Hanwha XNV-6080R 2MP Outdoor Vandal Dome 2.8-12mm — 50m IR, 150dB WDR, IP66/IK10, 512GB SD
1 4
Hanwha

Hanwha XNV-6080R 2MP Outdoor Vandal Dome 2.8-12mm — 50m IR, 150dB WDR, IP66/IK10, 512GB SD

SKU: XNV-6080R
Description

- 150dB WDR + WiseStream II: Preserves detail on backlit and mixed-light outdoor scenes; WiseStream II with H.265 cuts data by up to 99% versus baseline H.264.
- 2.8-12mm Motorised Varifocal + 50m IR: Adjust framing remotely; IR reach extends usable coverage across driveways, walkways, and parking overhangs after hours.
- 512GB Edge Storage: Materially larger microSD headroom than Q-Core/X-Core siblings — appropriate for remote sites or intermittent NVR connectivity.
- IK10 Vandal + IP66 Weather: Aluminium ivory-finish housing built for building perimeters, covered walkways, and car park structures where impact and weather are both risks.
$807.60 AUD $807.60 AUD $832.60 AUD
Sale 3.0% $25.00 AUD (3.0%)
Business or bulk buyer? Apply for trade pricing →
Found a lower price? We’ll match it →
Delivery, warranty & returns · ships same day before 2pm
  • Same-day dispatch on in-stock orders placed before 2pm, Sydney time.
  • 1–4 business days Australia-wide. Free standard shipping over $300, flat $25 under.
  • 3-year warranty on cameras and recorders, back-to-base, plus your Australian Consumer Law rights.
  • 30-day returns on unopened items. Faulty on arrival? We cover return shipping.
  • Genuine Australian stock. Never grey imports. Prices include GST.
  • American Express
  • Apple Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Union Pay
  • Visa

See all FAQs →

In stock
Build your setup Build a complete CCTV system Complete setup from $1,177.60

A camera needs an NVR, a hard drive, and cabling to work. Add everything below, or pick a ready-made kit.

Select hard drive · 4TB ≈ 2-3 weeks for 4 cameras recording 24/7
Add accessories Optional. Junction box → hides & weatherproofs cable joins (best for outdoors). Brackets → only if mounting on a corner or under eaves. Cable → one per camera; skip if you already have your own.
0
0
0
0
Bundle total: $807.60

§ 01Overview

What the XNV-6080R is

The Hanwha XNV-6080R is an IK10-rated outdoor vandal dome camera positioned for outdoor installations where lighting shifts dramatically between day and night and where harsh glare or backlight routinely compromises image quality on lesser cameras.

Suited to building perimeters, covered walkways, car park structures, and entrance canopies where both weather exposure and physical interference are ongoing concerns.

A 2.8-12mm motorised varifocal lens with 4.3x optical range lets framing be dialled remotely after installation without site revisits.

150dB Wide Dynamic Range resolves both bright and shadowed zones within a single frame — meaningful at building entrances with sunlit exteriors and shaded foyers.

WiseStream II combined with H.265 achieves up to 99% data reduction versus baseline H.264, making the XNV-6080R well suited to bandwidth-constrained multi-camera deployments where shared NVR storage or network capacity is a constraint.

Built-in IR extends to 50m for after-hours coverage.

Edge storage supports SD/SDHC/SDXC cards up to 512GB — materially larger than the 128GB or 256GB ceilings on Q-Core and X-Core siblings, appropriate for remote sites or installations with intermittent NVR connectivity.

Advanced analytics cover loitering, directional detection, sound classification, and PTZ handover.

§ 02Engineering

XNV-6080R specifications

- 2MP Full HD resolution (1920x1080) at up to 60fps H.265/H.264
- 1/2" CMOS sensor
- 2.8-12mm motorised varifocal lens, 4.3x optical zoom
- 150dB Wide Dynamic Range
- WiseStream II: up to 99% data reduction combined with H.265
- 50m IR viewable length
- Analytics: loitering, directional detection, sound classification, PTZ handover
- SD / SDHC / SDXC edge storage up to 512GB
- Aluminium vandal dome, ivory finish
- IP66 + IK10 rated
- PoE (IEEE 802.3af) powered

§ 04Why choose this

Built for the way you actually use the XNV-6080R

150dB WDR for Sunlit-to-Shaded Transitions

The full 150dB dynamic range handles building entries with backlit sky against shaded foyer — the specific scene where 120dB competitors lose detail on faces or plates at busy entrances.

