§ 01Overview
What the RFSM2-A is
The Bosch RFSM2-A is the smoke detector in the RADION wireless family. It senses smoke photoelectrically and also watches the temperature, with a fixed heat alarm at +57 °C and a rate-of-rise alarm when the room climbs 8.3 °C above +40 °C, so a fast, hot fire is caught even before the smoke builds.
It warns the room as well as the panel. The built-in sounder gives at least 85 dBA at 3 m when fire is detected, and alarm and supervisory messages go through the RADION receiver to the control panel. Built to the UL268 7th edition standard, it is meant for the living areas where fires most often start.
Day to day it needs little attention. Two CR123A batteries ship installed and give a typical battery life of up to 10 years. The optical chamber checks its own dust level every 40 seconds and compensates as dust builds up or is cleaned off, a sealed fine mesh screen keeps insects and dust out of the chamber, and the large test and silence button tests the sensor, electronics, battery and alarm or silences a nuisance alarm. When the detector reaches the end of its life, an audible and visual indicator says so.
The radio link is supervised for sensor health, low battery and tamper, and a tamper switch reports if the detector is taken off its twist-on mounting plate. It needs a B810 wireless SDI2 bus interface at the panel; on a Solution 6000 the panel must run firmware V2.53.19 or later, which added support for it.
It is an indoor detector for 4.4 °C to +55 °C, not a stand-alone household smoke alarm: without a receiver and a compatible panel it only sounds locally. It is the North and South American model, approved to UL 268, FCC and Industry Canada, so check with your installer which building rules apply to its use in Australia.
§ 02Engineering
RFSM2-A specifications
Bosch RFSM2-A sensing — photoelectric smoke sensor plus fixed and rate-of-rise heat sensor — smoke and heat in one wireless detector
Heat alarm — fixed at +57 °C, rate-of-rise 8.3 °C above +40 °C — a fast, hot fire is caught early
Sounder — built-in alarm of at least 85 dBA at 3 m — the room is warned, not only the panel
Radio — 433.42 MHz RADION transmitter, supervised for sensor health, low battery and tamper — the panel knows the detector's condition
Battery — two 3V CR123A batteries installed, typical life up to 10 years — years between battery changes
Dust compensation — the optical chamber checks dust every 40 seconds and adjusts — sensitivity stays steady as the chamber ages
Insect protection — sealed fine mesh screen over the optical chamber — fewer false alarms from insects and dust
Test and silence — one large button tests the sensor, electronics, battery and alarm, and silences a nuisance alarm — routine testing without a ladder trick
Mounting — twist-on mounting plate with multiple mounting points, 115 mm x 59 mm, 205 g — quick to fit on a ceiling or wall
Heat alarm — fixed at +57 °C, rate-of-rise 8.3 °C above +40 °C — a fast, hot fire is caught early
Sounder — built-in alarm of at least 85 dBA at 3 m — the room is warned, not only the panel
Radio — 433.42 MHz RADION transmitter, supervised for sensor health, low battery and tamper — the panel knows the detector's condition
Battery — two 3V CR123A batteries installed, typical life up to 10 years — years between battery changes
Dust compensation — the optical chamber checks dust every 40 seconds and adjusts — sensitivity stays steady as the chamber ages
Insect protection — sealed fine mesh screen over the optical chamber — fewer false alarms from insects and dust
Test and silence — one large button tests the sensor, electronics, battery and alarm, and silences a nuisance alarm — routine testing without a ladder trick
Mounting — twist-on mounting plate with multiple mounting points, 115 mm x 59 mm, 205 g — quick to fit on a ceiling or wall
§ 03Full datasheet
Detailed specifications
Overview & Compatibility
| Feature | Detail |
|---|---|
| Product | RFSM2-A Wireless smoke detector — RADION smoke |
| Region | For use in North and South America. |
| Description | RADION smoke is a photoelectric wireless detector that continuously senses both smoke, and high and fast rising temperatures caused by fire. |
| Standard | The detector fully meets the latest UL268 7th edition standard and is ideal for living areas where fire is most likely to start |
| Compatibility | Control panel: G Series B9512G/B8512G; B Series B6512/B5512/B4512/B3512; GV4 Series D9412GV4/D7412GV4 v2.00 or higher — Receiver: B810 wireless SDI2 bus interface |
| Parts included | 1 detector with installed radio module and batteries; 2 mounting screws; 2 wall anchors |
Detection & Coverage
| Feature | Detail |
|---|---|
| Sensing | Reliable photoelectric sensor technology; Fixed temperature and rate-of-rise heat sensor |
| Heat Alarm Fixed | +57 °C +/- 2 °C (+135 °F +/- 4 °F) |
| Heat Alarm Rate-of-rise | 8.3 °C > +40 °C (15 °F > +104 °F) |
| Sounder | RADION smoke built-in audible alarm sounds at a minimum sound output of 85 dBA at 3 m when fire is detected. |
