Hikvision DS-2CD2T47G2-LSU/SL 4MP Gen2 Outdoor ColorVu Bullet Camera Liveguard 60m White LED 2.8mm
SKU: DS-2CD2T47G2-LSU/SL
Description
The Hikvision DS-2CD2T47G2-LSU/SL is a 4 MP Gen 2 ColorVu bullet with active deterrence, built to stop trouble rather than just film it. It records full colour 24/7, and when AcuSense detects a person or vehicle after hours it can flash a white strobe light and play an audible warning to move them on.
Key points
- 4 MP (2688 x 1520) 1/1.8" CMOS, F1.0 ColorVu aperture
- 24/7 full colour; white supplement light up to 60 m
- White strobe light plus audible warning for active deterrence
- Built-in microphone and speaker for two-way talk
- AcuSense human and vehicle classification, 130 dB WDR
- 2.8, 4 or 6 mm lens; IP67 metal body; PoE (802.3af) or 12 VDC
Regular price
$272.55 AUD
Sale price
$272.55 AUD
Regular price
$379.00 AUD
Sale
28.09%
$106.45 AUD
(28.09%)
Member
Sign in to save $5.45 on this item — free to join.
Buying for business? Apply for trade pricing →
Building a kit or need installation? Email sales@smarket.com.au for a quote.
inc GST + 3 Year Warranty & Support
Free shipping over AUD300
In stock
No reviews
Hikvision DS-2CD2T47G2-LSU/SL 4MP Gen2 Outdoor ColorVu Bullet Camera Liveguard 60m White LED 2.8mm
1
/
of
1
Build your setup Build a complete CCTV system Complete setup from $1,216.15
A camera needs an NVR, a hard drive, and cabling to work. Add everything below, or pick a ready-made kit.
3-Year Warranty
Warranty on all cameras
Free Shipping
On orders over $300
30-Day Returns
Easy returns for unopened items
Fast Delivery
5-10 Day Delivery Australia-wide
§ 01Overview
What the DS-2CD2T47G2-LSU/SL is
The Hikvision DS-2CD2T47G2-LSU/SL is a 4 MP ColorVu fixed bullet that records vivid colour day and night and adds an active deterrent on top.
The 1/1.8" sensor and F1.0 aperture pull in enough light to keep faces, clothing and vehicle colours visible in the dark, and a white supplement light reaches up to 60 m so the scene stays lit in colour rather than the black and white of an infrared camera.
What sets this model apart is what happens when someone should not be there.
AcuSense deep-learning analytics classify human and vehicle targets, so your rules ignore cats, rain and moving branches.
When a real person or vehicle crosses a zone you have set, the camera can flash its white strobe light and play a recorded or live audible warning, which is often enough to send an intruder off before anything happens.
A built-in microphone and speaker also let you talk to visitors or delivery drivers live through the Hik-Connect app.
This is a compact metal bullet rated IP67 for Australian conditions, with a 2.8 mm wide lens or a 4 mm or 6 mm lens for a tighter, longer view.
Power and network it over one PoE cable (802.3af) or use 12 VDC, and record it to a Hikvision AcuSense NVR so the human and vehicle events stay quick to search.
See it in action
What the DS-2CD2T47G2-LSU/SL features actually look like
Representative illustrations of how each key feature performs in a real scene.
4MP Ultra HD
4MP captures roughly twice the detail of standard 1080p.
Full Color Night Vision
Unlike plain black-and-white night vision, this camera can capture colour after dark — so you can pick out the actual colour of a car, a jacket or a bag, detail that grey infrared footage loses.
Human/Vehicle Detection
Smart detection focuses on people and vehicles and can ignore things like swaying branches, rain or small animals — helping cut down false alerts and making the right moments easier to find.
IP67 Weatherproof
Sealed against dust and water to IP67, built to keep working through rain, storms and harsh sun — suitable for fully outdoor mounting.