WiseStream II Cuts Bandwidth Dramatically

Up to 99% data reduction combined with H.265 versus baseline H.264 — meaningful on multi-camera sites where shared NVR storage or network capacity constrains scale.

512GB Edge Storage for Remote Sites

Much larger SD headroom than standard Q-Core/X-Core cameras — practical for locations with intermittent NVR connectivity or edge-first recording architectures.

Vandal-Rated for Publicly Accessible Mounts

IP66 aluminium plus IK10 impact rating handles building perimeters, covered walkways, and car park structures where deliberate interference and weather exposure are considered risks.

§ 05Where it fits

Right at home in these scenarios

Building Perimeters and Facades

150dB WDR handles the sunlit-facade / shaded-entry contrast typical of Australian building fronts; 50m IR sustains coverage across the approach path after site lighting shuts down.

Covered Walkways and Car Park Structures

Vandal-rated housing suits publicly accessible overhead mounts on parking structures; the motorised varifocal lens tunes framing to specific bay layouts without site revisits.

Multi-Camera Bandwidth-Constrained Sites

WiseStream II + H.265 keeps bandwidth predictable across many-camera commercial NVR deployments — the up-to-99% data reduction can be the difference between adopting 2MP HD everywhere and having to compromise on resolution.

Remote-Site Deployments With Intermittent Connectivity

The 512GB SD edge storage headroom supports remote sites where NVR connectivity may drop out — the camera continues recording locally for extended windows before storage limits are hit.

§ 06Setup

Installation & setup

01

What is in the Box

1. Hanwha XNV-6080R Camera x 1 2. Mounting Screws & Anchors x 1 set 3. Quick Start Guide x 1

02

Installation Requirements

1. Power: PoE (IEEE 802.3af). 2. Storage: SD/SDHC/SDXC card up to 512GB for edge recording (leverage the larger ceiling on remote sites). 3. Mounting: wall, ceiling, or soffit — aluminium vandal dome housing. 4. Sealing: preserve IP66 rating by sealing all cable and conduit entries.

03

App/Software Setup

1. Access via web viewer, or add to Hanwha Wisenet WAVE or SSM software. 2. Dial in framing across the 2.8-12mm range. 3. Enable WiseStream II + H.265 to maximise storage/bandwidth savings. 4. Configure loitering and directional detection analytics as required.

§ 08Questions

Frequently asked about the XNV-6080R

Q.01

Q: How does the WiseStream II 99% data reduction claim work?
A: WiseStream II dynamically adjusts encoding complexity based on scene motion, and when combined with H.265 the combined savings versus baseline H.264-without-WiseStream can reach 99% on quiet scenes. Practical impact: shared NVR storage across many cameras holds materially longer recording windows than an equivalent H.264 setup.
Q.02

Q: How far does the IR reach?
A: Built-in IR extends usable coverage to 50m — appropriate for driveways, covered walkways, and car park approach lanes overnight.
Q.03

Q: How much edge storage is supported?
A: SD/SDHC/SDXC up to 512GB — substantially larger than the 128GB/256GB ceilings on Q-Core and X-Core siblings. Fits remote sites or installations with intermittent NVR connectivity where extended edge-recording windows matter.
Q.04

Q: Is the housing rated for direct outdoor exposure?
A: Yes — IEC 60529 IP66 (dust-tight, water jets) and IEC 62262 IK10 (impact resistance). Aluminium construction with ivory finish suits building entrances and commercial exteriors where the camera should blend into architectural finishes.
Q.05

Q: What field of view can I dial in?
A: The 2.8-12mm motorised varifocal lens with 4.3x optical zoom covers wide entrance coverage at 2.8mm to focused approach shot at 12mm. Adjust remotely from web viewer.
Q.06

Q: What AI analytics are supported?
A: Loitering detection, directional movement detection, sound classification, and PTZ handover. Compared to X-Core/Q-Core siblings this is a lighter AI feature set — for full face/plate classification the C-series XNV-C6083R sibling is the AI-focused alternative.
Q.07

Q: How is this different from the XNV-C6083R sibling?
A: The XNV-6080R is the classic Wisenet X vandal dome with WiseStream II compression and 50m IR; the XNV-C6083R is on the newer X-Core AI platform with 40m IR but adds full face and licence plate classification alongside intrusion, loitering, and line crossing analytics. Pick XNV-6080R for compression efficiency and IR reach; pick XNV-C6083R for AI feature richness.
Q.08

Q: Can this integrate with third-party VMS?
A: Yes — supports ONVIF for standard third-party integration.