| Minimum alarm sound | 85dBA at 3 m (10 feet) |
| Dust compensation | The optical sensor chamber monitors changes in dust levels every 40 seconds and automatically adjusts the photoelectric sensor for increases in dust, as well as for the removal of dust after cleaning. |
| Insect protection | The optical chamber is protected by a sealed fine mesh screen to reduce insect and dust contamination |
| Test / silence button | The large ergonomic test / silence button allows for frequent testing of the sensor, electronics, battery and alarm, and for silencing false or nuisance alarms. |
| Tamper | The tamper switch detects removal of the detector from its base. |
| Mounting | The detector has a twist-on mounting plate with multiple mounting points for easier installation. |
Wireless & Radio
| Feature | Detail |
|---|---|
| Frequency (MHz) | 433.42 |
| Supervision | Supervision alerts for sensor health, low battery, and tamper conditions |
Power & Electrical
| Feature | Detail |
|---|---|
| Battery type | Panasonic 3V CR123A (2x) |
| Typical battery life (years) | up to 10 |
Physical & Environment
| Feature | Detail |
|---|---|
| Dimensions (Ø x D) | 115 mm x 59 mm (4.5 in x 2.3 in) |
| Weight | 205 g (0.45 lb) |
| Minimum operating temperature | 4.4 °C (+40 °F) |
| Maximum operating temperature | +55 °C (+131 °F) |
| Operating and storage relative humidity | 0 - 93 % (non-condensing) |
| Use | Indoor use. |
Compliance & Warranty
| Feature | Detail |
|---|---|
| USA | UL 268 – Smoke detectors for fire alarm signaling systems; FCC T3X-EIHTSD |
| Canada | IC 1249A-EIHTSD |
| Overview & Compatibility — Product | RFSM2-A Wireless smoke detector — RADION smoke |
|---|---|
| Overview & Compatibility — Region | For use in North and South America. |
| Overview & Compatibility — Description | RADION smoke is a photoelectric wireless detector that continuously senses both smoke, and high and fast rising temperatures caused by fire. |
| Overview & Compatibility — Standard | The detector fully meets the latest UL268 7th edition standard and is ideal for living areas where fire is most likely to start |
| Overview & Compatibility — Compatibility | Control panel: G Series B9512G/B8512G; B Series B6512/B5512/B4512/B3512; GV4 Series D9412GV4/D7412GV4 v2.00 or higher — Receiver: B810 wireless SDI2 bus interface |
| Overview & Compatibility — Parts included | 1 detector with installed radio module and batteries; 2 mounting screws; 2 wall anchors |
| Detection & Coverage — Sensing | Reliable photoelectric sensor technology; Fixed temperature and rate-of-rise heat sensor |
| Detection & Coverage — Heat Alarm Fixed | +57 °C +/- 2 °C (+135 °F +/- 4 °F) |
| Detection & Coverage — Heat Alarm Rate-of-rise | 8.3 °C > +40 °C (15 °F > +104 °F) |
| Detection & Coverage — Sounder | RADION smoke built-in audible alarm sounds at a minimum sound output of 85 dBA at 3 m when fire is detected. |
| Detection & Coverage — Minimum alarm sound | 85dBA at 3 m (10 feet) |
| Detection & Coverage — Dust compensation | The optical sensor chamber monitors changes in dust levels every 40 seconds and automatically adjusts the photoelectric sensor for increases in dust, as well as for the removal of dust after cleaning. |
| Detection & Coverage — Insect protection | The optical chamber is protected by a sealed fine mesh screen to reduce insect and dust contamination |
| Detection & Coverage — Test / silence button | The large ergonomic test / silence button allows for frequent testing of the sensor, electronics, battery and alarm, and for silencing false or nuisance alarms. |
| Detection & Coverage — Tamper | The tamper switch detects removal of the detector from its base. |
| Detection & Coverage — Mounting | The detector has a twist-on mounting plate with multiple mounting points for easier installation. |
| Wireless & Radio — Frequency (MHz) | 433.42 |
| Wireless & Radio — Supervision | Supervision alerts for sensor health, low battery, and tamper conditions |
| Power & Electrical — Battery type | Panasonic 3V CR123A (2x) |
| Power & Electrical — Typical battery life (years) | up to 10 |
| Physical & Environment — Dimensions (Ø x D) | 115 mm x 59 mm (4.5 in x 2.3 in) |
| Physical & Environment — Weight | 205 g (0.45 lb) |
| Physical & Environment — Minimum operating temperature | 4.4 °C (+40 °F) |
| Physical & Environment — Maximum operating temperature | +55 °C (+131 °F) |
| Physical & Environment — Operating and storage relative humidity | 0 - 93 % (non-condensing) |
| Physical & Environment — Use | Indoor use. |
| Compliance & Warranty — USA | UL 268 – Smoke detectors for fire alarm signaling systems; FCC T3X-EIHTSD |
| Compliance & Warranty — Canada | IC 1249A-EIHTSD |
§ 04Why choose this
Built for the way you actually use the RFSM2-A
It warns the room, not just the panel
A sounder built into the detector gives at least 85 dBA at 3 m when fire is detected. The same event reaches the panel through the RADION receiver, so a monitored system reports it.