Two-Way Audio
Talk and listen in real time through the app — tell a courier where to leave a parcel, or speak to someone at the gate, whether you're home or away.
Illustrative — simulated for demonstration
§ 02Engineering
DS-2CD2T47G2-LSU/SL specifications
- 4 MP (2688 x 1520) 1/1.8" CMOS with F1.0 ColorVu aperture
- 24/7 full-colour imaging; white supplement light up to 60 m
- White strobe light plus audible warning on detection (active deterrence)
- Built-in microphone and speaker for two-way audio
- AcuSense deep-learning human and vehicle classification
- 130 dB WDR for high-contrast entrances and driveways
- 2.8, 4 or 6 mm fixed lens; H.265+ compression; microSD up to 512 GB
- IP67 weatherproof metal bullet; PoE (802.3af) or 12 VDC
- 24/7 full-colour imaging; white supplement light up to 60 m
- White strobe light plus audible warning on detection (active deterrence)
- Built-in microphone and speaker for two-way audio
- AcuSense deep-learning human and vehicle classification
- 130 dB WDR for high-contrast entrances and driveways
- 2.8, 4 or 6 mm fixed lens; H.265+ compression; microSD up to 512 GB
- IP67 weatherproof metal bullet; PoE (802.3af) or 12 VDC
§ 03Full datasheet
Detailed specifications
Camera & Image
| Feature | Detail |
|---|---|
| Image Sensor | 1/1.8" Progressive Scan CMOS |
| Max. Resolution | 2688 × 1520 |
| Min. Illumination | Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light |
| Shutter Speed | 1/3 s to 1/100,000 s |
| Slow Shutter | Yes |
| Wide Dynamic Range | 130 dB |
| Image Parameters Switch | Yes |
| Image Settings | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser |
| Day/Night Switch | Auto, Schedule |
| SNR | ≥ 52 dB |
| Image Enhancement | BLC, HLC, 3D DNR |
Lens & Distance
| Feature | Detail |
|---|---|
| Focal Length & FOV | 2.8 mm, horizontal FOV 111.9°, vertical FOV 60.5°, diagonal FOV 133.6° | 4 mm, horizontal FOV 95.2°, vertical FOV 50.6°, diagonal FOV 114.7° | 6 mm, horizontal FOV 58.4°, vertical FOV 31°, diagonal FOV 68.7° |
| Lens Mount | M16 |
| Aperture | F1.0 |
| Depth of Field | 2.8 mm: 3.1 m to ∞ | 4 mm: 5.4 m to ∞ | 6 mm: 12.1 m to ∞ |
| DORI | 2.8 mm, D: 58.2 m, O: 23.1 m, R: 11.6 m, I: 5.8 m | 4 mm, D: 77 m, O: 30.5 m, R: 15.4 m, I: 7.7 m | 6 mm, D: 115.6 m, O: 45.9 m, R: 23.1 m, I: 11.6 m |
| Pan Range | 0° to 360° |
| Tilt Range | 0° to 90° |
| Rotation Range | 0° to 360° |
Night Vision
| Feature | Detail |
|---|---|
| Smart Supplement Light | Yes |
| White Light Range | Up to 60 m |
| Visual Alarm | Yes |
Video
| Feature | Detail |
|---|---|
| Main Stream | 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) | 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720) |
| Sub-Stream | 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) | 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) |
| Third Stream | 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) | 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360); *Third stream is supported under certain settings. |
| Video Compression | Main stream: H.265/H.264/H.265+/H.264+; Sub-stream: H.265/H.264/MJPEG; Third stream: H.265/H.264; *Third stream is supported under certain settings. |
| Video Bit Rate | 32 Kbps to 8 Mbps |
| H.264 Type | Baseline Profile/Main Profile/High Profile |
| H.265 Type | Main Profile |
| H.264+ | Main stream supports |
| H.265+ | Main stream supports |
| Bit Rate Control | CBR/VBR |
| Scalable Video Coding (SVC) | H.265 and H.264 encoding |
| Region of Interest (ROI) | 1 fixed region for main stream and sub-stream |
Audio
| Feature | Detail |
|---|---|
| Audio Compression | G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
| Audio Bit Rate | 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) |
