH-PFA130-E is the larger, IP66-rated aluminium junction box in Dahua's range. It mounts behind turret and dome cameras to give a fully sealed cavity for the network cable and connector, with a higher 3.0 kg load rating and a G3/4 inch conduit entry for heavier or commercial installs.

Key points
- Suits Dahua turret & dome cameras (check the Accessory Selection line on your camera's datasheet)
- IP66 rated — the only box in this range with a stated weatherproof rating
- Aluminium alloy, white finish
- Ø124 mm × 41 mm, approx. 0.35 kg
- G3/4" conduit thread; 3.0 kg load rating

The Dahua DH-PFA134 is a compact, round water-proof junction box that mounts a round-base Dahua bullet camera and hides its cabling behind it. The camera fixes to the box, the cable routes inside, and the join stays sealed against weather - a small, tidy upgrade over leaving the connector exposed at the wall.

At a glance
- Compact round water-proof junction box for round-base bullet cameras
- Aluminium and SECC build, Φ90.0 x 35.0 mm, M20 (G1/2") thread
- 1.0 kg load bearing, white finish to match Dahua cameras
- Seals and conceals the cable join behind the camera
- Supplied with screws, anchors and a waterproof joint

The Dahua DH-PFA135 is a compact, round water-proof junction box that mounts a round-base Dahua bullet camera and conceals its cabling behind it. The camera fixes to the box, the cable routes inside, and the join stays sealed against the weather for a neat, protected outdoor install.

At a glance
- Compact round water-proof junction box for round-base bullet cameras
- Aluminium build, Φ90.0 x 34.1 mm, M20 (G1/2") thread
- 1.0 kg load bearing, white finish to match Dahua cameras
- Hides and seals the cable join behind the camera
- Supplied with screws, anchors and a waterproof joint

The Dahua DH-PFA136 is an aluminium junction box that mounts behind Dahua turret and eyeball cameras. It gives a sealed, tidy space to coil and protect the network cable and connector where it enters the camera. Note: some older listings describe this part as a wall mount bracket; it is a junction box that seats flat behind the camera.

Key points
- Junction box for Dahua turret & eyeball cameras (check the camera's Accessory Selection)
- Aluminium alloy, white finish
- Ø110.0 mm × 34.0 mm, approx. 0.19 kg
- M20 (G1/2") cable gland thread; 1.0 kg load rating
- Weather-resistant for outdoor mounting when the entry is sealed

The Dahua DH-PFA137 is the most widely used aluminium junction box for Dahua turret, eyeball and dome cameras. It mounts behind the camera to give a sealed, tidy space for the network cable and connector, and is the box Dahua lists under Accessory Selection for a large part of its HDW turret and eyeball range.

Key points
- Suits a wide range of Dahua turret, eyeball & dome cameras
- Aluminium alloy, white finish (black DH-PFA137-B also available)
- Ø122.0 mm × 34.2 mm, approx. 0.24 kg
- M20 (G1/2") cable gland thread; 1.0 kg load rating
- Weather-resistant for outdoor mounting when the entry is sealed

The Dahua DH-PFA139 is a compact aluminium junction box that mounts behind Dahua turret and eyeball cameras. It gives a tidy, sealed cavity to coil and protect the network cable and connector where it enters the camera, instead of leaving the join exposed on the wall.

Key points
- Suits Dahua turret & eyeball cameras (check the Accessory Selection line on your camera's datasheet)
- Aluminium alloy, white finish
- Ø108.0 mm × 28.5 mm, approx. 0.16 kg
- M20 (G1/2") cable gland thread; 1.0 kg load rating
- Designed for weather-resistant outdoor mounting when the entry is sealed

Dahua triple-clamp pole-mount bracket for PTZ/dome cameras (SECC & SUS304, 10 kg load).

The Dahua DH-PFB203W is an aluminium and steel wall mount bracket that holds a Dahua camera out from a vertical wall and conceals the cable through the arm. It angles a bullet, turret or dome camera over a door, driveway or path where there is no eave to mount under. Dahua has since released the DH-PFB204W as its near-identical replacement.

Key points
- Wall mount bracket for Dahua bullet, turret & dome cameras (check the camera's Accessory Selection)
- Aluminium & SECC steel, white finish
- 160 mm × 122 mm × 76 mm, approx. 0.5 kg
- 1.0 kg load rating; cable concealed through the bracket
- Superseded by the near-identical DH-PFB204W
