Hikvision DS-1605ZJ Wall Mount Bracket to suit Mini PTZ

SKU: DS-1605ZJ
Description

The Hikvision DS-1605ZJ is an aluminium-alloy wall mount bracket for Hikvision 4-inch mini PTZ cameras, such as the DS-2DE4A series. It holds the PTZ out from a wall on a solid arm with a waterproof design for outdoor use.

Key points
- Wall mount for Hikvision 4-inch mini PTZ cameras (DS-2DE4A series)
- Aluminium alloy with a waterproof design
- Φ171.7 mm × 158 mm × 228.6 mm, approx. 1120 g
- Maximum load 5 kg
- Sprayed Hikvision-white finish

Regular price $43.65 AUD Sale price $43.65 AUD Regular price $45.00 AUD
Sale 3.0% $1.35 AUD (3.0%)
EOFY sale: extra 5% off orders over $800 Applied automatically in cart — ends 30 June. Building a kit or need installation? Email sales@smarket.com.au for a quote.

inc GST + 3 Year Warranty & Support
Free shipping over AUD300

In stock
Build your setup Configure your bundle Bundle this camera with NVR, hard drive & accessories
Add accessories (optional, pick any)
1
1
1
Bundle total: $43.65
3-Year Warranty

3-Year Warranty

Warranty on all cameras

Free Shipping

Free Shipping

On orders over $300

30-Day Returns

30-Day Returns

Easy returns for unopened items

Fast Delivery

Fast Delivery

5-10 Day Delivery Australia-wide

§ 01Overview

What this product is

The Hikvision DS-1605ZJ is a wall mounting bracket made for Hikvision 4-inch mini PTZ cameras, such as the DS-2DE4A series. It carries the PTZ out from a vertical wall on a strong arm so the camera can pan, tilt and zoom with a clear view, and routes power and network cabling neatly to the camera base.

It is aluminium alloy with a waterproof design and a sprayed Hikvision-white finish, measures Φ171.7 mm by 158 mm by 228.6 mm, and weighs about 1120 g. The bracket is rated to a 5 kg maximum load, comfortably more than a 4-inch mini PTZ camera.

It is the wall-mount option for 4-inch mini PTZ bodies; for installs that also need a sealed cable cavity, Hikvision pairs it with the DS-1280ZJ-SD11 junction box. Confirm the mounting accessory listed on your PTZ camera's datasheet before ordering.

§ 02Engineering

Technical specifications

- Hikvision DS-1605ZJ aluminium-alloy wall mount bracket for 4-inch mini PTZ cameras
- Suits Hikvision DS-2DE4A-series 4-inch mini PTZ cameras
- Waterproof design for outdoor wall mounting
- Φ171.7 mm x 158 mm x 228.6 mm, approx. 1120 g
- Maximum load 5 kg
- Sprayed Hikvision-white finish to match the camera body

§ 03Full datasheet

Detailed specifications

Camera & Image

Camera & Image — Hikvision DS-1605ZJ Wall Mount Bracket to suit Mini PTZ
FeatureDetail

§ 04Why choose this

Built for the way you actually use it

01

Made for 4-inch mini PTZ

The bracket is sized and load-rated for Hikvision 4-inch mini PTZ bodies, so the camera mounts securely and moves without flex or vibration.

02

Strong aluminium build

At about 1120 g of aluminium alloy with a 5 kg load rating, it holds a moving PTZ steady so the image stays stable while it pans and tilts.

03

Built for outdoors

A waterproof design and sprayed finish stand up to Australian sun and rain on an exposed wall.

04

Tidy, matched finish

The Hikvision-white finish matches the camera and routes the cable cleanly to the camera base.

§ 05Where it fits

Right at home in these scenarios

01

PTZ on a building wall

Mount a 4-inch mini PTZ out from a wall to cover a yard, carpark or perimeter with pan, tilt and zoom.

02

Perimeter overwatch

Reach the PTZ out past eaves or trim so it has a clear sweep across the area it patrols.

03

Sites with no pole

Use a wall as the mounting point where there is no pole or parapet to fit the PTZ to.

04

Retail and commercial

A matched white finish and concealed cabling suit shopfronts, yards and commercial frontages.

§ 06Setup

Installation & setup

01

What's in the box

One DS-1605ZJ wall mount bracket with mounting hardware. The PTZ camera and any junction box are not included.

02

Installation requirements

Fix the bracket to a solid wall able to support at least three times the combined bracket and camera weight, using wall plugs rated for the load in masonry. Route power and network cabling through the bracket to the camera base, seal the entry for outdoor use, then mount the PTZ. Pair with the DS-1280ZJ-SD11 junction box if you need a sealed cable cavity.

§ 07Questions

Frequently asked

Q.01

Which cameras does the DS-1605ZJ suit?

It is the wall mount for Hikvision 4-inch mini PTZ cameras, such as the DS-2DE4A series. Because PTZ bodies vary across generations, confirm the wall-mount accessory listed on your PTZ camera's datasheet before ordering.
Q.02

What is the maximum load and how heavy is the bracket?

The bracket weighs about 1120 g and is rated to a 5 kg maximum load, which is comfortably more than a 4-inch mini PTZ camera. Fix it to a wall that can support at least three times the combined weight.
Q.03

Is it suitable for outdoor mounting?

Yes. It is aluminium alloy with a waterproof design and is built for outdoor wall mounting. Fit the waterproof rubber at the cable entry and seal where the base meets the wall so rain cannot track behind it.
Q.04

Do I need a junction box as well?

Not always. The bracket carries the camera and routes the cable, but if you want a sealed cavity to house cable joins and connectors, Hikvision pairs it with the DS-1280ZJ-SD11 junction box for 4-inch PTZ cameras.
Q.05

Will it fit a full-size PTZ camera?

No. It is sized and load-rated for 4-inch mini PTZ bodies. Larger PTZ cameras use heavier-duty wall mounts, so check the mounting accessory on that camera's datasheet.
Q.06

Is the camera included?

No. This listing is the wall mount bracket only. The PTZ camera is purchased separately.
Q.07

What finish does it come in?

It comes in a sprayed Hikvision-white finish to match the camera body for a clean, factory-matched look.

§ 09Bundles

Recommended packages

03

Bracket only

The DS-1605ZJ is the bracket only; the 4-inch mini PTZ camera is selected separately to suit your site.
