Dahua DHI-ASC3202B Two-Door Access Controller
1 1
Dahua

Dahua DHI-ASC3202B Two-Door Access Controller

SKU: DHI-ASC3202B
Description

Dahua DHI-ASC3202B controls two doors and connects compatible readers through RS-485 or Wiegand. Its built-in web server supports configuration without relying on a dedicated local configuration application.
$324.00 AUD $324.00 AUD
Business or bulk buyer? Apply for trade pricing →
Found a lower price? We’ll match it →
Delivery, warranty & returns · shipped from Australian stock
  • Tracked delivery on every order. The tracking number is emailed as soon as it ships.
  • Metro delivery: 2–4 business days. Regional areas may take longer. Free standard shipping over $300, flat $25 under.
  • 3-year warranty on cameras and recorders, back-to-base, plus your Australian Consumer Law rights.
  • 30-day returns on unopened items. Faulty on arrival? We cover return shipping.
  • Genuine Australian stock. Never grey imports. Prices include GST.
  • American Express
  • Apple Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Union Pay
  • Visa

See all FAQs →

In stock

01Overview

What the DHI-ASC3202B is

Dahua DHI-ASC3202B controls two doors and connects compatible readers through RS-485 or Wiegand. Its built-in web server supports configuration without relying on a dedicated local configuration application.

In main-controller mode it can manage up to 19 sub-controllers. Credential capacity depends on the mode, with 1,000 users in main mode or 10,000 in sub mode and storage for 300,000 records.

Use 12V DC or 802.3at PoE and calculate the total peripheral load before connecting locks and readers. The available 12V peripheral budget is 1,700mA on DC power or 1,200mA on PoE; each lock output is limited to 1,000mA.

02Engineering

DHI-ASC3202B specifications

Dahua DHI-ASC3202B — Doors: Two lock-control channels
Readers: Two RS-485 readers and two Wiegand readers
System expansion: Main mode manages up to 19 sub-controllers
Users: 1,000 main mode; 10,000 sub mode
Records: 300,000
Power input: 12 VDC or IEEE 802.3at Type 2 Class 4 PoE
Peripheral power: 12 V total: 1,700 mA with DC or 1,200 mA with PoE
Lock output limit: 1,000 mA

03Full datasheet

Detailed specifications

Specification

Specification — Dahua DHI-ASC3202B Two-Door Access Controller
FeatureDetail
Doors Two lock-control channels
Readers Two RS-485 readers and two Wiegand readers
System expansion Main mode manages up to 19 sub-controllers
Users 1,000 main mode; 10,000 sub mode
Records 300,000
Power input 12 VDC or IEEE 802.3at Type 2 Class 4 PoE
Peripheral power 12 V total: 1,700 mA with DC or 1,200 mA with PoE
Lock output limit 1,000 mA
Installation Indoor; surface or guide-rail mounting
