Hanwha XNV-C8083R X-Core 6MP AI IR Vandal Dome 4.4-9.3mm — 1/1.8" Sensor, 40m WiseIR, IP66/IP67/IK10/NEMA4X
1 5
Hanwha

Hanwha XNV-C8083R X-Core 6MP AI IR Vandal Dome 4.4-9.3mm — 1/1.8" Sensor, 40m WiseIR, IP66/IP67/IK10/NEMA4X

SKU: XNV-C8083R
Description

- 6MP + 1/1.8" Larger Sensor: Physically larger sensor than 2MP/4MP siblings — gathers more light per pixel, cleaner IR-lit and low-light footage.
- X-Core AI Face + Plate: Full classification suite plus intrusion, loitering, line crossing on 6MP resolution.
- 4.4-9.3mm Motorised Varifocal: Remote framing adjustment for entry points, corridors, car parks, and perimeter-facing mounts.
- Indoor + Outdoor Vandal Rated: IP66/IP67/IK10/NEMA4X — one SKU across mixed-environment installations, unlike the indoor-only XND-C8083RV sibling.
$1,476.90 AUD $1,476.90 AUD $1,522.59 AUD
Sale 3.0% $45.69 AUD (3.0%)
Business or bulk buyer? Apply for trade pricing →
Found a lower price? We’ll match it →
Delivery, warranty & returns · ships same day before 2pm
  • Same-day dispatch on in-stock orders placed before 2pm, Sydney time.
  • 1–4 business days Australia-wide. Free standard shipping over $300, flat $25 under.
  • 3-year warranty on cameras and recorders, back-to-base, plus your Australian Consumer Law rights.
  • 30-day returns on unopened items. Faulty on arrival? We cover return shipping.
  • Genuine Australian stock. Never grey imports. Prices include GST.
  • American Express
  • Apple Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Union Pay
  • Visa

See all FAQs →

In stock
Build your setup Build a complete CCTV system Complete setup from $1,846.90

A camera needs an NVR, a hard drive, and cabling to work. Add everything below, or pick a ready-made kit.

Select hard drive · 4TB ≈ 2-3 weeks for 4 cameras recording 24/7
Add accessories Optional. Junction box → hides & weatherproofs cable joins (best for outdoors). Brackets → only if mounting on a corner or under eaves. Cable → one per camera; skip if you already have your own.
0
0
0
0
Bundle total: $1,476.90

§ 01Overview

What the XNV-C8083R is

The Hanwha XNV-C8083R is the 6MP tier of the X-Core AI vandal dome family, engineered for commercial and institutional surveillance where image detail and analytical intelligence both matter.

A 4.4-9.3mm motorised varifocal lens supports remote zoom and focus adjustment — practical for entry points, corridors, car parks, and perimeter-facing mounts where site framing needs may evolve.

The 1/1.8-inch CMOS sensor is physically larger than the 1/2-inch sensor on the 2MP and 4MP siblings; larger sensors gather more light per pixel, giving cleaner low-light and IR-lit imagery even before AI noise reduction runs.

Sensor output is 3328x1872 at up to 30fps under H.265, H.264, and MJPEG (30fps rather than 60fps because higher pixel count reduces per-frame throughput on the same pipeline).

WiseIR reaches 40m and extremeWDR configurable across 120-150dB handles both high-contrast lighting and complete darkness.

AI classifies people, vehicles, faces, and licence plates with intrusion, loitering, and line crossing behavioural analytics.

IP66/IP67/IK10/NEMA4X ratings support exposed outdoor installation — the outdoor-rated counterpart to the IP52 indoor-only XND-C8083RV sibling.

§ 02Engineering

XNV-C8083R specifications

- 6MP resolution (3328x1872) at up to 30fps H.265/H.264
- 1/1.8" CMOS sensor — larger than 1/2" on 2MP/4MP siblings
- 4.4-9.3mm motorised varifocal lens
- On-device AI person, vehicle, face, licence plate classification
- Intrusion, loitering, line crossing analytics
- extremeWDR configurable 120-150dB
- WiseIR IR illumination up to 40m
- H.265, H.264, MJPEG codecs
- Wisenet X-Core platform
- IP66 + IP67 + IK10 + NEMA4X — indoor + outdoor rated
- microSD edge storage
- PoE powered
- Vandal dome housing

§ 04Why choose this

Built for the way you actually use the XNV-C8083R

6MP + Larger 1/1.8" Sensor

Higher resolution AND cleaner low-light imagery than 2MP/4MP siblings on 1/2" sensors. Practical impact: better face and plate detail at typical vandal dome mount distances (5-8m ceiling-to-floor) plus cleaner IR-lit footage.

