Hikvision iDS-2CD7A46G2-P-IZHSY 4MP DeepinView ANPR Bullet Camera 8–32mm — 100m IR, 150dB WDR, IP67/IK10
Skip to product information
1
/
of
1
Vendor:
Hikvision
Hikvision iDS-2CD7A46G2-P-IZHSY 4MP DeepinView ANPR Bullet Camera 8–32mm — 100m IR, 150dB WDR, IP67/IK10
SKU: iDS-2CD7A46G2-P-IZHSY-8-32MM
Description
- 4MP DeepinView ANPR With 8–32mm Motorised Lens: 1/1.8″ CMOS sensor delivers 2688×1520 resolution across a 42.5°–15.2° horizontal field of view, capturing plates at distance with motorised autofocus for remote adjustment without physical access to the housing.
- 100m IR With 150dB Adaptive WDR: Smart IR illumination reaches 100m for long-range night capture, while 150dB AWDR preserves detail in high-contrast scenes such as tunnel exits or direct headlight conditions at entry lanes.
- DarkFighter 2.0 Low-Light With Built-In Heater: Colour minimum illumination of 0.0005 lux ensures usable images in near-darkness. A built-in heater activates automatically in cold or damp environments, maintaining reliable operation from –40°C to +60°C.
- IP67/IK10 Metal Housing With G-Sensor: Sealed metal body rated IP67 weatherproof and IK10 vandal-resistant, with an integrated G-sensor that detects vibration or impact and triggers tampering alarms for pole-mounted or exposed installations.
Regular price
$1,371.60 AUD
Sale price
$1,371.60 AUD
Regular price
$1,627.00 AUD
Sale
15.7%
$255.40 AUD
(15.7%)
Business or bulk buyer? Apply for trade pricing →
Found a lower price? We’ll match it →
Delivery, warranty & returns · ships same day before 2pm
- Same-day dispatch on in-stock orders placed before 2pm, Sydney time.
- 1–4 business days Australia-wide. Free standard shipping over $300, flat $25 under.
- 3-year warranty on cameras and recorders, back-to-base, plus your Australian Consumer Law rights.
- 30-day returns on unopened items. Faulty on arrival? We cover return shipping.
- Genuine Australian stock. Never grey imports. Prices include GST.
In stock
No reviews
Hikvision iDS-2CD7A46G2-P-IZHSY 4MP DeepinView ANPR Bullet Camera 8–32mm — 100m IR, 150dB WDR, IP67/IK10
1
/
of
1
All cameras, NVRs and DVRs come with a 3-year back-to-base manufacturer warranty covering defects in materials and workmanship, in addition to your rights under Australian Consumer Law. Hard drives and accessories are covered as set out in our Warranty Policy.
Standard shipping is free on all orders over $300 AUD, Australia-wide. Orders under $300 ship at a flat rate of $25, calculated at checkout. Tracking is included on every order.
You have 30 days from the day you receive your order to request a change-of-mind return. Items must be unopened, factory-sealed and in resalable condition. A 15% restocking fee applies and return postage is at your cost. Faulty or incorrectly supplied items are different: we cover the return shipping and refund or replace at no charge. Read the full Return & Refund Policy.
Order before 2pm (Sydney time) on a business day and in-stock items are dispatched the same day. Most orders arrive within 1–4 business days Australia-wide; remote and regional areas can take a little longer. You'll receive a tracking number by email as soon as your order leaves the warehouse.
§ 01Overview
What the iDS-2CD7A46G2-P-IZHSY-8-32MM is
The Hikvision iDS-2CD7A46G2-P-IZHS(Y) (8–32 mm variant) is a professional DeepinView AI bullet camera designed for advanced analytics and licence-plate recognition (ANPR).
Equipped with a 4 MP 1/1.8″ CMOS sensor, it delivers exceptional clarity across all lighting conditions.
The 8–32 mm motorised varifocal lens allows precise adjustment for long-range or mid-range viewing, making it suitable for capturing vehicle plates and identifying objects from distance.
With DarkFighter 2.0 low-light imaging and 150 dB Adaptive WDR, it provides sharp, detailed images even in challenging environments such as tunnel exits or bright headlight conditions.
The built-in heater, G-sensor for vibration detection, and power-meter enhance durability and diagnostic capability, while the IP67 and IK10 housing ensures long-term reliability outdoors.
This camera excels in perimeter protection, gate access, and traffic monitoring applications that demand both precision and resilience.
§ 02Engineering
iDS-2CD7A46G2-P-IZHSY-8-32MM specifications
- 4 MP (2688 × 1520) 1/1.8″ Progressive Scan CMOS sensor
- Motorised varifocal lens: 8–32 mm, P-iris, 42.5°–15.2° horizontal FOV
- DarkFighter 2.0 low-light: colour 0.0005 lux, B/W 0.0001 lux minimum illumination
- 150 dB Adaptive Wide Dynamic Range (AWDR)
- IR illumination up to 100 m (8–32 mm lens variant)
- Up to 5 configurable video streams (H.265+, H.265, H.264+, H.264)
- Built-in heater, G-sensor vibration detection, and power-meter
- IP67 weatherproof and IK10 vandal-resistant metal housing
- Human/vehicle classification and on-board ANPR
- –40 °C to +60 °C operating temperature range
- Motorised varifocal lens: 8–32 mm, P-iris, 42.5°–15.2° horizontal FOV
- DarkFighter 2.0 low-light: colour 0.0005 lux, B/W 0.0001 lux minimum illumination
- 150 dB Adaptive Wide Dynamic Range (AWDR)
- IR illumination up to 100 m (8–32 mm lens variant)
- Up to 5 configurable video streams (H.265+, H.265, H.264+, H.264)
- Built-in heater, G-sensor vibration detection, and power-meter
- IP67 weatherproof and IK10 vandal-resistant metal housing
- Human/vehicle classification and on-board ANPR
- –40 °C to +60 °C operating temperature range
§ 04Why choose this
Built for the way you actually use the iDS-2CD7A46G2-P-IZHSY-8-32MM
DarkFighter 2.0 for Low-Light Plate Capture
DarkFighter 2.0 with 0.0005 lux colour sensitivity combined with 150dB AWDR keeps plates readable in near-darkness and in high-contrast conditions — tunnel exits, headlight glare, and dawn/dusk transitions where standard sensors fail.