| Audio Sampling Rate | 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Environment Noise Filtering | Yes |
AI & Deep Learning
| Feature | Detail |
|---|---|
| Face Capture | Yes |
| Perimeter Protection | Line crossing detection, intrusion detection, region entrance detection, region exiting detection. Supports human and vehicle targets classification |
Network & Storage
| Feature | Detail |
|---|---|
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket, WebSockets |
| Simultaneous Live View | Up to 6 channels |
| API | Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK |
| User/Host | Up to 32 users. 3 user levels: administrator, operator and user |
| Security | Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface |
| Network Storage | NAS (NFS, SMB/CIFS), auto network replenishment (ANR), MicroSD/SDHC/SDXC card (512 GB) local storage. Together with high-end Hikvision memory card, memory card encryption and health detection are supported |
| Client | iVMS-4200, Hik-Connect, Hik-Central |
| Web Browser | Plug-in required live view: IE 10, IE 11; Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+; Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+ |
Event & Alarm
| Feature | Detail |
|---|---|
| Basic Event | Motion detection (human and vehicle targets classification), video tampering alarm, exception |
| Smart Event | Scene change detection |
| Linkage Method | Upload to NAS/memory card/FTP, notify surveillance center, trigger recording, trigger capture, send email, strobe light, audible warning, trigger alarm output |
Interface
| Feature | Detail |
|---|---|
| Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
| On-Board Storage | Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB |
| Built-in Microphone | Yes |
| Built-in Speaker | 2 W, 10 cm: 97 dB |
| Audio Input | 1 input (line in), two-core terminal block , max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium |
| Audio Output | 1 output (line out),two-core terminal block , max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium |
| Alarm | NA |
| Reset Key | Yes |
General & Environment
| Feature | Detail |
|---|---|
| Material | Aluminum alloy body |
| Dimension | 289.5 mm × Ø 105 mm (11.4"× Ø 4.1") |
| Package Dimension | 386 mm × 156 mm × 155 mm (15.2" × 6.1" × 6.1") |
| Weight | Approx. 1165 g (2.6 lb.) |
| With Package Weight | Approx. 1639 g (3.6 lb.) |
| Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Startup and Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Language | 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| General Function | Anti-flicker, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter |
| Firmware Version | V5.5.114 |
| Software Reset | Yes |
| Power Consumption and Current | 12 VDC, 0.67 A, max. 8 W; PoE (802.3af, 36 V to 57 V), 0.25 A to 0.16 A, max. 9 W |
| Power Supply | 12 VDC ± 25%, reverse polarity protection; PoE: 802.3af, Class 3 |
| Power Interface | Ø 5.5 mm coaxial power plug |
| EMC | FCC SDoC: 47 CFR Part 15, Subpart B; CE-EMC: EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014; RCM: AS/NZS CISPR 32: 2015; IC VoC: ICES-003: Issue 6, 2016; KC: KN 32: 2015, KN 35: 2015 |
| Safety | UL: UL 60950-1; CB: IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014; CE-LVD: EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014; LOA: IEC/EN 60950-1 |
| Environment | CE-RoHS: 2011/65/EU; WEEE: 2012/19/EU; Reach: Regulation (EC) No 1907/2006 |
| Protection | IP67: IEC 60529-2013 |
§ 04Why choose this
Built for the way you actually use the DS-2CD2T47G2-LSU/SL
Full colour around the clock
ColorVu with an F1.0 aperture and a 60 m white light keeps faces and vehicle colours visible at night.
Alerts that matter
AcuSense human and vehicle classification keeps motion and perimeter alarms focused on people and cars.
