Hikvision DS-2CD2D25G1/M-D/NF Covert Network Camera
SKU: DS-2CD2D25G1/M-D/NF
Description
The Hikvision DS-2CD2D25G1/M-D/NF is a 2 MP covert network camera with a split-type design - a tiny lens head connects by cable to a separate main unit, so the camera can be hidden almost out of sight while the electronics sit elsewhere. It delivers 1080p at up to 60 fps with 120 dB WDR, and a discreet zinc-alloy head suits indoor positions where a normal camera would be too obvious.
Key points
- 2 MP (1920 x 1080) 1/2.8" CMOS, up to 60 fps
- Split-type covert design: miniature head plus separate main unit
- Fixed 2.8 or 4 mm lens (M12), 120 dB WDR
- Smart events: line crossing, intrusion, region entry and exit
- Line-in audio input (no built-in microphone or speaker)
- Indoor zinc-alloy body; 12 VDC power
- No infrared - needs some ambient light
Regular price
$242.50 AUD
Sale price
$242.50 AUD
Regular price
$280.00 AUD
Sale
13.39%
$37.50 AUD
(13.39%)
Member
Sign in to save $4.85 on this item — free to join.
Buying for business? Apply for trade pricing →
Building a kit or need installation? Email sales@smarket.com.au for a quote.
inc GST + 3 Year Warranty & Support
Free shipping over AUD300
In stock
No reviews
Hikvision DS-2CD2D25G1/M-D/NF Covert Network Camera
1
/
of
1
Build your setup Build a complete CCTV system Complete setup from $1,186.10
A camera needs an NVR, a hard drive, and cabling to work. Add everything below, or pick a ready-made kit.
3-Year Warranty
Warranty on all cameras
Free Shipping
On orders over $300
30-Day Returns
Easy returns for unopened items
Fast Delivery
5-10 Day Delivery Australia-wide
§ 01Overview
What the DS-2CD2D25G1/M-D/NF is
The Hikvision DS-2CD2D25G1/M-D/NF is a covert camera for places where a visible camera is unwanted or intrusive.
It uses a split-type design: a miniature 31.5 mm lens head connects by cable to a separate main unit, so you can conceal just the small head behind a fascia, in a fitting or in joinery while the body sits out of view.
That makes it well suited to retail counters, ATMs, reception desks, hospitality interiors and other sensitive indoor spaces.
Despite its size it is a capable 2 MP camera.
It records 1920 x 1080 at up to 60 fps, which captures smooth, clear motion at a busy till or doorway, and 120 dB WDR balances exposure against bright windows and entrances so faces are not lost in silhouette.
Smart events such as line crossing, intrusion and region entry and exit run on board, and a line-in audio input lets you add an external microphone where recording sound is permitted and appropriate.
Two honest points so you set it up correctly.
It has no infrared, so it relies on the room's existing light and is intended for indoor use with some ambient lighting, not for dark or outdoor positions.
And it has no built-in microphone or speaker - audio is via the line-in input only.
It runs on a 12 VDC supply and connects over the network to a Hikvision NVR for recording and search.
