Hikvision iDS-2CD7A46G2-P-IZHSY 4MP DeepinView ANPR Bullet Camera 8–32mm — 100m IR, 150dB WDR, IP67/IK10

SKU: iDS-2CD7A46G2-P-IZHSY-8-32MM
Description

- 4MP DeepinView ANPR With 8–32mm Motorised Lens: 1/1.8″ CMOS sensor delivers 2688×1520 resolution across a 42.5°–15.2° horizontal field of view, capturing plates at distance with motorised autofocus for remote adjustment without physical access to the housing.
- 100m IR With 150dB Adaptive WDR: Smart IR illumination reaches 100m for long-range night capture, while 150dB AWDR preserves detail in high-contrast scenes such as tunnel exits or direct headlight conditions at entry lanes.
- DarkFighter 2.0 Low-Light With Built-In Heater: Colour minimum illumination of 0.0005 lux ensures usable images in near-darkness. A built-in heater activates automatically in cold or damp environments, maintaining reliable operation from –40°C to +60°C.
- IP67/IK10 Metal Housing With G-Sensor: Sealed metal body rated IP67 weatherproof and IK10 vandal-resistant, with an integrated G-sensor that detects vibration or impact and triggers tampering alarms for pole-mounted or exposed installations.
$1,371.60 AUD $1,371.60 AUD $1,627.00 AUD
Sale 15.7% $255.40 AUD (15.7%)
Member Sign in to save $27.43 on this item — free to join.
Buying for business? Apply for trade pricing →
Building a kit or need installation? Email sales@smarket.com.au for a quote.

inc GST + 3 Year Warranty & Support
Free shipping over AUD300

In stock
3-Year Warranty

3-Year Warranty

Warranty on all cameras

Free Shipping

Free Shipping

On orders over $300

30-Day Returns

30-Day Returns

Easy returns for unopened items

Fast Delivery

Fast Delivery

5-10 Day Delivery Australia-wide

§ 01Overview

What the iDS-2CD7A46G2-P-IZHSY-8-32MM is

The Hikvision iDS-2CD7A46G2-P-IZHS(Y) (8–32 mm variant) is a professional DeepinView AI bullet camera designed for advanced analytics and licence-plate recognition (ANPR).

Equipped with a 4 MP 1/1.8″ CMOS sensor, it delivers exceptional clarity across all lighting conditions.

The 8–32 mm motorised varifocal lens allows precise adjustment for long-range or mid-range viewing, making it suitable for capturing vehicle plates and identifying objects from distance.

With DarkFighter 2.0 low-light imaging and 150 dB Adaptive WDR, it provides sharp, detailed images even in challenging environments such as tunnel exits or bright headlight conditions.

The built-in heater, G-sensor for vibration detection, and power-meter enhance durability and diagnostic capability, while the IP67 and IK10 housing ensures long-term reliability outdoors.

This camera excels in perimeter protection, gate access, and traffic monitoring applications that demand both precision and resilience.

§ 02Engineering

iDS-2CD7A46G2-P-IZHSY-8-32MM specifications

- 4 MP (2688 × 1520) 1/1.8″ Progressive Scan CMOS sensor
- Motorised varifocal lens: 8–32 mm, P-iris, 42.5°–15.2° horizontal FOV
- DarkFighter 2.0 low-light: colour 0.0005 lux, B/W 0.0001 lux minimum illumination
- 150 dB Adaptive Wide Dynamic Range (AWDR)
- IR illumination up to 100 m (8–32 mm lens variant)
- Up to 5 configurable video streams (H.265+, H.265, H.264+, H.264)
- Built-in heater, G-sensor vibration detection, and power-meter
- IP67 weatherproof and IK10 vandal-resistant metal housing
- Human/vehicle classification and on-board ANPR
- –40 °C to +60 °C operating temperature range

§ 04Why choose this

Built for the way you actually use the iDS-2CD7A46G2-P-IZHSY-8-32MM

Long-Range ANPR Without a Separate Server

The 8–32mm motorised lens paired with on-board DeepinView AI delivers licence plate reads from 10m to 100m, eliminating the need for a separate ANPR processing unit at single-lane entry points. The P-iris maintains optimal aperture across the zoom range.

DarkFighter 2.0 for Low-Light Plate Capture

DarkFighter 2.0 with 0.0005 lux colour sensitivity combined with 150dB AWDR keeps plates readable in near-darkness and in high-contrast conditions — tunnel exits, headlight glare, and dawn/dusk transitions where standard sensors fail.

Built to Run Unattended in Harsh Weather

The built-in heater activates automatically in cold or damp conditions, and the IP67/IK10 metal housing withstands direct outdoor exposure. The G-sensor triggers alerts if the camera is struck or moved, making it suitable for remote gate installations.

