Hikvision DS-3T1506HP-EI-UPS 4-Port Industrial PoE Switch with UPS Monitoring
1 1
Hikvision

Hikvision DS-3T1506HP-EI-UPS 4-Port Industrial PoE Switch with UPS Monitoring

SKU: DS-3T1506HP-EI-UPS
Description

The Hikvision DS-3T1506HP-EI-UPS is a four-port industrial Gigabit PoE switch with two SFP uplinks and battery status monitoring. Its total PoE budget changes with the input voltage: 110 W at 54 V or 60 W at 12 to 24 V. Rail, desktop and wall installation are supported. Download the official Hikvision datasheet (PDF).
$309.00 AUD $309.00 AUD $324.45 AUD
Sale 4.76% $15.45 AUD (4.76%)
Business or bulk buyer? Apply for trade pricing →
Found a lower price? We’ll match it →
Delivery, warranty & returns · ships same day before 2pm
  • Same-day dispatch on in-stock orders placed before 2pm, Sydney time.
  • 1–4 business days Australia-wide. Free standard shipping over $300, flat $25 under.
  • 3-year warranty on cameras and recorders, back-to-base, plus your Australian Consumer Law rights.
  • 30-day returns on unopened items. Faulty on arrival? We cover return shipping.
  • Genuine Australian stock. Never grey imports. Prices include GST.
  • American Express
  • Apple Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Union Pay
  • Visa

See all FAQs →

In stock

§ 01Overview

What the DS-3T1506HP-EI-UPS is

The Hikvision DS-3T1506HP-EI-UPS is a four-port industrial Gigabit PoE switch with two SFP uplinks and battery status monitoring.

Select the power and backup arrangement around the required load. Battery monitoring does not establish a supplied battery or a guaranteed backup runtime.

Match the input voltage, battery arrangement and total load. Ports 3 and 4 have configurable passive power modes; use those modes only with matching devices. Protect the IP30 unit inside a suitable enclosure.

§ 02Engineering

DS-3T1506HP-EI-UPS specifications

Hikvision DS-3T1506HP-EI-UPS PoE connections — 4 Gigabit PoE ports
Uplinks — 2 Gigabit SFP ports
Shared PoE budget — 110 W with 54 V input; 60 W with 12 to 24 V input
Power input — 12 VDC 10 A, 24 VDC 5 A or 54 VDC 2.22 A
High-power port — Port 1 supports up to 90 W, subject to the input-dependent budget
Management — Battery status monitoring and one RS-485 interface
Protection — IP30 metal enclosure; -40 to 75 C operation

§ 03Full datasheet

Detailed specifications

Specification

Specification — Hikvision DS-3T1506HP-EI-UPS 4-Port Industrial PoE Switch with UPS Monitoring
FeatureDetail
PoE connections 4 Gigabit PoE ports
Uplinks 2 Gigabit SFP ports
Shared PoE budget 110 W with 54 V input; 60 W with 12 to 24 V input
Power input 12 VDC 10 A, 24 VDC 5 A or 54 VDC 2.22 A
High-power port Port 1 supports up to 90 W, subject to the input-dependent budget
Management Battery status monitoring and one RS-485 interface
Protection IP30 metal enclosure; -40 to 75 C operation

§ 08Questions

Frequently asked about the DS-3T1506HP-EI-UPS

Q.01

What is the DS-3T1506HP-EI-UPS?
The Hikvision DS-3T1506HP-EI-UPS is a four-port industrial Gigabit PoE switch with two SFP uplinks and battery status monitoring.
Q.02

How many powered ports are available?
4 Gigabit PoE ports.
Q.03

What fibre connections are provided?
2 Gigabit SFP ports.
Q.04

How does input voltage affect the power budget?
110 W with 54 V input; 60 W with 12 to 24 V input.
Q.05

Which supply arrangements are supported?
12 VDC 10 A, 24 VDC 5 A or 54 VDC 2.22 A.
Q.06

Can the switch supply 90 W to one device?
Port 1 supports up to 90 W, subject to the input-dependent budget.
Q.07

What should I check before ordering?
Match the input voltage, battery arrangement and total load. Ports 3 and 4 have configurable passive power modes; use those modes only with matching devices. Protect the IP30 unit inside a suitable enclosure.
