The Hikvision DS-96256NXI-S24R is a 256-channel Ultra Series NVR with twenty-four hard-drive bays and a redundant power supply, built for airports, smart-city projects and enterprise campuses. It runs AcuSense face recognition, perimeter protection and video structuralization on the recorder, protects footage with RAID across 24 bays, and outputs 8K over HDMI. It has no built-in PoE and ships without hard drives.

At a glance
- 256 IP channels, up to 32MP; 1280 Mbps in / 1024 Mbps out (640/512 in RAID mode)
- On-NVR AcuSense: face recognition, perimeter protection, video structuralization, AcuSearch
- 24 SATA bays, up to 20TB each (up to 480TB), RAID 0/1/5/6/10 plus N+M hot spare
- 8K HDMI output; four 2.5GbE ports; redundant power supply
- 3U chassis; no built-in PoE; supplied with no HDD

The Hikvision DS-9632NI-M8 is a 32-channel M-Series network video recorder for larger commercial systems where cameras run from managed network switches. It records up to 32 IP cameras at resolutions up to 32MP with 320 Mbps of incoming bandwidth, stores footage across eight SATA bays with RAID, and outputs 8K over HDMI. It has no built-in PoE and is supplied without hard drives.

Key points
- 32 IP channels; 320 Mbps incoming, 400 Mbps outgoing bandwidth
- Records cameras up to 32MP; H.265+ compression
- Eight SATA bays (up to 16TB each) plus eSATA; RAID 0, 1, 5, 6, 10 and N+M hot spare
- No built-in PoE — cameras connect via external network switches
- Dual HDMI (8K) and dual VGA outputs for multi-screen monitoring
- Works with special cameras: people counting, ANPR and fisheye
- 2U rack chassis; hard drives not included; remote view via Hik-Connect

The Hikvision DS-9664NI-M16 is a 64-channel M-Series network video recorder for large commercial, industrial and multi-building sites. It records up to 64 IP cameras at resolutions up to 32MP, takes 400 Mbps of incoming bandwidth, stores footage across sixteen SATA bays with RAID, and outputs 8K over HDMI 1. It has no built-in PoE, so cameras connect through your own network switches, and it ships without hard drives so you can fit the capacity your retention period needs.

At a glance
- 64 IP channels; 400 Mbps incoming and 400 Mbps outgoing bandwidth
- 16 SATA bays, up to 16TB per drive, RAID 0/1/5/6/10 plus N+M hot spare
- Dual HDMI + dual VGA; 8K (7680 x 4320) on HDMI 1
- H.265+ compression; works with people-counting, ANPR and fisheye cameras
- 3U rack chassis; 100-240 VAC; no built-in PoE; supplied with no HDD

The Hikvision DS-9664NI-M8 is a 64-channel M-Series network video recorder built for large commercial and multi-building sites. It records up to 64 IP cameras at resolutions up to 32MP with 400 Mbps of incoming bandwidth, stores footage across eight SATA bays with RAID, and outputs 8K over HDMI. It has no built-in PoE, so cameras connect through your own network switches, and it is supplied without hard drives.

Key points
- 64 IP channels; 400 Mbps incoming and 400 Mbps outgoing bandwidth
- Records cameras up to 32MP; H.265+ compression
- Eight SATA bays (up to 16TB each) plus eSATA; RAID 0, 1, 5, 6, 10 and N+M hot spare
- No built-in PoE — cameras connect via external network switches
- Dual HDMI (8K) and dual VGA outputs for multi-screen monitoring
- Works with special cameras: people counting, ANPR and fisheye
- 2U rack chassis; hard drives not included; remote view via Hik-Connect

Gen2 IP video intercom kit including a 2MP outdoor door station with IP65 rating and a 7-inch touchscreen indoor monitor with Wi-Fi connectivity and Hik-Connect mobile app support for villa and home entry security.

The Hikvision DS-PDC10AM-EG2-WB is an outdoor curtain PIR detector for AX PRO alarm systems. Its narrow 5° beam forms an invisible curtain along a wall, window line or balcony, catching an intruder at the perimeter - before they reach a door or window - with active anti-masking to stop it being quietly disabled.

At a glance
- Curtain-style PIR detection, narrow 5° beam, 10m wall mount / 5m ceiling mount, 32 zones
- Active IR anti-masking alarms if the lens is covered or sprayed
- IP65 weatherproof; -25 to 60°C; L-shaped adapter bracket included
- Pet immunity up to 12kg (wall mount; none on ceiling mount)
- Tri-X two-way wireless to an AX PRO hub, up to 1km, 433MHz; two CR123A, up to 5 years

The Hikvision DS-PDC10AM-VG3 is a slim wired PIR curtain detector for AX Hybrid Pro alarm systems. It casts a narrow vertical curtain of detection along a window or door, raising the alarm the instant someone breaches that line while letting people move freely inside the room behind it.

At a glance
- Narrow 5-degree PIR curtain beam, 10m wall-mount or 6m ceiling-mount range
- Active IR anti-masking (AM) reports any attempt to spray, cover or block the lens
- 32 detection zones, directional detection and digital temperature compensation
- IP65 rated for both indoor and outdoor use, -10 to 55 degrees C
- Wired: NC alarm output, selectable EOL resistors, front and rear tamper, 9-16 VDC

The Hikvision DS-PDC10DM-EG2-WB is an outdoor curtain dual-tech detector for AX PRO alarm systems. Its narrow 5° beam forms an invisible curtain along a wall, window line or balcony, combining PIR and microwave sensing with active anti-masking to catch intruders early while keeping false alarms down.

At a glance
- Curtain-style dual-tech (PIR + 24GHz microwave), narrow 5° beam, 10m wall / 5m ceiling, 32 zones
- Active IR anti-masking alarms if the lens is covered or sprayed
- IP65 weatherproof; -25 to 60°C; L-shaped adapter bracket included
- Pet immunity up to 12kg (wall mount; none on ceiling mount)
- Tri-X two-way wireless to an AX PRO hub, up to 1km; two CR123A, up to 5 years