Flexible Streaming for Multi-System Sites

With up to 5 simultaneous streams and H.265+ compression, the camera feeds live view, recording, ANPR analytics, and mobile access simultaneously, reducing the camera count and bandwidth load for multi-purpose vehicle monitoring points.

§ 05Where it fits

Right at home in these scenarios

Vehicle Access Control at Gates and Boom Barriers

The 8–32mm lens captures plates at distances from 10m to 100m, suiting boom gate approaches, long driveways, and single-lane access points where the camera must be mounted well back from the vehicle stop line.

Car Park Entry and Exit Monitoring

On-board ANPR and vehicle classification allow the camera to log plate and vehicle type data at entry and exit lanes, feeding permit-based access rules or billing systems without requiring a separate ANPR server.

Perimeter Security With AI Event Filtering

Human/vehicle classification reduces false alarms at perimeter fence lines by suppressing motion events from animals, vegetation, and shadows, while still flagging vehicle approaches and pedestrian intrusions.

Industrial Site Traffic Monitoring

The –40°C to +60°C operating range and IP67/IK10 rating support year-round deployment at mine entries, freight yards, and processing facilities where vehicle logging and access auditing are required.

§ 06Setup

Installation & setup

01

Power Over Ethernet With Heater Load Planning

Powered via IEEE 802.3af PoE or 12 V DC. Confirm the PoE switch or injector can deliver adequate power when the built-in heater is active, particularly for installations in cold climate zones where the heater may run for extended periods.

02

Lens Adjustment and Focus

The 8–32mm motorised varifocal lens supports remote zoom and focus adjustment through the camera web interface or iVMS-8600. Set the zoom to frame the target lane width at the plate capture point, then lock focus using the auto-focus routine before commissioning.

03

IR Placement and Reflection Management

Position the camera so the IR beam path does not intersect nearby walls, poles, or reflective signs within 2 metres, as backscatter will overexpose the plate zone and degrade night reads. Use the live view in B/W mode at night to verify even illumination across the lane.

04

Cabling and Surge Protection

Use shielded Cat6 cable with surge protection for outdoor Ethernet runs. Seal all conduit and cable entry points with weatherproof glands to preserve the IP67 rating. For pole-mounted installations, verify the mounting bracket is rated for the combined weight of the camera and junction box under local wind conditions.

§ 07Questions

Frequently asked about the iDS-2CD7A46G2-P-IZHSY-8-32MM

Q.01

Q: What is the advantage of the 8–32 mm lens over the 2.8–12 mm variant?
A: The 8–32 mm lens offers long-range zoom flexibility for capturing vehicle plates at distances from approximately 10 m to 100 m, while the 2.8–12 mm variant suits shorter-range or wider-lane installations. Choose based on your camera-to-plate distance and lane width.
Q.02

Q: Can it perform licence-plate recognition (ANPR) without a separate server?
A: Yes. The DeepinView series includes built-in AI analytics that detect and recognise vehicle plates and classify vehicles by type directly on the camera, though a management platform such as iVMS-8600 is recommended for event search and database management.
Q.03

Q: Does it work in low-light or nighttime conditions?
A: Yes. DarkFighter 2.0 imaging delivers colour detail at 0.0005 lux minimum illumination, and the 100m smart IR provides B/W coverage for plate reads in near-total darkness.
Q.04

Q: Is it weather-resistant for outdoor use?
A: Yes. The IP67 and IK10-rated metal housing protects against dust, rain, and vandal impact across an operating range of –40°C to +60°C. The built-in heater prevents condensation and icing in cold or damp environments.
Q.05

Q: What is the IR distance on this model?
A: Approximately 100 m in optimal conditions for the 8–32 mm lens version. The smart IR adjusts intensity automatically to avoid overexposing plates at closer ranges.
Q.06

Q: How does the G-sensor help?
A: It detects vibration or impact and can trigger alarms if the camera is tampered with or moved, providing an additional layer of security for pole-mounted or exposed installations.
Q.07

Q: Can it detect humans as well as vehicles?
A: Yes. The DeepinView AI analytics distinguish between people and vehicles to minimise false alarms and support perimeter protection alongside vehicle monitoring.
Q.08

Q: How many simultaneous video streams does it support?
A: Up to five simultaneous streams for live viewing, recording, analytics, and mobile access.
Q.09

Q: Does it include a heater?
A: Yes. A built-in heater activates automatically in cold or high-humidity environments to prevent internal condensation.
Q.10

Q: What are typical applications for this camera?
A: Car park entries, gated driveways, warehouse entrances, perimeter security, and traffic monitoring where reliable plate and object capture is required at medium to long range.