§ 02Engineering
DS-2CD2D25G1/M-D/NF specifications
- 2 MP (1920 x 1080) 1/2.8" CMOS at up to 60 fps for smooth motion
- Split-type covert design: miniature head and separate main unit
- Fixed 2.8 or 4 mm M12 lens for the angle you need
- 120 dB WDR for bright entrances and backlit scenes
- On-board smart events: line crossing, intrusion, region entry and exit
- Line-in audio input for an external microphone
- Discreet indoor zinc-alloy head; 12 VDC power
- No infrared - designed for indoor use with ambient light
- Split-type covert design: miniature head and separate main unit
- Fixed 2.8 or 4 mm M12 lens for the angle you need
- 120 dB WDR for bright entrances and backlit scenes
- On-board smart events: line crossing, intrusion, region entry and exit
- Line-in audio input for an external microphone
- Discreet indoor zinc-alloy head; 12 VDC power
- No infrared - designed for indoor use with ambient light
§ 03Full datasheet
Detailed specifications
Camera & Image
| Feature | Detail |
|---|---|
| Image Sensor | 1/2.8" Progressive Scan CMOS |
| Max. Resolution | 1920 × 1080 |
| Min. Illumination | Color: 0.002 Lux @ (F1.2, AGC ON) |
| Shutter Time | 1/3 s to 1/100,000 s |
| Day/Night Switch | Day, Night, Auto, Schedule |
| Wide Dynamic Range (WDR) | 120 dB |
| Image Enhancement | BLC, HLC, defog, 3D DNR |
| Image Parameters Switch | Yes |
| Image Settings | Saturation, brightness, contrast, and sharpness adjustable by client software or web browser |
| Privacy Mask | Yes |
Lens & Distance
| Feature | Detail |
|---|---|
| Focal Length & FOV | 2.8 mm: horizontal FOV: 107.8°, vertical FOV: 57.9°, diagonal FOV: 126.7° | 4 mm: horizontal FOV: 82.8°, vertical FOV: 45.1°, diagonal FOV: 98° |
| Lens Mount | M12 |
| Iris Type | Fixed |
| Aperture | 2.8 mm: F2.0 | 4 mm: F2.0 |
| DORI | 2.8 mm: D: 42.8 m, O: 17 m, R: 8.6 m, I: 4.3 m | 4 mm: D: 55.2 m, O: 21.9 m, R: 11 m, I: 5.5 m |
Night Vision
| Feature | Detail |
|---|
Video
| Feature | Detail |
|---|---|
| Main Stream | 50 Hz: 50 fps (1920 × 1080, 1280 × 720) | 60 Hz: 60 fps (1920 × 1080, 1280 × 720) |
| Sub-Stream | 50 Hz: 25 fps (640 × 480, 640 × 360, 320 × 240) | 60 Hz: 30 fps (640 × 480, 640 × 360, 320 × 240) |
| Third Stream | 50 Hz: 1 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360, 320 × 240) | 60 Hz: 1 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360, 320 × 240) |
| Video Compression | Main stream: H.265/H.264; Sub-stream: H.265/H.264/MJPEG; Third stream: H.265/H.264 |
| H.264 Type | Baseline Profile/Main Profile/High Profile |
| H.265 Type | Main Profile |
| Bit Rate Control | CVR/BVR |
| Scalable Video Coding (SVC) | H.264 and H.265 encoding |
| Region of Interest (ROI) | Support 1 fixed region for main stream |
Audio
| Feature | Detail |
|---|---|
| Audio Type | Mono |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/AAC |
| Audio Bit Rate | 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/16 to 64 Kbps (AAC) |
| Audio Sampling Rate | 8 kHz/16 kHz/32 kHz |
| Environment Noise Filtering | Yes |
AI & Deep Learning
| Feature | Detail |
|---|
Network & Storage
| Feature | Detail |
|---|---|
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| Simultaneous Live View | Up to 15 channels |
| API | Open Network Video Interface, ISAPI, SDK, ISUP 5.0 |
| User/Host | Up to 32 users; 3 level: administrator, operator, and user |
| Network Storage | NAS (NFS, SMB/CIFS) |
| Client | iVMS-4200, Hik-Connect |
| Web Browser | Plug-in required live view: IE10, IE11; Plug-in free live view: Chrome 57.0+, Firefox 52.0+; Local service: Chrome 57.0+, Firefox 52.0+ |
Event & Alarm
| Feature | Detail |
|---|---|
| Basic Event | Motion detection, video tampering alarm, exception (HDD full, HDD error, network disconncected), video quality diagnosis |
| Smart Event | Intrusion detection, line crossing detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection. Audio exception detection, defocus detection, scene change detection |
| Linkage | Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture, audible warning |
Interface
| Feature | Detail |
|---|---|
| Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
| Audio | 1 input (line in) |
| Reset Key | Yes |
General & Environment
| Feature | Detail |
|---|---|
| Power | 12 VDC ± 20%, 0.13 A, max. 1.5 W, Ø 5.5 mm coaxial power plug |
| Material | Zinc alloy |
| Dimension | 31.5 mm × 31.5 mm × 49.6 mm (1.2" × 1.2" × 2") |
| Package Dimension | 130 mm × 104 mm × 85 mm (5.1" × 4.1" × 3.3") |
| Weight | Approx. 93 g (0.2 lb.) |
| With Package Weight | Approx. 202 g (0.4 lb.) |
| Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Startup and Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Language | 18 languages: English, Traditional Chinese, Russian, Turkish, Japanese, Korean, Thai, Vietnamese, Estonian, Bulgarian, Hungarian, Czech, Slovak, French, Italian, German, Spanish, Portuguese |
| General Function | One-key reset, heartbeat, mirror, password protection, privacy mask, rotate, watermark, IP address filter |
| EMC | FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2:2019, EEN 61000-3-3:2013+A1:2019, EN 50130-4: 2011+A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 7); KC (KN 32: 2015, KN 35: 2015) |
| Safety | UL (UL 62368-1); CB (IEC 62368-1:2014+A11); CE-LVD (EN 62368-1:2014/A11:2017); BIS (IS 13252(Part 1):2010/ IEC 60950-1 : 2005); LOA (IEC/EN 60950-1) |
| Environment | CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
§ 04Why choose this
Built for the way you actually use the DS-2CD2D25G1/M-D/NF
Sharp at busy points
1080p at up to 60 fps captures smooth motion at tills and doorways.