Two-way talk built in
A microphone and speaker let you greet visitors or warn off loiterers from your phone.
§ 05Where it fits
Right at home in these scenarios
Home entrances and driveways
Light the area in colour, talk to visitors, and let the strobe and siren deter anyone loitering after dark.
Shopfronts after hours
Warn off people at the door once you have closed while keeping clear colour evidence of who was there.
Side gates and boundaries
Use the 4 mm or 6 mm lens down a fence line and let AcuSense flag people rather than passing animals.
Small business yards
Keep colour footage and human or vehicle events that are quick to review the next morning.
§ 06Setup
Installation & setup
What's in the box
One DS-2CD2T47G2-LSU/SL bullet camera with a mounting template, fixings and a quick guide. The PoE switch or NVR, network cable, microSD card and any junction box are supplied separately.
Installation requirements
Mount it on a wall or eave overlooking the area you want to cover and run one network cable back to a PoE switch or NVR, or use a 12 VDC supply. Set the lighting, audio warning and AcuSense rules in the software, and add it to a Hikvision AcuSense NVR for recording and event search.
§ 07Questions
Frequently asked about the DS-2CD2T47G2-LSU/SL
Q.01
Does the DS-2CD2T47G2-LSU/SL record in colour at night?
Yes. It is a ColorVu camera, so a large F1.0 aperture and a white supplement light up to 60 m keep footage in full colour around the clock. The night image is lit in colour rather than the black and white of an infrared camera.
Q.02
How does the strobe and audible warning work?
When AcuSense detects a person or vehicle in a zone you have set, the camera can flash its white strobe light and play an audible warning. You choose whether the alarm triggers, what it plays and during which hours, so it deters intruders after closing time without disturbing visitors during the day.
Q.03
Can I talk through the camera?
Yes. It has a built-in microphone and a built-in speaker, so it supports two-way audio. You can listen to the scene and speak to a visitor or delivery driver live through the Hik-Connect app or a compatible NVR.
Q.04
What is the difference between this and the DS-2CD2T47G2-L?
The imaging, lens options and AcuSense are the same. This LSU/SL model adds the active strobe light, the audible warning and the built-in two-way audio, so it can actively warn people off rather than only record them.
Q.05
Is the white light on all the time?
By default the camera keeps a low level of white light so it can hold colour at night, and the brighter strobe only fires on a detection. You can switch the supplement light between always-on, smart and schedule modes to suit how bright you want the area.
Q.06
How does it cut down false alarms?
AcuSense deep-learning analytics classify human and vehicle targets, so motion, line-crossing and intrusion events trigger on people and cars and skip animals, rain and swaying plants. That keeps notifications meaningful and the strobe and siren reserved for real events.
Q.07
Can I power it with PoE?
Yes. It runs on standard PoE (802.3af, Class 3) over a single network cable from a PoE switch or PoE NVR, or on 12 VDC if you prefer a separate plug pack.
Q.08
Does it need a Hikvision NVR?
It works with ONVIF recorders, but the AcuSense search, smart events, two-way audio and easiest setup are at their best with a Hikvision AcuSense NVR. For the full feature set, pair it with a matching Hikvision recorder.
§ 09Bundles
Recommended packages
Record and search it
Connect it to a Hikvision AcuSense recorder such as the 8-channel DS-7608NI-I2/8P NVR, or the larger 16-channel DS-7732NXI-I4/16P, so human and vehicle events stay quick to find. Add a surveillance-grade drive like the 6 TB for weeks of continuous footage.
Power it over one cable
Run a single network cable per camera from a PoE source. The HiLook 8-port PoE switch feeds several cameras and the recorder, keeping the cabling tidy on multi-camera sites.
Mount and match cameras
A DS-1280ZJ-S junction box keeps the cabling tidy behind the camera. Pair it with the mic-free DS-2CD2T47G2-L bullet for spots that do not need the strobe, so the colour and analytics stay consistent across the site.