Up to 10 years of typical battery life
Two CR123A batteries come installed and give a typical battery life of up to 10 years. Low battery, sensor health and tamper are supervised, so the panel reports a problem before the detector goes quiet.
Fewer nuisance alarms as it ages
The optical chamber checks its dust level every 40 seconds and compensates for dust building up or being cleaned off. A sealed fine mesh screen keeps insects out of the chamber.
Simple to test and silence
One large button tests the sensor, electronics, battery and alarm, and silences a false alarm from burnt toast. An audible and visual indicator says when the detector has reached the end of its life.
No cable to the ceiling
It reports over 433.42 MHz radio to a B810 receiver, so a bedroom wing or a finished ceiling gets a supervised fire zone without a cable run. The twist-on plate fits a ceiling or a wall.
§ 05Where it fits
Right at home in these scenarios
Living areas of a home
The Bosch RFSM2-A suits the ceiling of the living areas where fires most often start, the lounge, hallway and kitchen approaches. Its sounder gives at least 85 dBA at 3 m while the panel reports the fire.
Bedroom wing without cabling
Where a cable run back to the panel is impractical, the detector reports over 433.42 MHz radio to the B810 receiver. A rented home or a finished ceiling gets a supervised fire zone with no cabling.
Solution 6000 system with a B810
A Solution 6000 on firmware V2.53.19 or later takes the detector through the B810 wireless SDI2 bus interface. A fire-zone alarm gives the keypad its own distinct tone.
§ 06Setup
Installation & setup
What's in the box
The Bosch RFSM2-A arrives as the detector with its radio module and two CR123A batteries installed, plus two mounting screws and two wall anchors. The B810 receiver and the panel are separate.
Receiver and panel firmware
Fit a B810 wireless SDI2 bus interface at the panel. On a Solution 6000, update the panel to firmware V2.53.19 or later before adding the detector, because that release added support for it.
Where to mount it
Mount it indoors, in a dry location, on a flat rigid ceiling or wall surface using the twist-on mounting plate and the supplied screws and anchors. Keep it within its 4.4 °C to +55 °C operating range and away from the locations the installation manual says to avoid.
No cable, but test the radio
There is no cable run to plan. Test the radio path from the intended spot before fixing the detector, then learn it into the panel as an RF zone.
Test and end of life
Press the test and silence button after installation to test the sensor, electronics, battery and alarm, and repeat the test regularly. Replace the detector when its audible and visual end-of-life indicator says so.
When to call an electrician
The detector is battery powered and needs no electrical work. Use a licensed electrician only if the wider job involves fixed mains wiring, and a licensed security installer for the panel programming.
§ 08Questions
Frequently asked about the RFSM2-A
Q.01
Does the Bosch RFSM2-A work with a Solution 6000?
Yes, through a B810 wireless SDI2 bus interface, on panel firmware V2.53.19 or later, which added support for the Bosch RFSM2-A. Confirm the panel firmware with your installer before ordering.
Q.02
Which receiver does it need?
The B810 wireless SDI2 bus interface. It receives the RADION family, including the smoke detector, and passes alarm and supervisory messages to the panel.
Q.03
Does it detect heat as well as smoke?
Yes. A photoelectric sensor handles smoke, and a heat sensor adds a fixed alarm at +57 °C and a rate-of-rise alarm when the temperature rises 8.3 °C above +40 °C.
Q.04
How loud is the built-in alarm?
At least 85 dBA at 3 m when fire is detected. The same event is sent through the RADION receiver to the panel.
Q.05
How long do the batteries last?
The two CR123A batteries come installed and have a typical life of up to 10 years. Low battery is supervised, and a Low Battery trouble on the panel clears once the battery is replaced and the detector transmits again.
Q.06
Will dust change its sensitivity over time?
The optical chamber monitors dust every 40 seconds and adjusts the photoelectric sensor as dust builds up or is cleaned off. A sealed fine mesh screen keeps insects and dust out of the chamber.
Q.07
How do I test it or stop a nuisance alarm?
Press the large test and silence button. It tests the sensor, electronics, battery and alarm, and silences a false or nuisance alarm.
Q.08
Can I mount it on a wall, and can it go outside?
The twist-on mounting plate suits a ceiling or a wall, following the installation manual's guidance on locations to avoid. It is for indoor, dry locations only, from 4.4 °C to +55 °C.
Q.09
Is it approved in Australia?
Its approvals are UL 268, FCC and Industry Canada; it is the North and South American RADION smoke detector. Check with your installer which building and fire rules apply to your installation.