Handles bright entrances
120 dB WDR keeps faces visible against backlight and glare.
Discreet indoor design
A small zinc-alloy head suits retail, hospitality and reception interiors.
§ 05Where it fits
Right at home in these scenarios
Retail counters and tills
Cover a point of sale discreetly with smooth, clear motion capture.
ATMs and cash points
Watch a cash machine or counter without an obvious camera on show.
Reception and concierge desks
Keep a discreet view of a front desk in a hotel or office.
Hospitality interiors
Add unobtrusive coverage to a bar, restaurant or boutique.
§ 06Setup
Installation & setup
What's in the box
One DS-2CD2D25G1/M-D/NF covert camera comprising the miniature lens head and the separate main unit with their connecting cable and fixings. The 12 VDC power supply, network cable and any NVR are supplied separately.
Installation requirements
Conceal the small lens head in the chosen indoor position with a clear line of sight and some ambient light, and mount the main unit nearby out of view. Connect the head to the main unit, run the network cable to a Hikvision NVR or switch, and provide 12 VDC power. There is no infrared, so make sure the area has enough light.
§ 07Questions
Frequently asked about the DS-2CD2D25G1/M-D/NF
Q.01
What makes the DS-2CD2D25G1/M-D/NF a covert camera?
It uses a split-type design where a tiny lens head connects by cable to a separate main unit, so you can conceal just the small head behind a fascia, fitting or piece of joinery while the body sits out of view. That lets it watch a space discreetly where a normal camera would be too obvious.
Q.02
Where is it meant to be used?
It is an indoor camera for sensitive spaces such as retail counters, ATMs, reception desks and hospitality interiors. It has no weatherproof rating and no infrared, so it is not intended for outdoor or dark positions.
Q.03
Does it work in the dark?
No, not on its own. It has no infrared and relies on the room's existing light, so it needs some ambient lighting to produce a usable image. For dark areas, choose a camera with built-in infrared or white light instead.
Q.04
Does it have a microphone?
It has no built-in microphone or speaker. There is a line-in audio input, so you can connect an external microphone where recording sound is permitted and appropriate, but the camera does not capture audio by itself.
Q.05
Why does it record at 60 fps?
The high 60 fps frame rate captures smooth, clear motion, which helps at busy points such as a retail till or a doorway where fast movement can blur on a slower camera. You can run it at a lower frame rate to save storage if you prefer.
Q.06
How is it powered and connected?
It runs on a 12 VDC supply and connects over the network to a Hikvision NVR. The miniature head links to the main unit by its cable, and the main unit provides the network and power connections.
Q.07
Which lens should I choose?
The 2.8 mm lens gives a wider view for a small room or counter area, while the 4 mm lens is a little tighter for a specific spot such as a till or an entry. Both are fixed M12 lenses, so pick the angle that matches the space.
§ 09Bundles
Recommended packages
Record it
Connect it over the network to a Hikvision DS-7608NI-M2/8P NVR, or a larger DS-7616NI-M2/16P, for recording and search.
Add a visible deterrent
Combine the covert view with a visible ColorVu camera such as the DS-2CD2787G2H-LIPTRZS motorised dome at the entrance, so you have both deterrence and discreet coverage.