Full X-Core AI Suite

Person + vehicle + face + licence plate classification with intrusion, loitering, and line crossing — richer AI than Q-Core siblings, positioned for corporate reception, retail loss-prevention, and any scene where subject identification matters.

Indoor + Outdoor Rated Vandal Dome

IP66/IP67/IK10/NEMA4X supports exposed exterior installations, unlike the IP52 XND-C8083RV indoor-only sibling. One SKU across mixed-environment sites where indoor + outdoor coverage is required.

Configurable extremeWDR

120-150dB configurable — use 150dB mode for extreme mixed-light scenes, or 120dB for typical building interiors.

§ 05Where it fits

Right at home in these scenarios

Building Entrances and Lobbies

The dome profile suits ceiling mounting at entrances; 6MP + face classification supports visitor identification workflows on backlit glazed lobby fronts.

Covered Car Parks and Ramp Entries

extremeWDR handles ramp entry contrast; AI vehicle and plate classification supports automatic vehicle logging on gated commercial car parks.

Corridors and Perimeter-Facing Mounts

Vandal dome housing suits publicly accessible ceilings; the larger 1/1.8" sensor delivers cleaner IR-lit footage on long corridor coverage after site lighting shuts down.

Mixed Indoor-Outdoor Institutional Sites

Universities, hospitals, and government facilities with indoor + covered-outdoor camera positions benefit from one SKU that works across both — simplifies procurement and NVR configuration.

§ 06Setup

Installation & setup

01

What is in the Box

1. Hanwha XNV-C8083R Camera x 1 2. Mounting Screws & Anchors x 1 set 3. Quick Start Guide x 1

02

Installation Requirements

1. Power: PoE — verify switch/injector budget for higher-resolution X-Core cameras. 2. Mounting: ceiling, soffit, or wall — vandal dome housing (indoor + outdoor rated). 3. Sealing: preserve IP66/IP67 rating by sealing all cable and conduit entries on outdoor installations.

03

App/Software Setup

1. Access via web viewer, or add to Hanwha Wisenet WAVE or SSM software. 2. Dial in framing across the 4.4-9.3mm range at commissioning. 3. Configure AI analytics: face/plate/person/vehicle classification, intrusion, loitering, line crossing. 4. Enable H.265 compression to keep 6MP streams NVR-friendly.

§ 08Questions

Frequently asked about the XNV-C8083R

Q.01

Q: How is this different from the XND-C8083RV sibling?
A: The XNV-C8083R is IP66/IP67/IK10/NEMA4X rated for exposed outdoor installation; the XND-C8083RV is IP52 indoor-only. Same 6MP + 1/1.8-inch sensor + 4.4-9.3mm varifocal + X-Core AI feature set. Pick XNV-C8083R when the mount is exterior or covered outdoor; XND-C8083RV when indoor-only at a lower price.
Q.02

Q: How does the larger 1/1.8-inch sensor help?
A: Physically larger than the 1/2-inch sensor on the 2MP and 4MP siblings — gathers more light per pixel. Practical impact: cleaner images in dim indoor scenes and less noise on IR-lit low-light footage. Underlying signal is better than smaller-sensor siblings even before compression.
Q.03

Q: Why does the C8083R run at 30fps instead of 60fps?
A: The higher pixel count (6MP vs 2MP/4MP) reduces per-frame throughput on the same processing pipeline. Practical impact for vandal dome deployments is minimal — 30fps is more than adequate for retail, corporate, education, and covered-outdoor monitoring.
Q.04

Q: What AI events can this detect?
A: Person, vehicle, face, and licence plate classification, plus intrusion, loitering, and line crossing. Configure through web viewer or Wisenet WAVE.
Q.05

Q: Is this suitable for direct outdoor exposure?
A: Yes — IP66 (water jets), IP67 (temporary immersion), IK10 (impact), NEMA4X (corrosion). Full spec for exposed exterior mounts including coastal and industrial-chemical environments.
Q.06

Q: What field of view can I dial in?
A: The 4.4-9.3mm motorised varifocal lens covers moderate zoom range — from wide entry sweep to focused vehicle-approach shot. Adjust remotely from web viewer.
Q.07

Q: How far does WiseIR reach?
A: Approximately 40m — appropriate for building entries, corridors, and covered car park coverage.
Q.08

Q: Can this integrate with third-party VMS?
A: Yes — supports ONVIF for standard third-party integration.