Built to Run Unattended in Harsh Weather
The built-in heater activates automatically in cold or damp conditions, and the IP67/IK10 metal housing withstands direct outdoor exposure. The G-sensor triggers alerts if the camera is struck or moved, making it suitable for remote gate installations.
Flexible Streaming for Multi-System Sites
With up to 5 simultaneous streams and H.265+ compression, the camera feeds live view, recording, ANPR analytics, and mobile access simultaneously, reducing the camera count and bandwidth load for multi-purpose vehicle monitoring points.
§ 05Where it fits
Right at home in these scenarios
Vehicle Access Control at Gates and Boom Barriers
The 8–32mm lens captures plates at distances from 10m to 100m, suiting boom gate approaches, long driveways, and single-lane access points where the camera must be mounted well back from the vehicle stop line.
Car Park Entry and Exit Monitoring
On-board ANPR and vehicle classification allow the camera to log plate and vehicle type data at entry and exit lanes, feeding permit-based access rules or billing systems without requiring a separate ANPR server.
Perimeter Security With AI Event Filtering
Human/vehicle classification reduces false alarms at perimeter fence lines by suppressing motion events from animals, vegetation, and shadows, while still flagging vehicle approaches and pedestrian intrusions.
Industrial Site Traffic Monitoring
The –40°C to +60°C operating range and IP67/IK10 rating support year-round deployment at mine entries, freight yards, and processing facilities where vehicle logging and access auditing are required.
§ 06Setup
Installation & setup
Power Over Ethernet With Heater Load Planning
Powered via IEEE 802.3af PoE or 12 V DC. Confirm the PoE switch or injector can deliver adequate power when the built-in heater is active, particularly for installations in cold climate zones where the heater may run for extended periods.
Lens Adjustment and Focus
The 8–32mm motorised varifocal lens supports remote zoom and focus adjustment through the camera web interface or iVMS-8600. Set the zoom to frame the target lane width at the plate capture point, then lock focus using the auto-focus routine before commissioning.
IR Placement and Reflection Management
Position the camera so the IR beam path does not intersect nearby walls, poles, or reflective signs within 2 metres, as backscatter will overexpose the plate zone and degrade night reads. Use the live view in B/W mode at night to verify even illumination across the lane.
Cabling and Surge Protection
Use shielded Cat6 cable with surge protection for outdoor Ethernet runs. Seal all conduit and cable entry points with weatherproof glands to preserve the IP67 rating. For pole-mounted installations, verify the mounting bracket is rated for the combined weight of the camera and junction box under local wind conditions.
§ 08Questions
Frequently asked about the iDS-2CD7A46G2-P-IZHSY-8-32MM
Q.01
Q: What is the advantage of the 8–32 mm lens over the 2.8–12 mm variant?
A: The 8–32 mm lens offers long-range zoom flexibility for capturing vehicle plates at distances from approximately 10 m to 100 m, while the 2.8–12 mm variant suits shorter-range or wider-lane installations. Choose based on your camera-to-plate distance and lane width.
Q.02
Q: Can it perform licence-plate recognition (ANPR) without a separate server?
A: Yes. The DeepinView series includes built-in AI analytics that detect and recognise vehicle plates and classify vehicles by type directly on the camera, though a management platform such as iVMS-8600 is recommended for event search and database management.
Q.03
Q: Does it work in low-light or nighttime conditions?
A: Yes. DarkFighter 2.0 imaging delivers colour detail at 0.0005 lux minimum illumination, and the 100m smart IR provides B/W coverage for plate reads in near-total darkness.
Q.04
Q: Is it weather-resistant for outdoor use?
A: Yes. The IP67 and IK10-rated metal housing protects against dust, rain, and vandal impact across an operating range of –40°C to +60°C. The built-in heater prevents condensation and icing in cold or damp environments.
Q.05
Q: What is the IR distance on this model?
A: Approximately 100 m in optimal conditions for the 8–32 mm lens version. The smart IR adjusts intensity automatically to avoid overexposing plates at closer ranges.
Q.06
Q: How does the G-sensor help?
A: It detects vibration or impact and can trigger alarms if the camera is tampered with or moved, providing an additional layer of security for pole-mounted or exposed installations.
Q.07
Q: Can it detect humans as well as vehicles?
A: Yes. The DeepinView AI analytics distinguish between people and vehicles to minimise false alarms and support perimeter protection alongside vehicle monitoring.
Q.08
Q: How many simultaneous video streams does it support?
A: Up to five simultaneous streams for live viewing, recording, analytics, and mobile access.
Q.09
Q: Does it include a heater?
A: Yes. A built-in heater activates automatically in cold or high-humidity environments to prevent internal condensation.
Q.10
Q: What are typical applications for this camera?
A: Car park entries, gated driveways, warehouse entrances, perimeter security, and traffic monitoring where reliable plate and object capture is required at medium to long range.
